HyperX CloudX Stinger Core Manual

Overview

Overview

  1. Swivel-to-mute microphone
  2. Status LED
  3. Power button
  4. Volume wheel
  5. USB charge port
  6. Pairing button
  7. Game/chat balance wheel
  8. USB charge cable

Charging

It is recommended to fully charge your headset before first use
Charging the unit

CHARGE STATUS LED
Fully charged Solid white
15% — 99% battery Breathing white
< 15% battery Breathing red

Power Button

Power on/off – Hold power button for 3 seconds

Mic monitoring

Short press power button to toggle mic monitoring on/off

Setup for Xbox Console Usage

Mic monitoring

  1. Power on the Xbox console. Press the connect button on your Xbox Console. The Xbox logo on the console will start blinking
  2. Power on the headset. Press and hold the pairing button for 3 seconds to enter pairing mode. The headset status LED will start blinking green
  3. The headset will connect to the Xbox Console

Volume Wheel

Scroll up or down to adjust volume level.


Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time.

Game/Chat Balance Wheel

Game/Chat Balance Wheel functionality
Scroll up or down to adjust mix between game audio and chat audio

The game/chat balance functionality operates independently from the overall headset audio volume

Swivel to Mute Microphone

Questions or Setup Issues?
Contact the HyperX support team at hyperx.com/support
