HyperX Cloud II Wireless Gaming Headset HHSC2X-BA-RD/G Manual

Overview

Overview Step 1

Overview Step 2

Overview Step 3

Overview Step 4

  1. Mic mute / mic monitoring button
  2. USB charge port
  3. Microphone port
  4. Status LED
  5. Power / 7.1 Surround Sound button
  6. Volume wheel
  7. Detachable microphone
  8. Microphone mute LED
  9. USB adapter
  10. Wireless pairing pin hole
  11. Wireless status LED
  12. USB charge cable

Specifications

Headphone
Driver: Dynamic, 53mm with neodymium magnets
Type: Circumaural, Closed back
Frequency response: 15Hz–20kHz
Impedance: 60 Ω
Sound pressure level: 104dBSPL/mW at 1kHz
T.H.D.: ≤ 1%
Weight: 300g
Weight with mic: 309g
Cable length and type: USB charge cable (0.5m)

Microphone
Element: Electret condenser microphone
Polar pattern: Bi-directional, Noise-cancelling
Frequency response: 50Hz-6.8kHz
Sensitivity: -20dBV (1V/Pa at 1kHz)

Battery life*
30 hours

Wireless Range**
2.4 GHz
Up to 20 meters

*Tested at 50% headphone volume. Battery life varies depending upon the usage.
**Wireless range may vary due to environmental conditions.

Setting up with PC

  1. Connect the wireless USB adapter to the PC.
    Setting up with PC Step 1
    Setting up with PC Step 2
  2. Power on the headset.
  3. Right click speaker icon > Select Open Sound settings > Select Sound Control Panel
    Setting up with PC Step 3
    Setting up with PC Step 4
  4. Under the Playback tab, click on "HyperX Cloud II Wireless" and click on the Set Default button.
    Setting up with PC Step 5
  5. Right click on "HyperX Cloud II Wireless" and click on Configure Speakers.
    Setting up with PC Step 6
  6. Select 7.1 Surround as the speaker configuration and click next.
    Setting up with PC Step 7
  7. Under the Recording tab, click on "HyperX Cloud II Wireless" and click on the Set Default button.
    Setting up with PC Step 8
  8. Under the Playback tab, verify that "HyperX Cloud II Wireless" is set as Default Device and Default Communication Device. Under the Recording tab, verify that "HyperX Cloud II Wireless" is set as Default Device.
    Setting up with PC Step 9
    Setting up with PC Step 10

Setting up with PlayStation 4

  1. Set Input Device to USB Headset (HyperX Cloud II Wireless)
    Setting up with PlayStation 4 Step 1
    Setting up with PlayStation 4 Step 2
  2. Set Output Device to USB Headset (HyperX Cloud II Wireless)
  3. Set Output to Headphones to All Audio
  4. Set Volume Control (Headphones) to maximum.
    Setting up with PlayStation 4 Step 3

Controls

Controls

Status LED

Status Battery Level LED
Pairing - Flash green and red every 0.2s
Searching - Slow breathing green

Connected
 90% - 100% Solid green
15% - 90% Blinking green
< 15% Blinking red

Power / 7.1 Surround Sound button

  • Hold for 3 seconds to power headset on/off
  • Press to toggle 7.1 Surround Sound* on/off
    *Virtual 7.1 surround sound outputs as a 2 channel stereo signal to be used with stereo headphones.

Mic mute / mic monitoring button

  • Press to toggle mic mute on/off
    • LED On – Mic muted
    • LED Off – Mic active
  • Hold for 3 seconds to toggle mic monitoring on/off

Volume wheel

Volume wheel

  • Scroll up and down to adjust volume level


Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time

Charging the Headset

It is recommended to fully charge your headset before first use.
When charging the headset, the headset status LED will indicate the current charge status.

Status LED Charge Status
Solid green Fully charged
Breathing green 15% - 99% battery level
Breathing red < 15% battery level

Wired charging

Wired charging
To charge the headset via wired, plug the headset to a USB port with the USB charge cable.

HyperX NGENUITY Software

Download NGENUITY software at: hyperxgaming.com/ngenuity

Manually Pairing the Headset and USB Adapter

The headset and USB adapter are automatically paired together out of the box. But if manual pairing is needed, follow the steps below to pair the headset and USB adapter.

  1. While the headset is powered off, hold down the power button until the headset status LED starts blinking red/green rapidly. The headset is now in pairing mode.
    Manually Pairing the Headset and USB Adapter Step 1
  2. While the USB adapter is plugged in, use a small tool (e.g. paper clip, SIM tray ejector, etc.) to hold down the button inside the pin hole until the USB adapter LED starts blinking rapidly. The USB adapter is now in pairing mode.
    Manually Pairing the Headset and USB Adapter Step 2
  3. Wait until both the headset LED and the USB adapter LED are solid.

The headset and USB adapter are now paired together.

Questions or Setup Issues?

Contact the HyperX support team at: hyperxgaming.com/support/
