Etec EX400SM Installation Manual
Etec EX400SM Installation Manual

Etec EX400SM Installation Manual

Tilting & swiveling flat panel wall mount

Advertisement

Quick Links

For technical assistance or troubleshooting
This product Wall Mount frame is intended for use only with an apparatus which has a maximum weight of 77 lbs. See apparatus
instructions. Using with an apparatus heavier than the maximum weight indicated may result in instability and cause possible
injury.
READ THIS FIRST Read this entire manual! Do not attempt to install this product if you do not understand the instructions.
Contact a qualified mount installer if you have any doubts about a safe and secure mount installation, or if you are not sure what
specific wall materials you are attaching this mount to. Check all the parts carefully to make sure there are no missing or
damaged parts. Improper installation may result in damage to your TV, property, and personal injury.
Tilting & Swiveling
Flat Panel Wall Mount
Installation Guide
Model: EX400SM
• Supports most 14" - 47" Flat Panel TVs
• Maximum weight capacity: 77 lbs.
• Supports VESA Sizes up to 400X400
please call 1-855-994-3832.
• Easy installation
• Low profile
• Built-in level for easy positioning
• Corrective leveling adjustments
after installation
• Forward / backward tilt range:
+5 to -15 degrees
• Left to right swivel range: 180 degrees
• Extension range: 2.7" to 18.5
"

Advertisement

loading
Need help?

Need help?

Do you have a question about the EX400SM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Etec EX400SM

  • Page 1 Tilting & Swiveling Flat Panel Wall Mount Installation Guide Model: EX400SM • Easy installation • Low profile • Built-in level for easy positioning • Corrective leveling adjustments after installation • Forward / backward tilt range: +5 to -15 degrees • Left to right swivel range: 180 degrees ”...
  • Page 2 Schoenfeld International Inc. and ETEC are not responsible for personal injury or product damage due to mishandling, incorrect mounting, incorrect assembly, or incorrect use of this product.
  • Page 3 Wall plate TV plate Plastic covers Left Extenders 7 Bubble Level Magnet Right Extenders Concrete Anchor M4x12mm bolts M4/M5 washers M4x30mm bolts M6/M8 washers Allen wrench M5x12mm bolts Socket tool M6x12mm bolts M6x35mm bolts M6x10mm bolt M8x16mm bolts M8x25mm bolts The actual appearance and quantity of parts may be different than shown in the illustration.
  • Page 4 Install the TV Plate on the television If your television is VESA 200x200 or smaller, mount the TV Plate (2) directly on the back of the television. Extenders are not required as shown in Fig. 1a. If your television is larger than VESA 200x200, install the extenders (3 & 4) on the TV plate (2) eight with the bolts (S) before installing the plate on the television (Fig.
  • Page 5 Use the selected bolts (D-J) and the washers (L-M) to install the TV Plate (2) with or without the extenders (3-4) to the rear of the TV as shown below in Fig 1b or 1c. Tighten securely using the Allen wrench (P). Do not over tighten. If the VESA is 200X200 or less on the TV, attach the TV plate (without extenders) as shown in Fig 1b.
  • Page 6 Step 2. Find and mark the best position for the wall mount on the wall. The best viewing height is parallel to the eye level of a person sitting on a couch. Normally, this is about 4 feet above floor level. In addition to your eye level height when you are seated, the following two measurements will help you determine the perfect height for your wall-mounted television: •...
  • Page 7 in the exact center of the stud. Use the Socket tool (Q), the two long bolts (A), and Washers (C), to attach the wall mount to the wall. Do not use wall anchors in wood stud walls. 6. Press the covers (5) on to each end of the Wall plate (Fig. 3c). Fig.
  • Page 8: Concrete Wall

    2.5” Use the Socket tool (Q), the two long bolts (A), and Washers (C), to attach the wall mount to the wall. 6. Press the covers (5) on to each end of the Wall plate (Fig.3e). 2.5” (65mm) Fig. 3d Concrete Wall 7 Bubble Level Fig.
  • Page 9 Step 4. Hang the Television Display 1. Lift the TV display with the bracket assembly securely attached with two people. 2. Hook the tab on the top of the TV Plate (2) over the top on the front of the Wall Plate arm as shown in Fig.
  • Page 10: Step 5. Adjusting The Tilt

    Step 5. Adjusting the Tilt 1. The Handles on the front of the Wall Plate mount arm are used to adjust the tilt angle of the TV to your desired angle. 2. These handles are tension levers. To loosen the tilt adjustment, turn the handle counter clock-wise until the handle hits the connecting plate and can turn no more.
  • Page 11 We warrant this product to you, the original purchaser at the time of purchase printed on a dated store receipt from an authorized ETEC retailer and for a period of six-years thereafter that our wall mount product and all it’s parts and components are free of defects in material and workmanship under normal use.
  • Page 12 Schoenfeld International Inc. and ETEC 5001 American Boulevard West Suite 275 Bloomington, MN 55437 ©Schoenfeld International Inc. 2013 PN: EX400SM Rev 1.3 October, 2013...
