- Page 1 ECOVACS：机密图档 平面印刷品基本技术要求 科沃斯机器人股份有限公司 物料名称 T30 系列高低配版说明书 - 美国 - 认证 尺 寸 145*210mm 型 号 ZJ2310 印刷颜色 单色 K 物料编码 451-2310-**** 装订方式 骑马钉 版 次 页 数 材 质 封面 157 哑粉纸 + 内页 80g 双胶纸 比 例 变更记录： 设计 审核...
- Page 2 Instruction Manual/Manuel d’instructions...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 4. Only use as described in this manual. Only use attachments recommended or sold by the IMPORTANT SAFETY INSTRUCTIONS manufacturer. READ ALL INSTRUCTIONS BEFORE 5. Do not handle plug or appliance with wet hands. USING THIS APPLIANCE. 6. - Page 4 14. Do not use to pick up flammable or Station if it is not working properly, has been combustible materials such as gasoline, printer dropped, damaged, left outdoors, or come in or copier toner, or use in areas where they may contact with water.
- Page 5 Instruction Manual. to fire or excessive temperature. Exposure to ECOVACS ROBOTICS cannot be held liable or fire or temperature above 130°C may cause responsible for any damages or injuries caused explosion. The temperature of 130°C can be by improper use.
- Page 6 39. Recharge only with the charger specified by 48. Please make sure your power supply voltage the manufacturer. A charger that is suitable for matches the power voltage marked on the one type of battery pack may create a risk of Docking Station.
- Page 7 Increase the separation between the equipment and Direct current receiver. Connect the equipment into an outlet on a circuit Alternating current different from that to which the receiver is connected. This Device Complies with DHHS Radiation Rules, Consult the dealer or an experienced radio/TV 21CFR Chapter 1, Subchapter J.
- Page 8 OUTLET seconds. And press and hold the AUTO Mode Button on the robot for 30 seconds. To enable Wi-Fi module on DEEBOT, power the robot OFF and then power ON. And unplug the Station and plug it again. GROUNDING PIN...
- Page 9 Device Update For INDOOR household use ONLY. This device contains licence-exempt transmitter(s)/ Typically, some devices are updated bi-monthly, but not receiver(s) that comply with Innovation, Science and always so specific. Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: Some devices, especially those that went on sale more than three years ago, will only be updated if a critical (1) This device may not cause interference.
-
Page 10: Package Contents
PACKAGE CONTENTS Robot Base Power Cord OMNI Station 地 面 清 洁 机 器 人 说 明 书 使用产品前请仔细阅读此说明书，并妥善保管。 Clean Water Tank Dirty Water Tank Side Brush Instruction Manual Note: * Figures and illustrations are for reference only and may differ from actual product appearance. Product design and specifications are subject to changes without notice. * Ag+ Antibacterial Module is compatible with the water tank. -
Page 11: Product Diagram
For professional Buttons on default settings. maintenance personnel Station use only. TrueDetect 3D Sensor Buttons on DEEBOT Microphone Wi-Fi Status Long press: Self-clean Short press: Exit/Return to the Station Indicator Long press: Power on/Power off Short press: Start/Pause/Continue Long press: Child Lock... - Page 12 Bottom View Universal Wheel Ultrasonic Sensor Side Brush Charging Contacts Brush Driving Wheels Water Filling Port* * Due to different product configurations, there may be models without a water filling port. Mopping Pad Assembly Anti-drop Sensors Mopping Pad Plates Brush Release Button Mounting Slots for Mopping Pad...
- Page 13 OMNI Station(Back) Note: * If the Light Strip is flashing red, please check the reason in ECOVACS HOME App. * If DEEBOT fails to charge, please wipe Charging Contacts with a clean and dry cloth. Light Strip Glowing Blue(Low brightness): Standby...
- Page 14 With Infrared Ranging-detecting the distance between the bottom of DEEBOT and ground by Infrared Sensor at the Anti-drop Sensor bottom, DEEBOT will not move forward when there are stairs in front or the identified distance exceeds the preset one, realizing the Anti-drop. The trigger distance is 60mm.
-
Page 15: Notes Before Cleaning
NOTES BEFORE CLEANING Tidy up the area to be cleaned by putting furniture, such as chairs, in During the first use, make sure each room door is open to help DEEBOT fully their proper place. explore your house. It may be necessary to place a physical barrier at the edge of a drop to Put away objects including cables, cloths and slippers, etc. -
Page 16: Quick Start
QUICK START DOWNLOAD THE ECOVACS HOME APP Before using DEEBOT, please remove all protective materials. To enjoy all available features, it is recommended to control your DEEBOT via the ECOVACS HOME App. Installation 1. Scan the QR Code under the Top Cover to download the App. - Page 17 Please be aware that the realization of intelligent functions such as remote startup, voice interaction, 2D/3D map display and control Turn on the DEEBOT and mobile phone Bluetooth. Allow the App to settings, and personalized cleaning (depending on different products) obtain mobile phone Bluetooth permission.
- Page 18 CHARGE DEEBOT Place the Station Assemble the Station Keep the area around the Station clear of objects especially objects with reflective surfaces. Note: • If there are reflective objects such as mirrors and reflective skirting lines near the Station, the bottom 14cm of that should be covered.
- Page 19 Use Tanks Power ON Long press to power ON. • DEEBOT cannot be charged when being powered OFF. • When DEEBOT is not working, it is recommended to keep it powered ON and charging. Long press Charge DEEBOT Short press to recall DEEBOT to enter the Station to charge.
- Page 20 Back to Station Short press to recall DEEBOT to the OMNI Station. When creating a map for the first time, please follow DEEBOT to help eliminate some minor issues. For example, DEEBOT may get stuck under the furniture. Please refer to the following solutions: 1.
- Page 21 MOPPING Attach the Mopping Pads and Mopping Pad Plates You would hear a “click” when the Mopping Pad Plates are properly Short press to start mopping. installed. Short press Note: 1. Do not frequently remove washable mopping pads. 2. Do not scratch the Mopping Pad Plates with a rag or any other object. 3.
-
Page 22: Regular Maintenance
REGULAR MAINTENANCE To keep DEEBOT running at peak performance, perform maintenance tasks and replace parts at the following frequencies: Robot Part Maintenance Frequency Replacement Frequency Washable Mopping Pad Every 1-2 months Dust Bag Replace when voice prompts Side Brush Once every 2 weeks... - Page 23 MAINTAIN DUST BIN AND FILTER Note: 1. Please rinse the filter with water as shown above. 2. Do not use finger or brush to clean the filter. Note: Maintenance tools are not included. Please clean with your own brush or Note: Completely dry the filter before use.
