Northwest 80-WSG032 Owner's Manual

Curved wall mounted/free stand electric fireplace, wall hanging/freestanding mode ac 120v 60hz 1500w
Hide thumbs

Advertisement

Table of Contents

Curved Wall Mounted / Free stand Electric Fireplace
Model Numbers: 80-WSG032
OWNER'S MANUAL
Wall Hanging Mode
Freestanding Mode
AC 120V 60HZ 1500W
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80-WSG032 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Northwest 80-WSG032

Summary of Contents for Northwest 80-WSG032

  • Page 1 Curved Wall Mounted / Free stand Electric Fireplace Model Numbers: 80-WSG032 OWNER’S MANUAL Wall Hanging Mode Freestanding Mode AC 120V 60HZ 1500W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.
  • Page 2 IMPORTANT SAFETY INFORMATION! WARNING  Read all instructions before using this heater!  This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear.
  • Page 3 WARNING  For residential use only! NOT for commercial use! Any commercial or public use of this heater voids all warranties, and could cause injury.  This product is not intended to be a primary heat source. It is for supplemental heat only. ...

  • Page 4: Parts And Hardware

     The power cord supplied with the heater has three prongs: two flat blades (live and neutral) and one round pin (ground). If a 3-slot receptacle is not available, an adapter MUST be used. The adapter MUST be properly grounded to the outlet box (see figure at right).

  • Page 5: Installation And Assembly

    Installation and Assembly Step 1. Find a safe location. Rear View of Fireplace Minimum clearance on each side: 19.7” (50 cm). Minimum 39.4” Minimum clearance below: (100 cm) 19.7” (50 cm). Minimum clearance above: 39.4” (100 cm). 19.7” 19.7” Minimum clearance from the front (50 cm) (50 cm) and sides: 19.7”...
  • Page 6 STEP2 ) Using the three wood screws (B) to fix the wall bracket , with wood screws thread the wall bracket and to lock with the drywall anchors, please tighten all wood screws.
  • Page 7 STEP 3) Have two people lift the fireplace machine up and insert the hooks ( 2 hooks on back of fireplace box) to the wall bracket slot. STEP 4) With the fireplace installed safely, then using screws driver to lock the bracket and fireplace with two ST4x10 (D) screws in both sides.Check the appliance for stability ensuring that the appliance will not pull free from the wall.

  • Page 8: Operation

    Installation for Metal Stand J1/J2 STEP 6A.Fix the J1 and J2 metal parts with screws ( G ) , in total two sets. Using screws (D) to fix the two stand brackets ( F ) to the J1/J2.8 screws (D) will be used. STEP 6B.Put the fireplace on a soft surface flatly,see the drawing above,locate the bracket to the bottom mounting holes,fix the baseboard with 8pcs ST4x10 screws(D) Tighten each screw securely with a Phillips screwdriver.
  • Page 9 Before operating, please review the IMPORTANT SAFETY INFORMATION on Pages 2 and 3, and heed all warnings. Control Panel / Remote Control Operation (Control panel POWER switch must be ON to use remote control.) BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1.

  • Page 10: Care And Maintenance

    1. Press once. Indicator lights up. HEATER button: Turns heater on and off. Fan blows cool air for 10 seconds. 750W NOTE: The heater only works when the heater turns on and blows warm air. flame effect is on. If the flame effect is off, 2.
  • Page 11 ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.
