Northwest BEF-42WM03 Owner's Manual

Wall mounted & wall recessed linear electric fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wall Mounted & Wall Recessed
Model#:
80-BEF-42W (BEF-42WM03)
WARNING
CAUTION
This electric fireplace has a remote that requires a
button battery that are hazardous to young children.
OWNER'S MANUAL
42"/60" Wall Mounted / Built-in Electric Fireplace
AC 120V 60Hz 1465W
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
Linear Electric Fireplace
80-BEF-60W (BEF-60WM03)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEF-42WM03 and is the answer not in the manual?

Questions and answers

Related Manuals for Northwest BEF-42WM03

Summary of Contents for Northwest BEF-42WM03

  • Page 1 Wall Mounted & Wall Recessed Linear Electric Fireplace Model#: 80-BEF-42W (BEF-42WM03) 80-BEF-60W (BEF-60WM03) OWNER’S MANUAL 42"/60" Wall Mounted / Built-in Electric Fireplace AC 120V 60Hz 1465W Read and understand this entire owner’s manual, including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING  Read all instructions before using this heater!  This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear.
  • Page 3  NEVER leave this heater unattended. ALWAYS unplug this heater when not in use.  ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet.  NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or connections. Plugging this heater into a faulty outlet could result in electric arcing within the outlet that could cause the outlet to overheat or catch fire.

  • Page 4: Parts And Hardware

    Parts and Hardware B – Wood Screws C – Drywall anchors A – Fireplace D- Remote Control E - “L”Shape Bracket F-Metal cover G-Box H-Decorative clear I - Log-set plate connector crystals Specification and Dimension PRODUCT DIMENSIONS Model Number 42” 18”...

  • Page 5: Installation And Assembly

    Installation and Assembly Your appliance is a wall-mounted, recessed and/or mantel installed appliance. Select a suitable location that is not susceptible to moisture and is away from drapes, furniture and high traffic areas. NOTE: Follow all National and local electrical codes. MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front.
  • Page 6 Wall Recessed Pre-installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance. A. Select a location that is not prone to moisture and is located at least 36” (94.1cm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
  • Page 7 Front Glass Panel Removal A. Take off the screws on both side.(Fig. 1-1 ) B. Carefully lift the front trim up and away from the appliance (Fig. 1-2 ). Place it face down on a soft, non- abrasive surface. C. Reverse these steps to install the front glass. Fig.
  • Page 8 Wall Recessed Installation A.Take off the screws (1 per side) from the sides of the fireplace. Set the screws aside (Fig. 2-1 ) B.Remove the two brackets and set them aside.(Fig. 2-2 ) Fig. 2-1 Fig. 2-2 D. Power the fireplace by plug-into the wall receptacle. E.

  • Page 9: Wall Mounted Installation

    Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. A.Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc.
  • Page 10 “L” Shape Bracket Installation A.Remove the silver screw at the bottom of the appliance. (Fig 4-1). Set the screw aside. Fig 4-1 Fig 4-2 B.Using the screw previously removed, attached the L-bracket (supplied) to the bottom of the fireplace box.(Fig 4-2) Fig 4-3 D.

  • Page 11: Hard Wiring Installation

    Hard Wiring Installation WARNING TURN OFF THE APPLIANCE COMPLETELY AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. HARD WIRING CONNECTION If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring.

  • Page 12: Operation

    Decorative Crystals & Log-set Installation Glass front must be removed and the appliance must be mounted in its final location before the log-set and crystals are installed. Remove the log-set (I) from the package, put it to the fireplace designed place. Fig 6-1. To switch to crystals, take out the log-set from ember bed, then carefully place the crystals (H) into the ember bed slot.
  • Page 13 Touch-on Control Panel Operation BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and 1. Press once. Indicator light turns on. Power remote control. Turns on flame effect. turns on. All functions enabled. OFF: Disables control panel functions and 2.
  • Page 14 COLOR button: Makes the color flame effect 1. Press once. Flame color effect gets changing. changing. NOTE: color effect stays on until power button 2. Press again until desired setting is reached. is turned off. Color flame effect must be on for In total with 10 color flames.
  • Page 15 Remote Control Battery Information Remote control uses one CR2025 battery (INCLUDED) Remove and immediately recycle or dispose of used  batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or  incinerate.

  • Page 16: Care And Maintenance

    Care and Maintenance Cleaning ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, fire, or personal injury.

  • Page 17: Customer Service

    Customer Service Contact us through our website: www.TeamCustomerService.com If you have a question about assembly, use or a possible missing part, Please contact us and we will be glad to assist you.
