用户手册 / 组装说明
ZH
EN
Instructions for use / Assembly instructions
2
3
Talis S
32313007
Logis
71300007
Talis E
71748XX7
Metris S
31443007 / 31447007
Logis
71314007
Talis S
72419007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Talis E 71748 7 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hans Grohe Talis E 71748 7 Series

  • Page 1 用户手册 / 组装说明 Instructions for use / Assembly instructions Talis S Metris S 32313007 31443007 / 31447007 Logis Logis 71314007 71300007 Talis S Talis E 72419007 71748XX7...
  • Page 2 中文 安全须知 符号说明 ! 装配时为避免挤压和切割受伤, 必须戴上手套. 请勿使用含有乙酸的硅胶! ! 本产品只允许作为洗浴, 卫生和洁身之用. 大小 (参见第页 13) ! 必须避免让身体敏感部位 (如眼睛) 接触到莲蓬 头喷水. 必须保持莲蓬头与人头之间有足够的距 流量示意图 (参见第页 15) 离. ! 该产品不得作扶柄使用. 必须安装单独的扶柄. 1 手持花洒 ! 冷热水管间过大的压力差必须予以平衡. 2 浴缸出水口 安装提示 备用零件 (参见第页 16) • 安装前必须检查产品是否受到运输损害. 安装后 XX = 颜色代码 将不认可运输损害或表面损伤. 00 = 镀铬 • 管道和阀门必须根据通用标准进行安装, 冲洗和 14 = Matt Black 检查.
  • Page 3: Safety Notes

    English Safety Notes Symbol description Gloves should be worn during installation to prevent Do not use silicone containing acetic acid! crushing and cutting injuries. Dimensions (see page 13) The product may only be used for bathing, hygienic and body cleaning purposes. Flow diagram (see page 15) Do not allow the streams of the shower touch sensitive body parts (such as your eyes).
  • Page 4 Talis S 32313007 / Logis 71300007 13233187 (1,8 Nm) 32313007 / 71300007...
  • Page 5 Talis S 32313007 / Logis 71300007 27 mm 3 mm (2 Nm) > 2 min...
  • Page 6 Metris S 31443007 / Metris S 31447007 / Logis 71314007 / Talis E 71748XX7 / Talis S 72419007 13244187 (1,8 Nm) 31443007 /31447007 / 71314007 (1,8 Nm) 71748XX7 / 72419007...
  • Page 7 Metris S 31443007 / Metris S 31447007 Logis 71314007 / Talis E 71748XX7 / Talis S 72419007 27 mm 3 mm (2 Nm)
  • Page 8 Metris S 31443007 / Metris S 31447007 / Logis 71314007 / Talis E 71748XX7 / Talis S 72419007 > 2 min...
  • Page 9 开 / open 关 / close 冷 / cold 热 / hot 开 / open...
  • Page 10 • • • • • Hansgrohe • , Hansgrohe • www.hansgrohe.com.cn/service/producer-quarantee. • • QuickClean QuickClean, • • QUICK QUICK CLEAN CLEAN...
  • Page 11: Warranty

    English • After cleaning rinse thoroughly with clean water to Cleaning Recommendation for Hans- remove any cleaner residue. grohe Products • The use of steam cleaners is not permitted. The high Today, modern sanitary and kitchen tapware, showers, temperatures can damage the products. accessories, washstands, sinks, tubs and radiators consist Important of very different materials to comply with the needs of...
  • Page 12 #94246000 > 1 min...
  • Page 13 Talis S Logis 32313007 71300007 Ø 2 9 4 2 / 4 2 12 5 12 5 12 5 12 5 Metris S 31447007 14 0 Ø 10 9 Metris S 31443007 14 0 Ø 10 9...
  • Page 14 Logis 71314007 42/42 Talis E 71748XX7 16 5 19 6 Ø 6 0 Ø 5 2 Ø 7 0 Ø 6 0 12 5 12 5 12 5 Talis S 72419007 Ø 29 Ø 48 Ø 60 Ø 70 Ø 60 Ø...
  • Page 15 Logis 71300007 / 71314007 Talis S 32313007 0,60 0,55 0,60 0,50 0,55 0,45 0,50 0,40 0,45 0,35 0,40 0,30 0,35 0,25 0,30 0,20 0,25 0,15 0,20 0,10 0,15 0,05 0,10 0,00 0,05 9 12 15 18 21 24 27 30 Q = l/min 0,00 Q = l/sec...
  • Page 16 Logis 71300007 95463000 92461000 (M24x1 - 30 l⁄min) 97660000 (M6x6) 3 mm 97779000 98183000 (23x2,5) 88512000 94184000 98211000 96299000 (21x2,5) 92250000 31098000 31098000 Logis 71314007 92461000 95464000 (M24x1 - 30 l⁄min) 96774000 97660000 28583000 (M6x6) 93339007 3 mm 94246000 28071000 97779000 98219000 (21x1,5)
  • Page 17 Talis S 32313007 95463000 95456000 97660000 98183000 (23x2,5) 97779000 95462000 88512000 98211000 (21x2,5) 31098000 95461000 94184000 Metris S 98956000 (171 mm) 98420000 (220 mm) 31443007 / 31447007 13914000 96774000 26530000 97660000 93339007 97779000 94246000 98219000 (21x1,5) 28071000 92214000 97159000 31097000 31096000 94184000 98189000...
  • Page 18 Talis S 72419007 98707000 92782000 97660000 98219000 96512000 (21x1,5) 97779000 26805400 93339007 94246000 92781000 28071000 94184000 97159000 95819000 98189000 31098000 (14x2,5) 98183000 (23x2,5) 98749000 98185000 (22x2) 96775000 98217000 (9x2,5) Talis E 92780XX0 71748XX7 98707XX0 97660000 96512XX0 98168000 (41x1,5) 97779XX0 26801407 93339007 94246000 92779XX0...
  • Page 20 Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon +49 (0) 78 36⁄51-1282 · Telefax +49 (0) 7836⁄511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
