- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Charbroil 04201101 Owner's Manual Shop genuine replacement parts for Charbroil 04201101 Find Your Charbroil Grill Parts - Select From 3592 Models -------- Manual continues below --------...
-
Page 2: Tools Needed For Assembly
04201101 04201101 Smoker, BBQ and Grill Smoker, BBQ and Grill Tools needed for assembly: Phillips screwdriver Adjustable wrench THIS UNIT IS HEAVY. DO NOT assemble without helper. CARBON MONOXIDE HAZARD Burning charcoal inside can kill Some parts may contain sharp edges - especially as noted in you. - Page 3 STOP! Call Our Help Line Missing a part? No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
- Page 4 • Attach one long leg and one short leg to make two leg assemblies Note: Short leg has two holes. Short Leg Long Leg • Position wood rack between legs and insert hooked ends of rack into holes on insides of legs. Note: Rack wires running front-to-back should be on bottom, side-to-side wires on top.
- Page 5 • Lay unit onto its back. Cotter Pin • Attach leg braces on each side using four #10- Wheel 24 x 1-3/4” screws and four 10-24 flange nuts per brace. Axle • Thread axle rod through both short legs. • Attach wheels onto axle rod using cotter pins. Bend cotter pin ends to prevent them from backing out of axle as shown in box A.
- Page 6 • Attach knockout cover to firebox with two Lids removed for clarity 8-32 x 1/2” screws and two 8-32 keps nuts Firebox • Place firebox onto smoker chamber. Fasten with six 1/4-20 x 3/4” screws, 1/4” flat washers and 1/4-20 flange nuts. Firebox Smoker Chamber...
- Page 7 • Fasten each shelf bracket to smoker chamber with one 1/4-20 x 1-1/4” screw and 1/4-20 flange nut. • Attach wood slats to shelf bracket with six 10-24 x 1” screws and 10-24 flange nuts. Wood Slat Lid removed for clarity Shelf Bracket Lid removed for clarity •...
- Page 8 • Attach handles on both the smoker chamber lid and firebox lid with two 1/4-20 x 3” screws, two washers, two spacers and two 1/4-20 flange nuts. • Attach logo plate using two Tennerman clips. • Push 13/16” hole plug into lid. Hole Plug Smoker Chamber Lid Wood Handle...
- Page 9 • Hang the grease clip under the smoker chamber on right side. • An empty soup can is recommended to hang from grease clip. Grease Clip...
-
Page 10: Hardware List
HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. Tennerman Clip Cotter Pin 1/4” Spacer Qty. 2 Qty:2 Flat Washer 13/16” Qty. 4 Qty. 10 Hole Plug Qty. 1 #8-32x1/2” #8-32 Machine Screw Keps Nut Qty. - Page 11 Before you begin . . . With any type of live fire cooking, allow enough time to build a fire and get the grill/smoker up to temperature. Familairize yourself with the major components and controls of Build a fire using either charcoal briquettes, lump charcoal, or the unit.
-
Page 12: Maintenance
Grilling Maintenance Position both fire grates in the smoker chamber. Build a fire on When finished cooking, and the unit has adequately cooled, top of the fire grates using either charcoal briquettes, lump clean out all remaining ashes. Ashes collect moisture, which charcoal, or wood chunks. - Page 13 KEEPERS OF THE FLAME Columbus, GA...
