Summary of Contents for Vivosun AeroLight A100
- Page 1 AeroLight USER MANUAL...
- Page 2 At Vivosun, quality craftsmanship and innovation are at the core of every product we create. Should you require further support or wish to share any suggestions, please don't hesitate to contact us.
- Page 3 PRODUCTS INCLUDED IN THIS MANUAL: Product AeroLight 100W VSA100 AeroLight 150W VSA150 AeroLight Wing 200W VSAW200 AeroLight Wing 400W VSAW400...
-
Page 4: Table Of Contents
CONTENTS Key Features Product Contents Smart Grow System Spectrum Dimensions Specifications Installation Application Warranty Information Warning... -
Page 5: Key Features
KEY FEATURES VSA100/VSA150 UNIFORM LIGHT & AIR 2-IN-1 GROW LIGHT BETTER CIRCULATION Patented grow light design With the central placement of Creative hollow light design with integrated highly the fan you have better air, and wind guide provide reliable circulation fan. circulation, and humidity. - Page 6 KEY FEATURES VSAW200/VSAW400 2-IN-1 GROW LIGHT BETTER CIRCULATION UNIFORM LIGHT & AIR Patented grow light design With the central placement of Creative hollow light design with integrated highly the fan you have better air, and wind guide provide reliable circulation fan. circulation, and humidity.
-
Page 7: Product Contents
PRODUCT CONTENTS VSA100/VSA150 LED Light Power Cord RJ45 Network Cable x 1pc x 1pc x 1pc Rope Hanger Hook H Bracket* Hex Wrench* x 2pcs x 2pcs x 1pc x 1pc * Not included if sold with the GrowHub kit. - Page 8 PRODUCT CONTENTS VSAW200/VSAW400 Power Cord RJ45 Network Cable 400W LED Light x 1pc x 1pc x 1pc Rope Hanger Hook x 2pcs x 2pcs...
-
Page 9: Smart Grow System
Control devices via Wi-Fi or Bluetooth Vivosun App GrowHub GrowHub E42A/E25 A10/A22 GrowHub easily monitors and Power devices remotely controls from a single screen via GrowHub’s smart plugs Connect Devices via GrowHub & Mobile App... -
Page 10: Spectrum
SPECTRUM The AeroLight Wing is spectrum-tunable and provides 3 spectral ranges for different growth stages (programmed via the GrowHub). VSA100/VSA150/VSAW200 SEEDLING SPECTRUM: More blue light promotes rooting and prevents overstretching. VEG SPECTRUM: Balanced spectrum for leaves growing. FLOWER SPECTRUM: Rich in 660nm red, 450nm blue and 730nm far-red light promote budding &... - Page 11 SPECTRUM VSAW400 SEEDLING SPECTRUM: More blue light promotes rooting and prevents overstretching. VEG SPECTRUM: Balanced spectrum for leaves growing. FLOWER SPECTRUM: Rich in 660nm red and 730nm far-red light promote budding & flowering; UV enhanced for better quality.
-
Page 12: Dimensions
DIMENSIONS VSA-100 4.5cm/1.8in 33cm/13.0in Top View Side View... - Page 13 DIMENSIONS VSA150 5.3cm/2.1in 33cm/13.0in Top View Side View...
- Page 14 DIMENSIONS VSAW200 66cm/26.0in Top View Side View...
- Page 15 DIMENSIONS VSAW400 5.6cm/2.2in 66cm/26.0in Top View Side View...
-
Page 16: Specifications
200W 400W Samsung 301B(VSAW400/301H EVO), 660nm Deep Red, LED Source 730nm Far Red, 450nm Blue, 395nm UVA Full Spectrum; 380nm-780nm, rich 660nm with FR and UVA Spectrum Spectrum tunable (Via GrowHub and VIVOSUN app) Light Light 120° Adjustable Distribution Dimming... -
Page 17: Installation
INSTALLATION INSTALLATION OPTIONS Option 1 Pass the rope hangers through the LED's hooks, and then fix the other end of rope hangers to the ceiling. Option 2 Remove the hooks from the LEDs, then fit them onto the ceiling bracket before installing them back onto the LED. - Page 18 INSTALLATION STEP 1 Attach the wire ropes to the frame of the AeroLight. Next, clip the carabiners of the rope hangers to the wire ropes.
- Page 19 INSTALLATION STEP 2 Loop the other end of the rope hangers around the crossbeam as shown in the diagram. Lock the carabiners to the rope to secure the grow light to the pole. STEP 3 Adjust the height of your grow light by pressing the buttons on the rope hangers and lifting until you find the correct height for your grown light .
- Page 20 INSTALLATION STEP 4 For VSAW200 & VSAW400, please unfold the light board and adjust to an appropriate angle.
- Page 21 INSTALLATION ADJUSTING THE LIGHT DISTRIBUTION Adjust the angle of the light board on the side to change the light distribution for larger coverage or higher light intensity for different grow stages. STANDARD Standard light coverage and uniformity. WIDTH Larger light coverage with more light for plants on the sides of your lights through improved coverage area.
- Page 22 E42(A) or E25 to control all the lights for dimming, spectrum tuning and ON/OFF cycle setting. Each light needs to connect the AC power separately and the GrowHub controller only needs to connect to an AeroLight to run. Please see the VIVOSUN GrowHub controller manual for information about light control and more.
-
Page 23: Application
APPLICATION SUGGESTED HANGING DISTANCE & SUGGESTED LIGHTING TIME Product Seedling Early Flower Late Flower PPFD Target 150-250 300-500 500-700 700-1000 Tent Size Time Distance 24" 18" 12" 12" VSA100 2'x2' Dimming 100% Level Distance 24" 18" 14" 14" VSA150 2'x2' Dimming 100% Level... -
Page 24: Warranty Information
WARRANTY INFORMATION VIVOSUN provides a 3-year warranty against defects on all AeroLight purchased directly from us or through our authorized dealers. This policy serves as our commitment to promptly address any manufacturing defects or premature breakage that may occur during normal use of our products. -
Page 25: Warning
WARNING ● This appliance can be used by children aged 8 years and above, as well as by individuals with reduced physical, sensory, or mental capabilities, or those lacking experience and knowledge, provided they have been supervised or instructed on the safe use of the appliance and understand the associated hazards. ●... - Page 26 AVERTISSEMENT ● L'appareil peut être utilisé par des enfants de 8 ans et plus, ainsi que par des personnes ayant des capacités physiques, sensorielles ou mentales réduites, ou un manque d'expérience et de connaissances, à condition qu'elles soient sous surveillance ou qu'elles aient reçu des instructions concernant l'utilisation sécurisée de l'appareil et qu'elles comprennent les dangers associés.
- Page 27 WARNUNG ● Das Gerät kann von Kindern ab 8 Jahren sowie von Personen mit eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten oder mangelnder Erfahrung und Wissen verwendet werden, sofern sie unter Aufsicht stehen oder Anweisungen zum sicheren Gebrauch des Geräts erhalten haben und die damit verbundenen Gefahren verstehen.
- Page 28 AVVERTENZA ● L'apparecchio può essere utilizzato da bambini di 8 anni e più, nonché da persone con capacità fisiche, sensoriali o mentali ridotte o mancanza di esperienza e conoscenza, se sono sotto supervisione o hanno ricevuto istruzioni sull'uso sicuro dell'apparecchio e comprendono i pericoli associati. ●...
- Page 29 ADVERTENCIA ● El aparato puede ser utilizado por niños de 8 años en adelante, así como por personas con capacidades físicas, sensoriales o mentales reducidas, o con falta de experiencia y conocimientos, siempre que estén bajo supervisión o hayan recibido instrucciones sobre el uso seguro del aparato y comprendan los riesgos involucrados. ●...
- Page 30 WAARSCHUWING ● Het apparaat kan worden gebruikt door kinderen van 8 jaar en ouder en door personen met verminderde fysieke, zintuiglijke of mentale capaciteiten, of gebrek aan ervaring en kennis, mits zij toezicht of instructies hebben ontvangen over het veilige gebruik van het apparaat en de bijbehorende risico's begrijpen. ●...
