  • Page 1 Grow Tent Kit USER MANUAL...
  • Page 2 PRODUCTS INCLUDED IN THIS MANUAL: Product Standard Grow Tent 2FTx2FT WEB-304113-42NJ VS1000 LED Grow Light WEB-LED-100NJ LED Protective Grow Room Glasses WEB-LED-100NJ 4-Inch 190CFM Inline Duct Fan WEB-306201P-4 4-Inch Carbon Filter WEB-306143-0412J 4-Inch 8 ft Ducting WEB-306104-48J 4-Inch Clamps WEB-306104-48J...
  • Page 3: Table Of Contents

    CONTENTS PRODUCT CONTENTS Product Contents Grow Tent Key Features Installation Specifications LED Grow Light Grow Tent VS Grow Light Inline Fan Key Features x 1pc x 1pc x 1pc Installation Specifications Application Inline Fan Installation Specifications 7-Day Digital Timer Carbon Filter Grow Room Glasses Ducting and Clamps Instructions...
  • Page 4: Key Features

    KEY FEATURES INSTALLATION Frame Poles & Ceiling Bars 1. High Light Reflectivity and Containment Professional-grade canvas designed with 600D Oxford nylon fabric that prevents light leaks and an interior 4 pcs. Mylar lining featuring our specialized ''lychee'' patterning that is more reflective than other patterns.
  • Page 5 INSTALLATION INSTALLATION STEP 1 STEP 3 Connect two Poles(A) and two Poles(D) to four Corner Supports(4) to form base Connect four Poles (C) to the Poles (B). frame of the tent. STEP 2 STEP 4 Connect four Poles (B) to the Corner Supports (4) of the tent base. Connect the other four Corner Supports (4) to the Poles (C).
  • Page 6 INSTALLATION INSTALLATION STEP 5 STEP 7 Connect two Poles(A) and two Poles(D) to four Corner Supports(4) to form base Pull the tent roof and cover on the top frame. frame of the tent. STEP 6 STEP 8 Unfold the Tent Coat(1) and put the base frame in the bottom of the Tent Put the Ceiling Bars (E, F) on the top frame for hanging devices.
  • Page 7 INSTALLATION SPECIFICATIONS STEP 9 Place the Floor Tray (2) into the tent. Dimensions 48" x 24" x 60" Weight 20.1 lbs. Warranty 1 Year Package Size 49.2'' x 9.6'' x 5.3'' Suggested Plant 2-4 plants in Suggested VS2000 Count 3 gallon pots Lighting Recommended 4'' Inline Fan...
  • Page 8 KEY FEATURES INSTALLATION 1. SAMSUNG LED Diodes Powered by Samsung high-efficiency diodes designed to provide the perfect spectrum for growing plants LED Grow Light Rope Hanger 2. High Efficacy x 1pc x 2pcs High-quality diodes and power supply mean high PPE, up to 2.7 umol/J. 3.
  • Page 9 INSTALLATION INSTALLATION CONNECTING MULTIPLE LIGHTS 1. Pass the rope hangers' carabiners through the hooks attached to the LED light fixture and then attach the other end of the rope hangers to the roof of the tent or the ceiling. Controlled Light Main Control Light Controlled Light 2.
  • Page 10: Specifications

    SPECIFICATIONS APPLICATION SUGGESTED HANGING DISTANCE & SUGGESTED LIGHTING TIME LED Source Samsung LM301D Frequency 50-60Hz Distance Stage Time Inch (In.) Centimeter (cm.) Input Voltage 120-277V Input Power 100W Germination 24-30 61-76 18 Hours ON Seeding 24-30 61-76 16 Hours ON >0.9 Power Factor Weight...
  • Page 11: Installation

    INSTALLATION INSTALLATION A. HANGING UPWARD STEP 4 Tuck the loose end through the center gap of the ladder lock to secure the loop. A.1 HANGING STRAPS STEP 1 Loop the two hanging straps around the flanges as shown in the diagram. STEP 5 Loop the other end of two hanging straps around a pole as showed in picture.
  • Page 12 INSTALLATION INSTALLATION A.2 ROPE HANGERS B. HANGING DOWNWARD B.1 HANGING STRAPS STEP 1 Loop the two rope hangers around the flanges as shown in the diagram. Lock the carabiners to the ropes to secure the fan. Loop the hanging straps around the pole and the flange brackets of the fan. Adjust and tighten the hanging straps, as show in part A.1, Steps 2-4.
  • Page 13: Specifications

    SPECIFICATIONS INSTRUCTION This timer has a built-in backup battery that saves the user's presets and programs. Diameter 4 Inch Voltage 120V The timer is designed for indoor use so please ensure that the timer stays dry and is kept away from water and moisture. Do not use the timer in temperatures above 131°F or below -14°F.
  • Page 14: Timer Setting

    TIMER SETTING TIMER SETTING 1. INITIAL SETTINGS c. Setting ''minute'' While pressing the ''CLOCK'' button, press the ''MIN'' button to Press Reset button ''R'' to reset the timer. The screen will turn blank and show reset display. adjust the current minute. For example, the current hour is Note: 08:30.
  • Page 15 TIMER SETTING TIMER SETTING Press the ''HOUR'' button and choose the working hour you Press the ''CLOCK'' button to exit the program setting and need. Long press the ''HOUR'' button (about 3 seconds) to return to the current time. change the hour number. NOTE: Press the ''PROG'' button repeatedly to review the program settings you have created.
  • Page 16 TIMER SETTING TIMER SETTING 5. DAYLIGHT SAVINGS TIME Random function setting: Check and ensure that the programs have been set correctly and the timer is set to This function allows the timer to adjust for daylight savings time automatically. AUTO mode. NOTE: If the timer is not in AUTO mode please set it according to section 4.
  • Page 17 TIMER SETTING TIMER SETTING 1. Setting a countdown: 3. Cancel countdown mode a. Long-press WEEK and DEL to enter the countdown setting. Keep press ''WEEK''and ''DEL'' to cancel the countdown mode at ''dOFF 00:00:00'' will be displayed on the screen. any time and display will back to current time.
  • Page 18: Equipment Setup

    EQUIPMENT SETUP EQUIPMENT SETUP Ducting Opening GROW TENT VENTILATION TYPICAL SETUP Inline fan and Carbon filter: Choose an appropriate Your grow tent has multiple duct openings and intake holes for ventilation. inline fan for your tent size. Hang the inline fan from the crossbars of your tent.
  • Page 19: Safety Information

    Please read the following information carefully before using. Failure to observe VIVOSUN will be free from defects in manufacturing for a period of one years from the date these safety instructions may result in serious injury and will release VIVOSUN of purchase.
