Summary of Contents for Vivosun Grow Tent Standard Series

  • Page 1 Grow Tent Standard Series USER MANUAL...
  • Page 2 PRODUCTS INCLUDED IN THIS MANUAL: Product Model Standard Grow Tent 2FTx2FT VST-S223 304113-21 Standard Grow Tent 2FTx2FT VST-S224 304113-22 Standard Grow Tent 2.7FTx2.7FT VST-S276 304113-27 Standard Grow Tent 2.5FTx1.5FT VST-S3018 304113-3018 Standard Grow Tent 3FTx1.7FT VST-S326 304113-32 Standard Grow Tent 3FTx3FT VST-S336 304113-33 Standard Grow Tent 4FTx2FT...
  • Page 3: Table Of Contents

    CONTENTS KEY FEATURES 1. Light-block & High-reflect Tent Coat Key Features Professional tent coat design with Product Contents 600D oxford nylon fabric exterior Specifications surface and high reflective mylar interior surface. Installation VST-S224/S276/S336/S448/S558/G336/G448/G558 2. Ducting Openings VST-S326/S425/S538/G425 Multiple ducting openings with adjustable size suitable for different VST-S223/S3018 sizes of ductings with no leak of...
  • Page 4: Product Contents

    PRODUCT CONTENTS PRODUCT CONTENTS VST-S224/S276/S336/G336 VST-S448/S558/G448/G558 Frame Poles & Ceiling Bars Frame Poles & Ceiling Bars 8 pcs. 8 pcs. 4 pcs. 4 pcs. 4 pcs. 4 pcs. 1 pc. 1 pc. 1 pc. 2 pcs. Tent Jacket Cover, 1 pc. Floor Tray, 1 pc.
  • Page 5 PRODUCT CONTENTS PRODUCT CONTENTS VST-S326/S425/G425 VST-S538 Frame Poles & Ceiling Bars Frame Poles & Ceiling Bars 4 pcs. 4 pcs. 4 pcs. 4 pcs. 4 pcs. 4 pcs. 4 pcs. 4 pcs. 1 pc. 1 pc. 1 pc. 2 pcs. Tent Jacket Cover, 1 pc.
  • Page 6 PRODUCT CONTENTS PRODUCT CONTENTS VST-S223 VST-S3018 Frame Poles & Ceiling Bars Frame Poles & Ceiling Bars 8 pcs. 4 pcs. 4 pcs. 4 pcs. 1 pc. 4 pcs. 1 pc. 1 pc. 1 pc. Tent Jacket Cover, 1 pc. Floor Tray, 1 pc. Tent Jacket Cover, 1 pc.
  • Page 7: Specifications

    SPECIFICATIONS SPECIFICATIONS VST-S224 VST-S276 VST-S336 VST-S448 VST-S558 VST-S326 Dimensions Dimensions 24"x24"x48" 32"x32"x63" 36"x36"x72" 48"x48"x80" 60"x60"x80" 36"x20"x63" (LxWxH) (LxWxH) Interior Material High-reflective Mylar Material Interior Material High-reflective Mylar Material Exterior Material Oxford Fabric Exterior Material Oxford Fabric Sealing Type Double-covered Zippers Sealing Type Double-covered Zippers View Window...
  • Page 8 SPECIFICATIONS SPECIFICATIONS VST-S425 VST-S538 VST-S223 VST-S3018 VST-G425 VST-G336 Dimensions Dimensions 48"x24"x60" 60"x32"x80" 24"x24"x36" 30"x18"x36" 48"x24"x60" 36"x36"x72" (LxWxH) (LxWxH) Interior Material High-reflective Mylar Material Interior Material High-reflective Mylar Material Exterior Material Oxford Fabric Exterior Material Oxford Fabric Sealing Type Double-covered Zippers Sealing Type Double-covered Zippers View Window...
  • Page 9: Installation

    SPECIFICATIONS INSTALLATION VST S224/S276/S336/S448/S558/G336/G448/G558 VST-G448 VST-G558 STEP 1 Connect four (A) Poles to four Corner Supports (4) to form the base frame of the Dimensions tent. 48"x48"x80" 60"x60"x80" (LxWxH) Interior Material High-reflective Mylar Material Exterior Material Oxford Fabric Sealing Type Double-covered Zippers View Window Front Window x1...
  • Page 10 INSTALLATION INSTALLATION STEP 3 STEP 5 Connect four (C) Poles to the (B) Poles. Connect the other four (A) Poles to the Corner Supports (4) to form the top frame of the tent. STEP 4 STEP 6 Mount the other four Corner Supports (4) to the (C) Poles as shown. Unzip and unfold the Tent Jacket Cover (1) and put the base frame in the bottom of the Tent Jacket Cover.
  • Page 11 INSTALLATION INSTALLATION STEP 7 STEP 9 Place the Floor Tray (2) into the tent. Pull up the tent roof and cover the top of the frame. STEP 8 STEP 10 Place the Ceiling Bars (E, F) on the top frame for hanging devices like lights and Pull the zippers to close the tent walls and door.
  • Page 12: Vst-S326/S425/S538/G425

    INSTALLATION INSTALLATION VST S326/S425/S538/G425 STEP 3 Connect four (C) Poles to the (B) Poles. STEP 1 Connect two (A) Poles and two (D) Poles to four Corner Supports (4) to form the base frame of the tent. STEP 2 STEP 4 Connect four (B) Poles to the Corner Supports (4) of the tent base.
  • Page 13 INSTALLATION INSTALLATION STEP 5 STEP 7 Connect two (A) Poles and two (D) Poles to the Corner Supports (4) to form the Pull up the tent roof and cover the top of the frame. top frame of the tent. STEP 6 STEP 8 Unzip and unfold the Tent Jacket Cover (1) and put the base frame in the bottom Place the Ceiling Bars (E, F) on the top frame for hanging devices like lights and...
  • Page 14: Vst-S223/S3018

    INSTALLATION INSTALLATION STEP 9 VST S223/S3018 Place the Floor Tray (2) into the tent. STEP 1 Connect four (A) Poles to four Corner Supports (4) to form the base frame of the tent. For the VST-S3018, connect two (A) Poles and two (B) Poles to four Corner Supports (4).
  • Page 15 INSTALLATION INSTALLATION STEP 3 STEP 5 Attach the other four Corner Supports (4) to the (B) Poles or (D) Poles as shown. Unzip and unfold the Tent Jacket Cover (1) and put the base frame in the bottom of the Tent Jacket Cover. *VST-S223 *VST-S3018 STEP 4...
  • Page 16 INSTALLATION INSTALLATION STEP 7 STEP 9 Place the Ceiling Bars (E, F) on the top frame for hanging devices. Pull the zippers to close the tent walls and door. Make sure the tent jacket cover fits the frame at the corners. *VST-S223 *VST-S3018 STEP 8...
  • Page 17: Equipment Setup

    EQUIPMENT SETUP EQUIPMENT SETUP Ducting Opening VENTILATION OF GROW TENT TYPICAL SETUP Inline Fan & Carbon Filter: Choose an appropriate The grow tent has multiple ducting openings and intake holes for ventilation. inline fan suitable for your grow tent. Hang the inline fan on the ceiliing bar of the tent and connect with AeroZesh Ducting Opening: Install a necessary ducting...
  • Page 18: Complete Your Setup

    - Compatible with GrowHub controller CONTROLLER CLIP ON CIRCULATION FAN GrowHub E42/E42A AeroWave - WiFi remotely control with VIVOSUN App - Patented clip-on design, easy to install - Complete control of lights, inline fans and - Automatical oscillation circulation fans - Fan speed adjustable - Temp./Humidity monitoring and control...
  • Page 19: Warranty

    GROW BAG The VIVOSUN warranty program is our commitment to you. That the product sold by VIVOSUN will be free from defects in manufacturing for a period of two years from the date - Different size of 1-30 gallons of purchase. If a product is found to have a defect in material or workmanship within one...
