- Page 1 Prestel 4K-PTZ1HC090X3 3X4K HDMI+USB Type-C HD PTZ Camera USER MANUAL...
-
Page 2: Table Of Contents
CONTENT CONTENT ......................1 SAFETY GUIDES .....................2 USE CHECK ..................... 4 PRODUCT HIGHLIGHTS ................6 CAMERA SPEC ....................7 INTERFACE DESCRIPTION ................9 CAMERA DIMENSION .................10 IR REMOTE CONTROLLER ................ 11 VISCA IN(RS232 PORT) ................13 VISCA PROTOCOL ..................14 PELCO-D PROTOCOL .................. 21 PELCO-P PROTOCOL ................... -
Page 3: Safety Guides
SAFETY GUIDES ● Before operation, please fully read and follow all instructions in the manual. For your safety, always keep this manual with the camera. ● The camera power voltage is 12V DC, rated currency is 2A. We suggest you use it with the original power supply adapter supplied by the factory. - Page 4 SAFETY GUIDES Attention！ ▲ The video quality may be affected by the specific frequencies of electromagnetic field. ▲ Never grasp the head of the camera, and never move the camera by hand when it is working, otherwise, mechanism maybe destroyed. Declaration：...
-
Page 5: Use Check
USE CHECK PACKING LIST Check all below items when open the package Camera ················································· 1PCS Power Adapter········································· 1PCS Power Cable··········································· 1PCS Remote Controller···································· 1PCS USB Type-C Cable····································1PCS RS232 Cable··········································· 1PCS User Manual··········································· 1PCS QC PASS··············································· 1PCS QUICK START — 4 —... - Page 6 USE CHECK Dial Switch Setting (at the bottom of the camera) Dial Switch (ARM) SW-1 SW-2 Instruction Upgrading mode Debugging mode Undefined Working mode Dial Switch SW-3 SW-4 Instruction Reserved Reserved Reserved Reserved Dial Switch SW-5 SW-6 Instruction Reserved Reserved Reserved Reserved —...
-
Page 7: Product Highlights
PRODUCT HIGHLIGHTS ★With the most advanced HD DSP, 1/2.8 inch 8.4 million image sensor. ★Ultra-high-quality 3x 92-degree wide-angle optical lens, to ensure the smooth and transparent UHD images. ★ Independent intellectual property rights of the focus algorithm, fast and accurate focus performance, to ensure that the image remains clear in the process of zooming, focusing process is fast and smooth. -
Page 8: Camera Spec
CAMERA SPEC 3X4K UHD PTZ Camera Sensor 1/2.8 inch high quality, 8.4 MP CMOS Sensor 3840*2160P30/25 1920*1080P60/50/30/25 HDMI 1920*1080I60/50 1280*720P60/50/30/25 MJPG： 3840*2160P30/25；1920*1080P30/25； Video Format 1280*960P30/25；1280*720P30/25； 1024*768P30/25；800*600P30/25；640*480P30/25； Type-C 320*240P30/25 YUY2： 640*480P30/25/20/15；320*240P30/25/20/15 Video Interface HDMI, USB Type-C Focal Length 3.3mm~9.7mm Aperture F2.0~3.7 View Angel 92°(Wide)~35.8°(Tele) Lens... - Page 9 CAMERA SPEC Supported Supported 2D Noise Supported Reduction 3D Noise Supported Reduction Anti-flicker OFF, 50Hz, 60Hz Pan Tilt Flip Supported Mirroring Supported Input Voltage DC 12V / USB 5V Dimension 148mm×132mm×162mm Net Weight 0.85kg(1.85LBS) Working -10℃~50℃ Temperature Working ≤80% Humidity —...
-
Page 10: Interface Description
INTERFACE DESCRIPTION 1.Camera Lens 5.Dial Switch 9.DC 12V plug 2.Camera Base 6.Tripod Screw Hole 10.RS232 port 3.IR Receiver Panel 7.Installation Hole 11.HDMI port 4.Power Indicator Light 8.Power Indicator 12.USB Type-C port — 9 —... -
Page 11: Camera Dimension
CAMERA DIMENSION — 10 —... -
Page 12: Ir Remote Controller
IR REMOTE CONTROLLER LED Function Instruction Press any button and shows in red color: Current selection is to control the camera; Press any button and shows in green color: Current selection is to control the codec; Press any button and shows in blue color: Current selection is to control the TV;... -
Page 13: Learning Function
IR REMOTE CONTROLLER LEARNING FUNCTION： 1. Press the green button, the LED indicator light will show in green color for 1 second, means switch to video terminal/codec control mode; 2. Single Button Coding: long press(3seconds) Home +number"1" button simultaneously, the green indicator LED will light, enter button learning mode, press the buttons which need to be learned, LED will start flickering(1HZ), now can start button learning: get the codec remote point to the camera remote’s infrared tube( about 10cm distance), then press the button which... -
Page 14: Visca In(Rs232 Port)
VISCA IN (RS232 PORT) Functions IR OUT Visca IN Mini DIN Connection VISCA IN DB9 Connection CameraVISCA IN Windows DB-9 Camera VISCA IN Mini DIN A(+) A(+) IR OUT IR OUT B(-) B(-) SERIAL PORT CONFIGURATION： Parameter Value Baud rate 2400/4800/9600/115200 Start bit 1bit... -
Page 15: Visca Protocol
VISCA PROTOCOL Part1 Camera Return Command Ack/Completion Message command Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. Error Messages command Note Returned when the command format is different or when a command Syntax Error z0 60 02 FF with illegal command parameters is accepted. - Page 16 VISCA PROTOCOL Command type function command Direct 8x 01 04 48 0p 0q 0r 0s FF pqrs: Focus Position Auto Focus 8x 01 04 38 02 FF Manual Focus 8x 01 04 38 03 FF One Push AF 8x 01 04 18 01 FF pqrs: Zoom Position 8x 01 04 47 0p 0q 0r 0s 0t 0u CAM_Zoom Focus...
- Page 17 VISCA PROTOCOL Command type function command 8x 01 04 3D 02 FF Exposure Compensation 8x 01 04 3D 03 FF ON/OFF CAM_WDR pq: ExpComp Position Direct 8x 01 04 D3 pq FF (0~0x6) 8x 01 04 33 02 FF BackLight On CAM_Back Light(BLC) 8x 01 04 33 03 FF BackLight Off...
- Page 18 VISCA PROTOCOL Command type function command pp: Video format 1080P60 0x00 1080P50 0x01 1080I60 0x02 1080I50 0x03 1080P30 0x04 1080P25 0x05 720P60 0x06 720P50 0x07 Video System 8x 01 06 35 00 pp FF 720P30 0x08 Set(Factory) 720P25 0x09 1080P59.94 0x0E 1080I59.94 0x0F...
- Page 19 VISCA PROTOCOL Command type function command Up right 8x 01 06 01 VV WW 02 01 FF Down Left 8x 01 06 01 VV WW 01 02 FF Down Right 8x 01 06 01 VV WW 02 02 FF Stop 8x 01 06 01 VV WW 03 03 FF Absolute 8x 01 06 02 VV WW 0Y 0Y...
- Page 20 VISCA PROTOCOL Command type command return note y0 50 00 FF Full Auto y0 50 03 FF Manual CAM_AE Mode Inq 8x 09 04 39 FF y0 50 0A FF Shutter priority y0 50 0B FF Iris priority y0 50 0D FF Bright p: 0: OFF CAM_Flicker Mode...
- Page 21 VISCA PROTOCOL VISCA PAN TILT ABSOLUTE POSITION VALUE PAN ANGLE VISCA value TILT ANGLE VISCA value -170 0xF670 0xFE50 -135 0xF868 0x0000 0xFAF0 0x01B0 0xFD78 0x0360 0x0000 0x510 0x0288 0x0510 0x0798 0x0990 VISCA PAN TILT SPEED VALUE Pan(Degree/Second) Tilt(Degree/Second) — 20 —...
-
Page 22: Pelco-D Protocol
PELCO-D PROTOCOL Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00 0x02 Pan Speed Tilt Speed... -
Page 23: Pelco-P Protocol
PELCO-P PROTOCOL Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 Tilt 0Xa0 Address 0x00 0x08 Pan Speed 0Xaf Speed Tilt Down 0Xa0 Address 0x00 0x10 Pan Speed 0Xaf Speed Tilt Left 0Xa0 Address 0x00 0x04 Pan Speed 0Xaf Speed Tilt Right 0Xa0... -
Page 24: Osd Menu
OSD MENU 1. Under working mode, press the MENU key on the IR remote controller, to enter the OSD menu as bellow: 2. After entering the main menu, use the navigate UP/DOWN key to select the main menu. Once selected, the main menu will change to blue background, and the right side will show sub-menu options. - Page 25 OSD MENU FOCUS MODE Optional: AUTO/MANU/PUSH Default: AUTO DZOOM Optional: OFF/ON Default: OFF RATIO DIS Optional: OFF/ON Default: OFF FOCUS ZOOM SPEED Optional: 1~7 Default: 5 RETURN Back to the main menu EXP. MODE AUTO, MANU, SHUT Default: AUTO Shutter speed: 1/30~1/10000, only valid SHUTTER Default: AUTO under MANU and SHUT mode...
- Page 26 OSD MENU D_WDR Optional: OFF/ON Default: OFF RETURN Back to the main menu 1080P60 1080P50 1080P30 1080P25 FORMAT 1080P60 1080P50 1080P30 1080P25 RETURN Back to the main menu CAM RESET Reset image parameter to default PTZ RESET Reset pan/tilt/zoom parameter to default RESET ALL RESET Reset all parameter to default...
-
Page 27: Uvc Control
UVC CONTROL 1. Only run the client software after the camera has completed self-configuration (the IR indicator in blue color and will not flash); otherwise may cause black video issue. 2. Make sure the camera is recognized by the PC Device Manager. 3.
