Prestel 4K-PTZ430HSU3N User Manual

4k uhd ptz camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Prestel 4K-PTZ430HSU3N
4K UHD PTZ Camera
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4K-PTZ430HSU3N and is the answer not in the manual?

Questions and answers

Related Manuals for Prestel 4K-PTZ430HSU3N

Summary of Contents for Prestel 4K-PTZ430HSU3N

  • Page 1 Prestel 4K-PTZ430HSU3N 4K UHD PTZ Camera USER MANUAL...

  • Page 2: Fcc Notice (Class A)

    Copyright All contents of this manual, whose copyright belongs to ourcorporation, cannot be cloned, copied or translated without the permission of our corporation. Notice Product specifications and information which were referred to in this document are for reference only. We may change, delete, or update any content at any time and without prior notice.

  • Page 3: Table Of Contents

    4K UHD PTZ Camera User Manual Catalogue Safety Precautions..................1 2 Packing List ....................1 3 Product Connection ..................1 4 Video Format ....................3 5 About Product ....................3 Features ........................ 3 Specifications ....................... 5 Interface and Switch ..................... 7 Dimension ......................
  • Page 4 4K UHD PTZ Camera User Manual 7.5.5 Noise ........................21 Audio Settings..................... 21 System Settings ....................21 7.7.1 Initialize ........................21 7.7.2 User ......................... 21 7.7.3 U Disk Record ......................21 7.7.4 Online Upgrade ....................... 22 Network Settings ....................22 7.8.1 Lan ...........................

  • Page 5: Safety Precautions

    4K UHD PTZ Camera User Manual  If the device emits smoke, smells, or Safety Precautions makes noises, please turn off the power immediately and unplug the  During the installation and use of the power cord, and contact the dealer in equipment, all electrical safety time.
  • Page 6 4K UHD PTZ Camera User Manual LINE IN LINE OUT SYSTEM IN RS232 OUT SELECT RS485 DC 12V USB2.0 USB3.0 3G-SDI HDMI RESTORE The schematic diagram is for reference only. Please refer to the actual application scenario for product connection. Note...

  • Page 7: Video Format

    4K UHD PTZ Camera User Manual 2) After the camera is powered on, it such as education, conferences and live starts to initialize, right up to the limit broadcasts. position, and then both horizontal and vertical go to the middle position, the motor stops running, and the initialization is completed.
  • Page 8 4K UHD PTZ Camera User Manual  NDI|HX2(Optional) function, which is convenient for NDI|HX2 has the characteristics of low engineering installation and use. delay and plug and play, which is convenient for project implementation and deployment. It has good ecology and supports the simultaneous transmission of audio, video and control commands.

  • Page 9: Specifications

    4K UHD PTZ Camera User Manual 5.2 Specifications PoE+ Support Preset Camera Position HDMI: 4KP60, 4KP50, Preset 0.1° 4KP30, 4KP25, Accuracy 4KP59.94, 4KP29.97, USB Features(USB 3.0 Optional) 1080P60, 1080P50, Operate Windows 7/8/10, Mac 1080P59.94, 1080P30, System OS X, Linux, Android 1080P29.97, 1080I60, Color 1080I50, 1080I59.94,...
  • Page 10 4K UHD PTZ Camera User Manual Audio 169mm x 188mm x Dimension Compression 226mm Audio Bit Net Weight About 2.3Kg 96K, 128K Rate NDI®|HX2, TCP/IP, Product specifications and Note HTTP, RTSP, RTMP(S), Protocols parameters are subject to change ONVIF, DHCP, SRT, without notice.

  • Page 11: Interface And Switch

    4K UHD PTZ Camera User Manual 5.3 Interface and Switch SYSTEM IN RS232 OUT LINE IN LINE OUT SELECT RS485 USB2.0 USB3.0 3G-SDI HDMI RESTORE DC 12V 10 11 13 14 Name LINE IN Interface LINE OUTInterface SYSTEM SELECT Switch RS485 Interface RS232 IN Interface RS232 OUT Interface...

  • Page 12: Installation

    4K UHD PTZ Camera User Manual Ø 100 1/4''-20UNC 4-M3 5.5 Installation Wall Mount Ceiling Mount The above installation diagram is for reference only, please refer to actual product for the installation accessories. Note...

  • Page 13: Remote Control

    4K UHD PTZ Camera User Manual 7. ZOOM Keys 5.6 Remote Control  SLOW: Zoom In [+] or Zoom Out [-] slowly  FAST: Zoom In [+] or Zoom Out [-] fast 8. L/R SET Key CAMERA SELECT  Standard: Simultaneously press [L/R SET] + [1] ...
  • Page 14 4K UHD PTZ Camera User Manual Successively press [*] + [#] + [9]: Quickly set up inversion Successively press [MANUAL]: Restore to default IP address...

  • Page 15: Gui Settings

    4K UHD PTZ Camera User Manual Backlight:On, Off (Effective only in Automode). GUI Settings Bright: 0~17 (Effective only in Bright mode). 6.1 MENU Press [MENU] key to display the main menu on the normal screen, using arrow key to move the cursor to the item to be set.

  • Page 16: Color

    4K UHD PTZ Camera User Manual Gain Limit:0~15 (Effective only in Auto, Color Temp: 2500K~8000K (Effective SAE, AAE, Bright mode). only in VAR mode). Anti-Flicker:Off, 50Hz, 60Hz (Effective only in Auto, AAE, Bright mode). Meter: Average, Center, Smart, Top (Effective only in Auto, SAE, AAE, Bright mode).

  • Page 17: Image

    4K UHD PTZ Camera User Manual AF-Sense:High, Low, Normal. 6.4 IMAGE L/R Set: STD, REV. Move the main menu cursor to [Image], Display Info:On, Off. and press [HOME] key enter the image Image Freeze:On, Off. page, as shown in the following figure. Digital Zoom:Off, 2x, 4x, 8x, 16x.

  • Page 18: Tracking Config

    4K UHD PTZ Camera User Manual Protocol:Auto, VISCA, PELCO-D, Video Mode:Press the [HOME] key to confirm enter the "Video Mode" page and PELCO-P. set SDI-3G Mode, Video Output. SDI-3G Mode: LEVEL-A, LEVEL-B. Video Output: HDMI, SDI. Other:Press the [HOME] key to confirm enter the "Other"...

  • Page 19: Restore Default

    4K UHD PTZ Camera User Manual V_Address:1~7(Effective only in Auto, 7.2 Control Camera VISCAprotocol). All pages include two menu bars: V_AddrFix:On, Off (When set to On, Real Time Monitoring: Video image useless in 88 30 01 FF Command). displaying with function buttons. P_D_Address: 0~254(Effective only in Parameter Setup: Parameter Auto,PELCO-D protocol).
  • Page 20 4K UHD PTZ Camera User Manual 1) Pan and Tilt Control The direction arrows and HOME button allow you to manually drive the camera to desired position. 2) Zoom Zoom In and Zoom Out buttons allow for wide or narrow view of the space. 3) Focus Focus In and Focus Out button allow for fine manual focus adjustment if the...

  • Page 21: Video Settings

    4K UHD PTZ Camera User Manual 7.3 Video Settings English 中文(简) Video Settings Русский Language HDMI/SDI Output HDMI Click either “Chinese”, “English” or Video Format Dial Priority “Russian” to change the language of the Encode Level mainprofile webpage. First Stream Encode Protocol H264 Resolution...

  • Page 22: Tracking Settings

    4K UHD PTZ Camera User Manual 6) Bit Rate 1) Auto Zoom/Auto Tilt The user can specify the bit rate. When Auto Zoom or Tilt is off, camera Generally speaking, the larger of the bit stops rate, the clearer of the image. However, zooming in/out or tilting automatically.

  • Page 23: Image Settings

    4K UHD PTZ Camera User Manual Tracking Start Area:Zone A, Zone B, 7.5 Image Settings Zone C, 7.5.1 Exposure Zone D. Exposure Color P/T/Z Noise Image Exposure Mode Auto ExpCompMode Backlight Anti-Flicker 50Hz Gain Limit Meter Average Submit Default 1) Exposure Mode Exposure Mode: Auto, Manual, SAE, AAE, Bright.

  • Page 24: Color

    4K UHD PTZ Camera User Manual 1) Luminance 7.5.2 Color Luminance: 0~14. 2) Contrast Contrast: 0~14. 3) Sharpness Sharpness: 0~11. 4) Flip-V Turn On/Off the Flip-V function. 5) Flip-H Color Exposure Image P /T/Z Noise Turn On/Off the Flip-H function. WB Mode Auto 6) B&W-Mode...

  • Page 25: Noise

    4K UHD PTZ Camera User Manual 7.5.5 Noise 7.7 System Settings 7.7.1 Initialize Reboot Reboot Factory Default Factory Default 1) Reboot Click “Reboot” to restart system. Noise Exposure Color Image P/T/Z 2) Factory Default Click the “Factory Default”, and the 3D NR “Please press OK to reset the camera.”...

  • Page 26: Online Upgrade

    4K UHD PTZ Camera User Manual 1) Record Settings 7.8.2 Port Set up the File Format and Packed Time. 2) USB Flash Disk Information HTTP Port View the Capacity and Free Space of the RTSP Port USB Flash Disk. TCP Port 5678 7.7.4 Online Upgrade 1259...

  • Page 27: Srtsettings

    4K UHD PTZ Camera User Manual two streams. 7.8.4 SRTSettings Click “Submit” and restart to take effect. SRT Mode Listener SRT Server 192.168.100.1 SRT Port 4578 SRT Encryption None SRT Password 1234564913131 SRT Bandwidth Overhead SRT Variable Latency SRT StreamId #!::u=admin Submit Cancel...

  • Page 28: Freed

    4K UHD PTZ Camera User Manual port of the first stream and 6690 is the 1) Stream multicast port of the second stream). Stream: First Stream, Second Stream. 2) Time Enable 7.8.8 FreeD Enable or disable the Time. 3) Title Enable FreeD Data Output(Beta) Enable or disable the Title.
  • Page 29 4K UHD PTZ Camera User Manual The operation steps are as follows: Step 1 Enter the current IP address, account, and password of the camera through the browser (see WEB Settings) to log in to the camera web interface. Step 2 Enter the “Tracking” option, select speaker mode “Presenter”, and set the tracking parameters in the “Track Off”...
  • Page 30 4K UHD PTZ Camera User Manual Step 3 We can consider how long the Target Retention Time will take, with a default of 6 seconds and a maximum of 10 seconds. Auto Zoom: Usually remains the default. When “Auto Zoom” is turned off, the camera lens can still move, but can only maintain the current magnification and cannot zoom.
  • Page 31 4K UHD PTZ Camera User Manual Step 4 Select the desired close-up effect.  Figure Size By selecting different modes, users can customize the proportion of characters in the close-up screen, which is a very important feature. The modification here takes effect immediately.
  • Page 32 4K UHD PTZ Camera User Manual Upper: The close-up image includes tracking the target above the knee, as shown in the following figure. Close: The close-up image includes tracking the target above the waist, as shown in the following figure.
  • Page 33 4K UHD PTZ Camera User Manual Custom: Adjust the tracking target proportion size. Note...
  • Page 34 4K UHD PTZ Camera User Manual If the proportion set is large, the proportion of the tracking target in the camera screen will also increase. When the tracking target moves rapidly, the camera may not keep up.  Tracking Start Position The user can choose the position of the camera lens when starting and stopping tracking.
  • Page 35 4K UHD PTZ Camera User Manual Step 5 According to the requirements of the application scenario, you can choose whether to require “Humanoid frame” and “Tracking hint”, with default modes. Used in live streaming scenarios, it is often not opened for temporary adjustments during live streaming.
  • Page 36 4K UHD PTZ Camera User Manual Humanoid frame: Default/Off/Debug Default: After turning on tracking, if there are multiple people in front of the camera and pressing the direction key to select the tracking target, this box will automatically appear. After pressing the HOME key to confirm tracking, this box will disappear and the camera will start tracking.
  • Page 37 4K UHD PTZ Camera User Manual Step 6 Turn on tracking, press the arrow keys to select the tracking target, and then press Home to confirm.  Area Tracking (Zone)
  • Page 38 4K UHD PTZ Camera User Manual Function: Divide the frequently active areas of the tracking target into several areas (A, B, C, D) as needed, and set corresponding preset positions and save them. When the tracking target enters this area, the camera will automatically call the preset position corresponding to the area to achieve tracking.
  • Page 39 4K UHD PTZ Camera User Manual  Tracking Start Area Tracking Start Area: You can select any Zone position as the tracking start or end position. When tracking is turned on, the camera will first move to this Zone position. If someone enters the video screen at this time, the camera will automatically track.

  • Page 40: Remote Control

    4K UHD PTZ Camera User Manual 8.2 Remote Control  Speaker Tracking (Presenter) The camera default is Speaker Tracking (Presenter), which allows you to check the current settings from the web interface. Function: This method can quickly achieve on/off tracking and select tracking targets. ...
  • Page 41 4K UHD PTZ Camera User Manual shown in the following figure, indicating that the tracking program has successfully started. Users can press F4 key to exit tracking mode.  Multi Person Scenario If there are multiple people in the scene, please first press the F3 key on the remote control to start tracking, if there are multiple people in front of the camera, you can press the left and right key on the remote control to select the target to track, and then press the HOME key to confirm.

  • Page 42: Troubleshooting

    4K UHD PTZ Camera User Manual Troubleshooting Image  The monitor shows no image 1) Ensure that the camera power supply is connected, the voltage is normal, and the power indicator is always on. 2) Turn off the power switch to check that the camera is self-testing. 3) Ensure the cable of video platform and TV that in correct connection.
  • Page 43 4K UHD PTZ Camera User Manual  Unable to access camera through the browser 1) Using PC to access the network to test that the network access can work properly to eliminate the network fault caused by cable and PC virus until the PC and camera can ping each other.
