- Page 1 09067-20.960.05 5600 SilentComfort Art. 9067 Art. 9068 6300 SilentComfort Operator‘s manual Pressure Tank Unit...
- Page 2 Art. 9090 Art. 9091...
- Page 3 Art. 1723 Art. 1724 min. 2,2 l A 7a min. 1,8 m...
-
Page 4: Table Of Contents
3.3.2 Connecting the suction hose [Fig. A9] ......................11 3.4 Connecting the hose to the pressure side ......................12 3.4.1 Connecting the pressure hose [Fig. A10] ....................12 3.4.2 Connect the pressure hose via the GARDENA combi system ..............13 3.4.3 Parallel connection of pressure hoses ......................13 3.5 Connecting the soil moisture sensor (optional) [Fig. A11]..................13 4 Commissioning ..........................14 4.1 Initial commissioning ............................ - Page 5 7 Messages on the screen ........................21 7.1 Status indicators ..............................21 7.2 Informative messages ............................22 7.3 On-screen messages related to Bluetooth®function: ................... 23 8 Settings .............................. 24 8.1 Timer ................................24 8.2 Mode (adjustable pressure ranges) ........................24 8.2.1 Mode selection ............................24 8.2.2 Individual mode ............................
-
Page 6: Terms And Abbreviations
1 TERMS AND ABBREVIATIONS • PTU: This abbreviation stands for pressure tank unit. This is the name for the entire device incl. pump unit and pressure tank. • Pump unit: Component mounted on the pressure tank that connects to the hose lines and pumps the water. -
Page 7: Safety Instructions
The use of this product by young people under the age of 16 is not recommended. The GARDENA PTU is intended for pumping ground and rainwater, tap water and chlorinated water in private gardens and allotments.The GARDENA PTUs 5600/6300 Bluetooth® Art. 9067/9068 are part of an irrigation system along with the Bluetooth®... -
Page 8: Additional Safety Instructions
￫ Always conduct a visual inspection of the PTU (especially the mains connection cable and mains plug) before use. A damaged PTU must not be used. It is essential to have the PTU checked by GARDENA Service if it is damaged. Electrical modifications may only be carried out by a qualified electrician. ￫ Disconnect the PTU from the mains before filling, removal or maintenance. - Page 9 2.3.2. Additional personal safety instructions DANGER! Risk of suffocation ￫ Small parts can easily be swallowed. ￫ Keep small children away when you assemble the product. DANGER! Risk of injury from hot water The pumped water is pressurised and can cause injury if it directly strikes the body or eyes. If there is no water supply on the suction side, the water in the PTU may heat up and the hot water produced could cause injury if leakage occurs.
-
Page 10: Assembly
3 ASSEMBLY DANGER! Risk of injury Risk of injury due to unintentional startup. ￫ Disconnect the plug from the mains socket. 3.1 Selecting the installation location • The surface must be low-vibration (e.g. do not place on metal sheets or plastic tanks) to ensure quiet operation. -
Page 11: Connecting The Suction Side
• Connect suction hoses !4 without a threaded connection to the connection on the suction side using a suction hose connection piece (for example Art. 1723/1724), ensuring it is airtight. 3.3.1 Types of connection systems Designed for a flat gasket: Including all GARDENA suction sets made of plastic. No thread sealing tape is required. Ensure that the flat gasket !G is inserted into the suction hose fitting and is undamaged. Designed for thread sealing tape: If you use different connections, use sealing tape on the male thread of the connections. -
Page 12: Connecting The Hose To The Pressure Side
Efficient use of the pumping capacity of the pump unit is achieved by con- necting: • 19 mm (3/4“) hoses in conjunction with the GARDENA pump connection set Art. 1752 or • 25 mm (1“) hoses with the GARDENA female quick thread coupling Art. 7109/quick coupling hose connector Art. 7103. Hold or fix the pressure hose vertically to prevent it kinking at the vertical pump outlet.Lay the hose flat on the ground and ensure that there are no U-shaped rises in it or coiled hoses. The best way of all- owing air to escape is for the pressure hose to be stretched out so that it runs upwards when viewed from the PTU. -
Page 13: Connect The Pressure Hose Via The Gardena Combi System
If more than two pressure hoses are connected in parallel, we recommend the use of: • e.g., the GARDENA 2-way or 4-way distributor Art. 8193/8194 or the GARDENA 2-way valve Art. 940.These can be screwed directly onto the connections on the pressure side !7. -
Page 14: Commissioning
4 COMMISSIONING 4.1 Initial commissioning 4.1.1 Commissioning the PTU for the first time ￫ Connect your PTU to the power supply. The Welcome screen starts. The Select language menu opens. 4.1.2 Selecting a language 1. To select a language, navigate with . 2. -
Page 15: Stopping The Pump Unit
If the pump is not pumping water after five minutes: 1. Let the pump unit cool down. 2. Look for possible causes in the error tables (see “11.2 Error messages”) and (see “11.3 Error table for the PTU”). 3. Restart the pump unit. 4.2.2 Stopping the pump unit To stop automatic mode, press the key. 4.2.3 Max. flow values The pump unit has a bypass valve to enable short suction times. -
Page 16: Functions
5.3 Power Boost The Powerboost function reliably detects high flow rates (e.g. in a sprinkler) and continues pumping despite reaching the switch-off pressure. After watering has been completed (including a follow-up time), the PTU returns to the previously selected pressure mode, provided that the demand is only for small flows (e.g. for toilet flushing or drip irrigation). 5.4 Bluetooth® The Bluetooth function offers you a convenient way to control your PTU using the GARDENA Blue- tooth® app. To do this, you must pair your PTU with your mobile device (Android® or iOS®) via Blue- tooth® (see “8.4 Bluetooth”). 5.5 Timers and watering schedules In addition to switching your PTU on and off manually, you can also switch it on and off using the timer function or watering schedules. Note that when the consumer unit is open, the pressure tank drains after the timer has expired or at... -
Page 17: Timer
5.6.1 Automatic restart In case of suction or dry running problems, an automatic restart takes place after 1, 5, 12 and finally every 24 hours. In the case of saved watering schedules, a restart takes place at the beginning of the next schedule. 5.7 Reminder Use the reminder function to remind yourself of the next filter cleaning based on operating hours and your own experience (local water pollution level). 5.8 Direct start With the “Direct start“ function, the PTU starts as soon as it is supplied with power. This func- tion is particularly suitable for operation with a timer or the GARDENA “smart Power adapter” (Art. 19095/19096). -
Page 18: Safety
5.9 Safety Your PTU has two optional safety options. 5.9.1 Leakage detection The leakage detection function can detect small leaks and thus prevent water loss. It ensures that your PTU is automatically stopped if a permanently low water flow is detected. This feature is disabled by default. 5.9.2 Maximum run time The function “Max. run time” limits the time of continuous water output by performing a safety switch- off, e.g. in the case of a burst garden hose. By using the “Max. run time” function, it is possible to defi- ne how long the PTU can draw water continuously. As soon as the set time is reached, the PTU auto- matically stops and thus effectively protects against increased water loss due to possible major leaks in the piping system. -
Page 19: Operation
6 OPERATION You can operate the GARDENA pressure tank units 5600 and 6300 via the device‘s own control panel or conveniently via the GARDENA Bluetooth® app in conjunction with a mobile device. 6.1 Operating the pressure tank unit via app The free GARDENA Bluetooth®... -
Page 20: Menu Navigation
6.2.3 Menu navigation ￫ To open the menu, select the icon by clicking the lower key 2,1 bar ￫ To navigate through the menu, select the icon by clicking the lower key Timer ￫ To open a menu item, click the middle key Timer ￫... -
Page 21: Messages On The Screen
7 MESSAGES ON THE SCREEN 7.1 Status indicators PTU in automatic mode - Pump unit currently started. 2,1 bar Automatic mode is switched off. 2,1 bar Water can be removed from the pressure tank. PTU in automatic mode - Pump unit is currently switched off until cut-in pressure is STANDBY 2,1 bar undershot due to water extraction. PTU ready for operation for a defined period of time - After the timer has expired, 99:00 min status switches to “OFF”... -
Page 22: Informative Messages
7.2 Informative messages These messages provide you with information about possible hazards for the PTU at an early stage. ￫ Look for the possible cause in the table below and resolve the problem. ￫ Close the message with . Message Possible cause Remedy Risk of frost... -
Page 23: On-Screen Messages Related To Bluetooth®Function
7.3 On-screen messages related to Bluetooth®function: Message Possible cause Remedy Soil moisture The measured soil moisture is higher ￫ If necessary, adjust the soil moisture too high than the previously set value. sensor setting. The watering cycle has been skipped. ￫... -
Page 24: Settings
8 SETTINGS The operation of the “Settings” menu is explained in chapter (see “6.2.3 Menu navigation”). 8.1 Timer ￫ Open the Timer menu to start or set the timer. The timer is factory set to 15 minutes by default. Timer 15 min ￫ Starting the timer ￫ Select to start the timer. After a 3-second countdown has elapsed, the PTU switches on. ￫... -
Page 25: Individual Mode
1. Open the “Power Boost” menu. POWER BOOST Power Boost 2. Use to switch the function on or off. 3. Confirm your selection with . The screen displays “Saved”. 8.4 Bluetooth To use the Bluetooth function, you will need the GARDENA Bluetooth® app (see “6.1 Operating the pressure tank unit via app”). 8.4.1 Switching Bluetooth on and off 1. Open the “Bluetooth” menu. ON/OFF Bluetooth 2. Use to switch the function on or off. 3. Confirm your selection with . -
Page 26: Pairing (Connecting A Mobile Device For The First Time)
3. Confirm your selection with . 03:00 Pairing Pairing. . . 4. You now have 3 minutes to connect your mobile device. 5. Follow the instructions in the GARDENA Bluetooth® app. Connection successful: The screen shows “Success”. Connection failed: The screen displays “Failed”. 6. Select to try pairing again. 7. Confirm your selection with . -
Page 27: Language
8.6 Language 1. Open the “Language” menu. Language deutsch english 2. Select to navigate between languages. 3. Confirm with to select a language. The screen displays “Saved”. Tip: Incorrect language selected If an incorrect language is selected, you can change this in the settings of your device within the GAR- DENA Bluetooth®... -
Page 28: Direct Start
8.8 Direct start If this function is switched on, the pump unit starts directly in automatic mode when the power is sup- plied. 1. Open the “Direct start” menu. DIRECT START Direct Start 2. Navigate with to perform the desired setting. 3. Confirm your selection with . The screen displays “Warning”. -
Page 29: Max. Run Time
8.9.2 Max. run time 1. Open the “Safety” menu. 2. Navigate to “Max. run time” with . Max. Leckage runtime 3. Confirm with . The current setting of your maximum run time opens. 4. Navigate with to perform the desired setting. 5. Confirm with . The screen displays “Saved”. Note: The function cannot provide guaranteed protection. 8.10 Factory settings 1. -
Page 30: Maintenance
9 MAINTENANCE DANGER! Risk of injury Risk of injury due to unintentional startup. ￫ Disconnect the plug from the mains socket. ￫ Make sure that all parts have been properly secured after maintenance. 9.1 Cleaning the pressure tank unit [Fig. M1] DANGER! Risk of injury and damage to property! Not cleaning the product properly can injure people and damage the product. -
Page 31: Cleaning The Filter [Fig. M2]
9.4 Cleaning the filter [Fig. M2] Depending on the level of water pollution, the filter should be cleaned at regular intervals, at the latest if it malfunctions. 1. Close all the shut-off valves on the suction side. 2. Open any shut-off valves in the delivery line (watering accessories, water stop etc.). 3. This causes the pressure side to depressurise. 4. Unscrew the fitting !8 on the filler neck !9 by hand (do not use any tools). 5. Pull the filter !13 vertically out of the filler neck !9. 6. Hold the cup !14 tight and turn the filter !13 anticlockwise out of the cup !14 (bayonet lock). 7. Rinse the cup !14 under running water. 8. Use e.g. a soft brush to clean the filter !13. 9. Reinstall the filter !13 in reverse order. 9.5 Cleaning the check valve [Fig. M3/M4] 1. -
Page 32: Storage
10 STORAGE CAUTION! Damage to the PTU due to frost ￫ Store the PTU in a frost-proof place. 10.1 Decommissioning and storage [Fig. S1] The product must be stored away from children. 1. Disconnect the plug from the mains socket. 2. Close any shut-off valves in the suction line. 3. -
Page 33: Troubleshooting
11 TROUBLESHOOTING DANGER! Risk of injury Risk of injury due to unintentional startup. ￫ Disconnect the plug from the mains socket. ￫ Allow the PTU to cool before troubleshooting. 11.1 Releasing the impeller [Fig. M3/T1] If the impeller has been blocked by contamination (pump unit hums), it can be released. 1. -
Page 34: Error Messages
WARNING Frost Hardware error There is an error with the hardware of the ￫ Disconnect the PTU from the power PTU. supply and contact GARDENA Ser- WARNING vice. Hardware error Error 0 The check valve is blocked or not instal- ￫... -
Page 35: Errors 1 And 2
11.2.2 Errors 1 and 2 WARNING WARNING Error 1 Error 2 Problem Possible cause Remedy Switch-off pressure cannot The suction depth is too great ￫ Select a lower switch-off be reached for the selected switch-off pres- pressure. sure. PTU does not suction ￫ Use a suction hose with backflow preventer (see “13 Accessories/spare parts”) or install a backflow preven-... -
Page 36: Error 10 And 11
Air cannot escape because the 1. Lay the pressure hose fully pressure hose is coiled up out straight. 2. Route the hose upwards from the pump outlet. 3. Do not kink the pressure hose at the pump outlet. 4. Open all consumers as much as possible. -
Page 37: Error Table For The Ptu
￫ Have the product checked damaged. by GARDENA Service. IMPORTANT! Repairs may only be carried out by GARDENA service centres or by specialist dealers approved by GARDENA. ￫ Please contact your GARDENA service centre in the event of other faults (see reverse). -
Page 38: Technical Data
12 TECHNICAL DATA Pressure tank unit Unit Value (Art. 9067) Value (Art. 9068) Rated power 1050 Mains voltage V (AC) Mains frequency Max. delivery capa- 5600 6300 city Max. pressure /Max. bar/m delivery head Max. self-priming level Working pressure (cut-in to cut-out pressure) Cut-in pressure Cut-out pressure Normal... -
Page 39: Accessories/Spare Parts
13 ACCESSORIES/SPARE PARTS GARDENA suction hoses Kink- and vacuum-resistant, available either by the metre Art. 1720/1721 (19 mm (3/4")/25 mm (1")) without connection fittings or in fixed lengths Art. 9090/9091 complete with connection fit- tings. GARDENA suction hose con- Art. 1723/1724 For connection on the suction nector) side. GARDENA pump connection Art. 1750/1752 For connection on the pressure side. -
Page 40: Service
14 SERVICE The current contact information for our service department can be found online: www.gardena.com/ contact... -
Page 41: Disposal
15 DISPOSAL 15.1 Disposal of the pressure tank unit (in accordance with Directive 2012/19/EU/S.I. 2013 No. 3113) The product must not be disposed of together with normal household waste. It must be dis- posed of in line with local environmental regulations. IMPORTANT! ￫... -
Page 42: Annex
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG, Inc. and any use of such marks by GARDENA is under licence. Apple and the Apple logo are trademarks of Apple Inc., registered in the United States and other countries. -
Page 43: Performance Characteristics
17 PERFORMANCE CHARACTERISTICS 5300 SilentComfort, Art. 9067 6300 SilentComfort, Art. 9068 max. max. 47 m 49 m max. 900 l/h 40 m max. 1.400 l/h 40 m max. 2.200 l/h 30 m max. 3.000 l/h 30 m max. 3.600 l/h 20 m max. - Page 44 Safra Highway (Beirut – Tripoli) Center Poland Spica Co. Ltd M.H. Al-Mahroos Husqvarna France 622 Mezher Bldg. Gardena Service Center Vrbno 243/2 Onnuch Rd., Prawat BUILDING 208, BLOCK 356, 9/11 Allée des pierres mayettes P.O.Box 215 c/o Husqvarna Manufacturing CZ...
