Model No. WECCSY99400
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-936-4266
Mon.–Fri., 8 a.m.–6:30 p.m. EST
(excluding holidays)
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
Serial
Number
Decal
®
USER'S MANUAL
fitness tips, and much more!
Patent Pending
Visit our website at
www.weiderfitness.com
new products, prizes,
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weider PRO 9940
Summary of Contents for Weider PRO 9940
- Page 1 ® Patent Pending Model No. WECCSY99400 USER’S MANUAL Serial No. The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.
-
Page 2: Table Of Contents
Table of Contents Important Precautions ..............2 Before You Begin . -
Page 3: Before You Begin
WEI- cardiovascular system, the WEIDER PRO 9940 PRO 9940 Home Gym (see the front cover of ® ® makes it easy to achieve the results you want. -
Page 4: Assembly
Assembly Note: This introduction will save you more time Identifying Parts than it takes to read it! To help you identify the small parts used in assem- bly, we have included a PART IDENTIFICATION CHART located in the center of this manual. Place Making Things Easier for Yourself the chart on the floor or work table and use it to Everything in this manual is designed to ensure... -
Page 5: Frame Assembly
Frame Assembly 1. Before beginning, make sure that you have read and understood the information on page 4. Locate and open the parts bag labeled “FRAME ASSEMBLY.” See drawing 1a. Press a 2” Square Inner Cap (28) into each end of the Butterfly Base (4). Press two 2” Square Inner Caps (28) into the Weight Base (5). - Page 6 3. Place the bracket on the lower end of the Butterfly Upright (1) over the indicated 5/16” x 2 1/2” Carriage Bolts (92) in the Butterfly Base (4). Hand tighten two 5/16” Nylon Locknuts (64) onto the Bolts. Do not tighten the Nylon Locknuts yet.
- Page 7 6. Press a 2” Square Inner Cap (28) half way into the top of the Front Leg (20). Press a 2” Square Inner Cap (28) into each end of the Small Leg Lever (41). Attach the Bumper (40) to the indicated hole in the Front Leg (20) with a 1”...
- Page 8 9. Press a 2” Square Inner Cap (28) into the Press Seat Frame (7). Slide the bracket on the Press Seat Frame (7) onto the indicated 5/16” x 2 1/2” Carriage Bolts (92) in the Press Base (6). Hand tighten two 5/16” Nylon Locknuts (64) onto the Bolts.
- Page 9 12. Place two Weight Bumpers (51) over the indicated holes in the Weight Base (5). Slide a Weight Guide (15) into each of the holes. Attach the indicated Weight Guide (15) to the Weight Base (5) with a 3/8” x 2 3/4” Bolt (46), two 3/8” Flat Washers (48), and a 3/8”...
-
Page 10: Arm Assembly
15. Attach each of the four Weight Guides (15) to the Weight Top Frame (66) with a 3/8” x 3 3/4” Bolt (59), a 3/8” Flat Washer (48), and a 3/8” Nylon Locknut (50). Important: Go back and fully tighten all Nylon Locknuts used in steps 1 through 15. -
Page 11: Cable Assembly
18. Press a 1 3/4” Square Inner Cap (35) into each end of the Right Butterfly Arm (11). Wet the lower end of the Arm with soapy water. Slide a Butterfly Foam Pad (29) onto the lower end of the Arm. Axle Lubricate the indicated axle on the Butterfly Top Frame (33). - Page 12 21. Remove both 3 1/2” Pulleys (24) from the pre-assem- bled Small Pulley Bracket (22). Wrap the Butterfly Cable (73) around a 3 1/2” Pulley (24) in the direction shown. Attach the Pulley to the Small Pulley Bracket (22) with a 3/8” x 1 3/4” Bolt (57) and a 3/8”...
- Page 13 25. Remove both 3 1/2” Pulleys (24) from the pre-assem- bled Adjustable Pulley Plates (23). Wrap the Ab Cable (74) around a 3 1/2” Pulley (24) in the direction shown. Attach the Pulley and a Cable Trap (25) to the top hole in the two Adjustable Pulley Plates (23) with a 3/8”...
- Page 14 28. Wrap the Ab Cable (74) around a 3 1/2” Pulley (24) in the direction shown. Slide the Pulley and a Cable Trap (25) onto the 3/8” x 3 1/2” Carriage Bolt (95) already inserted into the Butterfly Base (4). Secure the Pulley with a 3/8”...
- Page 15 31. Remove a Pro Pulley (26) from the bag marked Pulley Bag 2. Identify the Low Pulley Cable (75). It is approximately 143 1/2” long and it has a ball on one end and a loop on the other. Route the end with the loop through the slot in the cable guide on the Butterfly Base (4).
- Page 16 35. Attach the loop on the end of the Low Pulley Cable (75) to the indicated hole in the Small Leg Lever (41) with a 3/8” x 2 3/4” Bolt (46), two 3/8” Flat Washers (48), and a 3/8” Nylon Jamnut (63). 36.
- Page 17 39. Important: Although the following steps are not difficult to perform, the correct routing of the cable is critical to the functioning of the home gym. Please make sure that you wrap the cable around the pulleys exactly as shown in each step. Route the Press Cable (72) through the opening in the Press Frame (8), and wrap the Cable around a 3 1/2”...
- Page 18 43. Wrap the Press Cable (72) around a 3 1/2” Pulley (24) in the direction shown. Attach the Pulley and a Cable Trap (25) to the indicated hole on the far side of the Leg Press Lever (83) with a 3/8” x 4 3/4” Bolt (60) and a 3/8”...
- Page 19 47. Route the threaded end of the Press Cable (72) around the 3 1/2” Pulley (24) that was mounted on the bracket on the Weight Base (5) in an earlier step. 48. Wrap the Press Cable (72) over a 4 1/2” Pulley (82) in the direction shown.
-
Page 20: Seat Assembly
Seat Assembly 50. Locate and open the parts bag labeled “SEAT ASSEMBLY.” Attach the Backrest (12) to the indicated holes in the Butterfly Upright (1) with two 1/4” x 2 1/2” Bolts (79) and two 1/4” Flat Washers (71). 51. Insert a 1/4” x 2 1/2” Carriage Bolt (45) through the center hole in a Seat Plate (65). -
Page 21: Miscellaneous Assembly
52. Insert a 1/4” x 2 1/2” Carriage Bolt (45) through the center hole in a Seat Plate (65). Attach the Seat Plate to a Seat (13) with two 1/4” x 3/4” Bolts (49). Insert the 1/4” x 2 1/2” Carriage Bolt (45) into the indi- cated hole in the Butterfly Seat Frame (14) and secure it with a 1/4”... - Page 22 56. Apply the WEIDER PRO 9940 decal in the location shown. Important: The warning decals shown below have been attached to the home gym in the locations shown. If a decal is missing or illegible, please call our customer hotline at the number on the front cover of this manual to order a replacement decal.
-
Page 23: Cable Diagrams
Cable Diagrams The Cable Diagrams below and on the next page show the proper routing of the Butterfly Cable (73), the Ab Cable (74), the Low Pulley Cable (75) and the Press Cable (72). The numbers show the correct route for each Cable. - Page 24 Press Cable (72)
-
Page 25: Adjustment
Adjustment The instructions below describe how each part of the home gym can be adjusted. Refer to the exercise poster accompanying this manual to see how the home gym should be set up for each exercise. IMPORTANT: When using an attachment, make sure it is in the correct starting position for the exercise to be performed. If there is any slack in the cables or chain as an exercise is performed, the effectiveness of the exercise will be reduced. -
Page 26: Trouble-Shooting And Maintenance
To use the Curl Pad (105), remove the 2” Square Inner Cap (28) from the Front Leg (20) and insert the Curl Post (104) into the Front Leg. Secure the Curl Pad by inserting the Adjustment Knob (103) at the desired height. Trouble-shooting and Maintenance Inspect and tighten all parts each time you use the home gym. -
Page 27: Weight Resistance Chart
The threaded ends on the Press Cable (72) and the Ab Cable (74) that are attached to the weight stacks can also be used to tighten the cables. To tighten the Ab Cable (74), remove the “U”-Bracket (97) from the Short Weight Tube (17) by removing the 5/16” x 1 3/4”... -
Page 28: Ordering Replacement Parts
Friday, 8 a.m. until 6:30 p.m. EST (excluding holidays). When ordering parts, please be prepared to give the fol- lowing information: • The MODEL NUMBER of the product (WECCSY99400) • The NAME of the product (WEIDER PRO 99400) ® • The SERIAL NUMBER of the product (see the front cover of this manual) •... - Page 29 REMOVE THIS PART IDENTIFICATION CHART FROM THE MANUAL This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part. Important: Some parts may have been pre-assembled for shipping purposes.
- Page 30 3/4" Round Inner Cap (43) 1" Round Inner Cap (86) 1” Retainer Ring (31) 1" Round Inner Cap (76) 1" Square Inner Cap (98) 1" Round Outer Cap (38) 1 3/4" Square Inner Cap (35) 2" Square Inner Cap (28)
- Page 31 3/8" x 2 3/4" Bolt (46) 3/8" x 3" Bolt (88) 3/8" x 3 1/4" Bolt (62) 3/8" x 3 1/2" Bolt (56) 3/8" x 3 1/2" Carriage Bolt (95) 3/8" x 3 3/4" Bolt (59) 3/8" x 4" Bolt (78) 3/8"...
- Page 32 Part Identification Chart–Model No. WECCSY99400 R0700A 5/16" Nylon Locknut (64) 1/4" Nylon Locknut (68) 5/16" x 1 3/4" Bolt (96) 5/16" x 2 1/2" Bolt (87) 3/8" Nylon Locknut (50) 3/8" Nylon Jamnut (63) 5/16" x 2 1/2" Carriage Bolt (92) 1/4"...
- Page 33 REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL...
- Page 34 Part List—Model No. WECCSY99400 R0700A Key No. Qty. Description Key No. Qty. Description Butterfly Upright Leg Press Plate Press Upright 3/8” x 3 1/2” Bolt Support Frame 3/8” x 1 3/4” Bolt Butterfly Base Nylon Strap Weight Base 3/8” x 3 3/4” Bolt Press Base 3/8”...
- Page 35 Exploded Drawing—Model No. WECCSY99400 R0700A...
