Hyundai GIF27 AU100 Manual

Copy OEM Logo Here (→)
Electronic Installation Instructions
If this is a printed copy of the installation instructions, ensure you have the latest revision by
scanning the QR code or by entering the website address listed below before beginning installation.
Use the latest revision date as noted by "Rev. Date" above.
www.hyundaiaccessories.com/admin_media_uploads/installationSheets/gif27_au100.pdf
Application Notes
Instructional Symbols / Definitions
Denotes warnings that may lead to serious
physical injury or vehicle damage
Denotes cautions to be taken to avoid
physical injury or electronic component
damage
Denotes cautions to be taken to avoid
vehicle and component damage
Basic Required Tools
50/50 Isopropyl
Shampoo, Alcohol &
Alcohol (70%) &
Water
Water
(SLIP Mixture)
(Clean Solution)
Part Weight (Gross) FMVSS 110 Compliance Information
All dealers must determine if the Net weight they have added in the form of all options or accessories, when added to the weight of all Port/Dealer Installed
0.01
lbs
options or accessories, exceeds the lesser of 1.5% of GVWR or 100 lbs. If the additional weight does exceed the lesser of the indicated thresholds, a "Load
Carrying Capacity Reduced" label must be installed. A black, fine-point, indelible marker must be used to write by hand onto the label, the reduced carrying
0.005
kg
capacity in kilograms or pounds, which is the total weight of all added options and accessories.
Load Label Part Number: NP070 - 09003
Notes to the installer:
1) Read the entire Installation Instructions prior to beginning the installation of this accessory.
If applicable, scan the barcode label located on the accessory part or packaging prior to installing, to register the part. If this accessory is installed as a replacement, register the removal of
2)
the old part before registering the new part. Old and new parts will have different barcode data, and the old registration cannot be reused.
Make sure the vehicle is completely clean and dry in the area(s) the part is to be installed.
3)
4) Ensure the vehicle is properly protected in the area(s) that the accessory is to be installed.
NEVER place tools on painted surfaces, seating surfaces, dash pad, console or floor carpet/mats.
5)
6) Always wear appropriate personal protective equipment, including gloves, safety glasses, etc., when required.
Roll down the driver's window and adjust the power seats (if applicable) prior to disconnecting battery power, if needed.
7)
8) After installation, do not wash vehicle for 24 hours.
9) This product should be installed with proper installation tools.
10) Install this product while observing all warnings and precautions stated in the instructions.
Preparation Before Installation:
VERY IMPORTANT: Thoroughly wash vehicle with soap and water where accessory will be applied.
1)
2) VERY IMPORTANT: Sleeve must be installed on plastic/nylon Squeegee throughout the entire installation process.
VERY IMPORTANT: It is recommended that the ambient temperature of the accessory and the vehicle be between 65ºF and 90ºF at the time of installation and for 2 hours after.
3)
Parts storage should be flat at room temperature and in a clean dry place. Care should be taken to avoid a dusty environment.
4)
Place a large towel or pad on the ground to catch wetting mixture.
5)
Make sure you have a clean, flat table/work area to use.
6)
Genuine Accessories
Vehicle Model: Ioniq 5
Model Year 2022~
Part No. GIF27 AU100 (DIO)
GIF27 AU700 (PIO)
Language English
Rev. Date 7/12/2021
Does NOT Apply to Exterior Matte Color Painted Models
Denotes quality processes to be checked
prior to moving to the next step
Denotes specific tools that are necessary
to complete a step
N
O
Denotes important information to be
T reviewed during the step
E
Nylon Squeegee with
Microfiber Cloth
Sleeve
Revision Date
07/12/2021
Accessory: Applique, Charging Port
Difficulty: ( B )
Note: Difficulty stated above reflects the minimum level of
expertise required to install the accessory:
(A) Customer
(B) Dealer Technician
(C) Master Technician or Specialist
Denotes personal protective equipment (PPEs) that
may be required for a step. Examples of safety
equipment icons noted below:
Glasses
Mask Hearing Protection
Gloves
Page 1 of 5
