Summary of Contents for AEG KPK742280M
- Page 1 EN User Manual | Oven KPK742280B KPK742280M KPK742280T aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................7 4. CONTROL PANEL..................8 5. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. -
Page 4: Safety Instructions
• Always use oven gloves to remove or insert accessories or ovenware. • Use only the food sensor (core temperature sensor) recommended for this appliance. • To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. -
Page 5: Electrical Connection
2.2 Electrical connection 2.3 Use WARNING! WARNING! Risk of fire and electric shock. Risk of injury, burns and electric shock or explosion. • All electrical connections should be made by a qualified electrician. • Do not change the specification of this •... -
Page 6: Pyrolytic Cleaning
• Always cook with the appliance door • Read carefully all the instructions for closed. pyrolytic cleaning. • If the appliance is installed behind a • Keep children away from the appliance furniture panel (e.g. a door) make sure the while the pyrolytic cleaning operates. -
Page 7: Product Description
2.7 Service • Contact your municipal authority for information on how to dispose of the • To repair the appliance contact the appliance. Authorised Service Centre. • Disconnect the appliance from the mains • Use original spare parts only. supply. •... -
Page 8: Control Panel
Grill- / Roasting pan To bake and roast or as a pan to collect fat. Food Sensor To measure the temperature inside food. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. Menu Lists the appliance functions. -
Page 9: Before First Use
4.2 Display Display with key functions set. Time of Day START/STOP 12:30 Temperature 150°C Heating functions 85°C Timer Food Sensor (selected models only) START 15min Display indicators Basic indicators - to navigate on the display. To go one level To undo the last To confirm the selection / setting. -
Page 10: First Connection
5.2 First connection The display shows welcome message after the first connection. You have to set: Language, Display Brightness, Key Tones, Buzzer Volume, Time of Day. 6. DAILY USE WARNING! Refer to Safety chapters. 6.1 How to set: Heating functions Step 1 Turn on the oven. -
Page 11: Heating Functions
6.3 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to two shelf positions at the same time and to dry food. Set the temper‐ ature 20 - 40 °C lower than for Conventional Cooking. -
Page 12: Clock Functions
Heating function Application To dry sliced fruit, vegetables and mushrooms. Dehydrating To preheat plates for serving. Plate Warming To defrost food (vegetables and fruit). The defrosting time depends on the amount and size of the frozen food. Defrost For dishes such as lasagna or potato gratin. To make gratins and to brown. Au Gratin To prepare tender, succulent roasts. - Page 13 Clock function Application End Action To set what happens when the timer ends counting. Delayed start To postpone the start and / or end of cooking. Time Extension To extend cooking time. Reminder To set a countdown. Maximum is 23 h 59 min. This function has no effect on the operation of the appliance.
-
Page 14: Using The Accessories
How to delay start of cooking Step 5 Press: Delayed start. Step 6 Choose the value. Step 7 Press: . Repeat the action until the display shows the main screen. How to extend cooking time When 10% of cooking time is left and the food seems not to be ready, you can extend cooking time. You can also change the heating function. -
Page 15: Food Sensor
Baking tray / Deep pan: Push the tray between the guide bars of the shelf support. 8.2 Food Sensor Food Sensor - measures the temperature inside the food. You can use it with every heating function. There are two temperatures to be set: The oven temperature: minimum 120 °C. -
Page 16: Additional Functions
Step 4 Plug Food Sensor into the socket at the front of the oven. The display shows the current temperature of: Food Sensor. Step 5 - press to set the core temperature of the sensor. Step 6 - press to set the preferred option: •... -
Page 17: Function Lock
- press to reset the setting. - press to cancel the setting. 9.2 Function lock This function prevents an accidental change of the heating function. Step 1 Turn on the appliance. Step 2 Set a heating function. Step 3 - press at the same time to turn on the function. To turn off the function repeat step 3. -
Page 18: Moist Fan Baking
10.2 Moist Fan Baking Sweet rolls, 16 pieces baking tray or dripping 20 - 30 Swiss Roll baking tray or dripping 20 - 30 Sponge flan base flan base tin on wire shelf 25 - 35 Poached fish, 0.3 kg baking tray or dripping 15 - 25 Whole fish, 0.2 kg... -
Page 19: Care And Cleaning
1st side 2nd side 1st side 2nd side Burgers 9 - 13 8 - 10 Toast 2.5 - 3.5 2.5 - 3.5 11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. - Page 20 Step 1 Turn off the oven and wait until it is cold. Step 2 Pull the front of the shelf support away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove Step 4 Install the shelf supports in the oppo‐...
-
Page 21: Cleaning Reminder
11.4 Cleaning Reminder When the reminder appears, cleaning is recommended. Use the function: Pyrolytic Cleaning. 11.5 How to remove and install: CAUTION! Door Carefully handle the glass, especially You can remove the door and the internal around the edges of the front panel. The glass panels to clean it. -
Page 22: Troubleshooting
11.6 How to replace: Lamp WARNING! Risk of electric shock. The lamp can be hot. Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until the Disconnect the oven from the Put a cloth on the bottom of the cav‐ oven is cold. -
Page 23: Service Data
The appliance does not turn on or does not heat up Possible cause Remedy The fuse is blown. Make sure the fuse is the cause of the problem. If the problem recurs, contact a qualified electrician. The appliance Child Lock is on. Refer to "Menu"... -
Page 24: Energy Efficiency
13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name KPK742280B 944005023 Model identification KPK742280M 944004923 KPK742280T 944005024 Energy Efficiency Index 61.6 Energy efficiency class Energy consumption with a standard load, conventional mode 0.89 kWh/cycle... -
Page 25: Menu Structure
The fan and lamp continue to operate. When warm. The residual heat indicator or you turn off the appliance, the display shows temperature appears on the display. the residual heat. You can use that heat to Cooking with the lamp off keep the food warm. -
Page 26: Submenu For: Setup
Submenu Application Child Lock Prevents accidental activation of the appliance. When the option is on, the text Child Lock appears in the display when you turn on the appliance. To enable the appliance use, choose the code letters in the alphabetical order. When the option is on, and the appliance is turned off the appliance door is locked. -
Page 27: Environmental Concerns
Start using the appliance Quick start Turn on the appli‐ Step 1 Step 2 Step 3 ance and start cook‐ ing with the default Press and hold: - select the Press: temperature and preferred function. time of the function. Quick Off Turn off the appli‐... - Page 28 867370939-B-342023...
