SFP timing parameters for SFP management
Parameter
TX_DISABLE Assert time
TX_DISABLE Negate time
Time to initialize, including
reset of TX_FAULT
TX Fault Assert Time
TX_DISABLE to reset
LOS Assert Time
LOS Deassert Time
Serial ID Clock Rate
Notes:
Time from rising edge of TX_DISABLE to when the optical output falls below 10% of nominal
1)
Time from falling edge of TX_DISABLE to when the modulated optical output rises above 90% of
2)
nominal
From power on or negation of TX_Fault using TX Disable
3)
Time from fault to TX fault on.
4)
Time TX Disable must be held high to reset TX_Fault
5)
6) Time from LOS state to Rx LOS assert
7) Time from non-LOS state to Rx LOS deassert
