- Page 1 4K 5x1 Seamless Switcher with Multiview S h o w i n g t h e W o r l d SD-MV-0501P 4K 5X1 Seamless Switcher with Multiview VER 1.0...
-
Page 2: Table Of Contents
REMOTE CONTROL EDID AND HDCP HANDLE VIDEO AND AUDIO OUTPUT MULTIVIEW CONTROL SOFTWARE RS232 COMMANDS System commands Switching and Input commands Output commands Multiview commands Audio commands EDID command Video Keep Alive (VKA) command 4K-AUTO command Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 3: Features
4K 5x1 Seamless Switcher with Multiview Introduction SD-MV-0501P is a HDMI 2.0 and DP 1.2 Seamless Video Switcher with Multiview function. It supports 3x HDMI, 1x DP and 1x USB-C (video & Audio only) inputs, one HDMI and one HDBaseT video mirror outputs. -
Page 4: Connectors And Controls
HDMI 1, HDMI 2, HDMI 3, DP, USB-C Baud Rate: 9600, Data Bits:8, Parity: None Stop Bits:1 RS232 3 way 3.5mm phoenix connector TX means Switcher PC; RX means Switcher PC G means Ground 24V power adapter to plug in Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 5: Remote Control
1680x1050 4K60-5.1CH 1600x1200 4K60-7.1CH 1440x900 4K30-2.0CH 1360x768 4K30-5.1CH 1280x1024 4K30-7.1CH 1024x768 1080P60-2.0CH 720P 1080P60-5.1CH AUTO 1080P60-7.1CH USER 1920x1200 The switcher support 3 HDCP options at HDMI output: FORCE-1.4, FORCE-2.2, FORCE-OFF User can select it via RS232. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 6: Video And Audio Output
PBP, 3xWIN & 4xWIN: Inputs selection, Display Aspect Ratio selection, Layout Mode PIP: Inputs selection, Sub window size and position selection Multiview window distribution as following: User can do more layouts via RS232 or OSD menu navigation. It can save up to 20 preset layouts via RS232. Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 7: Control Software
Data Bits: 8 Stop Bit: 1 No Parity Note: Only Serial Port connection is supported. In ‘Output’ tab user can change the resolution, select VKA mode between Black Screen or Blue Screen, and Disable 4K Auto function. Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 8 Values for H and Y start position and H and Y size are the percentage of the Display Screen. You can only change the size and the position of Window 2. User can assign different video source to Window 1 and Window 2. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 9 Windows 1 by using ‘Display config’ boxes. • 3 x WIN In 3xWIN user can choose ‘Aspect’ ratio between full and 16:9. User can also select 1 of 4 modes for preset layouts of Windows 1 ,2 ,3. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 10 20 layouts. To save the layout type in the name in the designated box and choose the slot from the dropdown list. • Window/Source User can change the source on each Window by selecting right grid. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 11 4K 5x1 Seamless Switcher with Multiview In ‘Audio’ user can select an audio source, control the volume or Mute it. ‘System’ tab allows to select an EDID or upload customized Edid file. User can also change the Baudrate. Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 12: Rs232 Commands
3840x2160p60 4096x2160p60, 4096x2160p50, 3840x2160p60, SET OUT RESOLUTION w 3840x2160p50, 3840x2160p30, 3840x2160p25, 1920x1200p60RB, 1920x1080p60, 1920x1080p50, 1360x768p60, 1280x800p60, 1280x720p60, 1280x720p50, 1024x768p60，AUTO, USER GET OUT RESOLUTION Get current output resolution setting SET RESO-USER Width Set user defined output resolution Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 13: Multiview Commands
SET FREEZE-WINx w x is one of 1, 2, 3 ,4 or ALL, w is ON or OFF Get the freeze status of display window (x) GET FREEZE-WINx x is one of 1, 2, 3 ,4 or ALL Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 14 Get position and size of the USER PiP window Set the PBP display mode, default is mode 1 w is one of 1,2 or 3, SET PBP MODE w SET PBP ASPECT w Set the PBP window display aspect. default is FULL Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 15 Set the 3xWIN window display aspect ratio, default is FULL SET 3xWIN ASPECT w w is FULL or 16:9, GET 3xWIN ASPECT Get the 3xWIN window display aspect ratio Set the 4xWIN display mode, default is 1 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 16: Audio Commands
ON or OFF GET AUDIO-MUTE Get status of audio mute EDID command The following commands are used to set EDID mode for the inputs Commands Details SET IN EDIDMODE w Customize the inputs EDID, Default is 4K60-2.0 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 17: Video Keep Alive (Vka) Command
ON or OFF, default ON Example: SET OUT 4K-AUTO w Send: SET OUT 4K-AUTO ON Receive: OUT 4K-AUTO ON Get current OUT 4K-AUTO mode Example: GET OUT 4K-AUTO Send: GET OUT 4K-AUTO Receive: OUT 4K-AUTO ON Website: www.seada.co.uk E-mail: sales@seada.co.uk...
