- Page 1 SD-WP31C 3x1 Wallplate Transmitter Switcher with HDMI and USB-C S h o w i n g t h e W o r l d VER 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shook, lighting strikes, etc. -
Page 3: Product Introduction
24V PoC output. Firmware upgrade by Micro-USB port. 1.2 Package List ① 1x SD-WP31C ② 1x 2-pin Terminal Block ③ 2x 3-pin Terminal Blocks ④ 1x Power Adapter (24V 1.25A) ⑤ 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the components is found. -
Page 4: Specification
SD-WP31C-UK: 146mm x 86mm x 39mm Net Weight 230g Note: The SD-WP31C also can be powered from the HDBaseT receiver which supports 48V PoH. The CAT6A cable is recommended when the SEADA HDBaseT receiver is chosen to be used with the SD-WP31C wallplate transmitter switcher. -
Page 5: Panel Description
3. Panel Description 3.1 Front Panel SD-WP31C-EU SD-WP31C-UK ① IR: Built-in IR sensor for IR learning feature. It also supports IR pass-through to receive IR signal from IR remote to control display device ② HDMI IN 1: Type-A HDMI port to connect HDMI source. -
Page 6: Rear Panel
3.2 Rear Panel SD-WP31C-EU SD-WP31C-UK 2 3 4 2 3 4 ① HDBT (POC): RJ45 HDBaseT output port to connect to the HDBT IN port of the receiver by a CATx cable. It supports 24V-48V PoC to enable the switcher can be powered from a compatible receiver. -
Page 7: Side Panel
3.3 Side Panel SD-WP31C-EU SD-WP31C-UK ① FIRMWARE: Micro-USB port for firmware upgrade. Website: www.seada.co.uk 7 / 17 E-mail: sales@seada.co.uk... -
Page 8: System Connection
R S 2 3 2 D C IN IR IN HDBT OUT Power In Projector Laptop Blu-ray MacBook Projector Screen Note: We recommend CATx cabling with alien crosstalk prevention technology to ensure the performance of HDBaseT link. Website: www.seada.co.uk 8 / 17 E-mail: sales@seada.co.uk... -
Page 9: Button Control
2) If the incompatible display device needs to be used with this switcher, the DISPLAY ON/OFF button can be programed by IR learning or RS232 command. For more details, please refer to the 7 Button User-defined on the page 14. Website: www.seada.co.uk 9 / 17 E-mail: sales@seada.co.uk... -
Page 10: Rs232 Control
(e.g. projector) to the RS232 port of receiver. The connection diagram shown as below: S i g R S 2 3 2 D C IN IR IN HDBT OUT Power In Projector Laptop Website: www.seada.co.uk 10 / 17 E-mail: sales@seada.co.uk... -
Page 11: Rs232 Control Software
Uninstallation: Delete all the control software files in corresponding file path. ⚫ Basic Settings: Connect SD-WP31C with all input devices and output devices needed, then to connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. -
Page 12: Rs232 Command
4K@30Hz Dolby/DTS 5.1 EDID:4K30, DOLBY/DTS 5.1 50774% 1280x720@60Hz DVI EDID:1280x720@60, DVI 50775% 1920x1080@60Hz DVI EDID:1920x1080@60, DVI 50776% 1920x1200 PCM 2CH 6CH EDID:1920x1200, PCM 2CH 6CH 50777% 3840x2160@60Hz 4:2:0 8 bit EDID:3840x2160@60, 4:2:0 8BIT Website: www.seada.co.uk 12 / 17 E-mail: sales@seada.co.uk... -
Page 13: Cec Control
CEC VOLUME DECREASE 50732% Volume mute toggle. CEC VOLUME MUTE 50733% Display on. CEC DISPLAY ON 50734% Display off. CEC DISPLAY OFF Send CEC command “xx:xx:xx…” to control CEC <xx:xx:xx…> <xx:xx:xx..> display device. Website: www.seada.co.uk 13 / 17 E-mail: sales@seada.co.uk... -
Page 14: Button User-Defined
Press and hold the SOURCE AUTO button until the both the button LEDs go out to exit the IR learning mode. The switcher will enter auto switching mode five seconds later. Note: The IR learning function will self-terminate after 30 seconds of inactivity. Website: www.seada.co.uk 14 / 17 E-mail: sales@seada.co.uk... - Page 15 Baud rate is 38400 b=5, Baud rate is 57600 b=6, Baud rate is 115200 SET TIME TO xxx MINUTES /x0:xxx Set the booking shutdown time to xxx. TO TURN OFF THE DISPLAY IF NO SOURCE DETECTED Website: www.seada.co.uk 15 / 17 E-mail: sales@seada.co.uk...
-
Page 16: Panel Drawing
8. Panel Drawing 151.00 mm 70.00 mm 3.00 mm 39.10 mm 108.60 mm l o w e r l e ve l 3 9 .1 m m 2 6 .2 m m SD-WP31C-EU Website: www.seada.co.uk 16 / 17 E-mail: sales@seada.co.uk... - Page 17 146.00 mm 120.60 mm 3.00 mm 39.10 mm 108.63 mm l o w e r l e ve l 3 9 .1 m m 2 6 .2 m m SD-WP31C-UK Website: www.seada.co.uk 17 / 17 E-mail: sales@seada.co.uk...
