- Page 1 MS-HBT88B70 KIT HDBaseT™ 8×8 Matrix Switcher over CAT6/6a VER 1.0...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shook, lighting strikes, etc. -
Page 3: Introduction
⑤ 7x Phoenix connectors ⑥ 1x 100~240V AC 50/60Hz Power Cable ⑦ 16x Wideband IR receiver cables ⑧ 15x Wideband IR blaster cables ⑨ 12x Mounting Ears (Receiver) ⑩ 2x Mounting Ears (Matrix) 1x User Manual Website: www.seada.co.uk E-mail: sales@seada.co.uk 1/12... -
Page 4: Specifications
TX: 440mm(W)*320mm(D)*44.5mm(H) Dimensions RX: 115mm(W)*65mm(D)*17mm(H) Power Supply 100~240V AC 50/60Hz Power Consumption 74W Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Website: www.seada.co.uk E-mail: sales@seada.co.uk 2/12... -
Page 5: Operation Controls And Functions
IR receiver included can be inserted into the EXT port at the rear to extend the IR sensor range and enable local control of the matrix. Website: www.seada.co.uk E-mail: sales@seada.co.uk 3/12... -
Page 6: Remote Controller
④ Press the‘ALL’key to select all output firstly, then corresponding select only one input source. At this moment, The left and the right keys have no function. Website: www.seada.co.uk E-mail: sales@seada.co.uk 4/12... -
Page 7: Ir Control System
HDBT receiver output, the IR control will switch to following output select corresponding input source. Attention: The matrix has two location HDMI outputs. If the HDMI input source is switched to the two location HDMI outputs, the IR control will has no function. Website: www.seada.co.uk E-mail: sales@seada.co.uk 5/12... - Page 8 To control the display: Plug IR Receiver into IR IN port of transmitter unit; place receiver in position where it is able to receive remote signals. IR BLASTER IR RECEIVER Website: www.seada.co.uk E-mail: sales@seada.co.uk 6/12...
-
Page 9: Web Gui User Guide
Then select the “TCP Control Mode” port, click the “Search” button. At this moment, you can get current IP address. You can set the IP address to your PC/laptop/mobile Internet Explorer and click “Search” to enter Web GUI page. The Web GUI likes below: Website: www.seada.co.uk E-mail: sales@seada.co.uk 7/12... - Page 10 Close this switch, it will mute. ④ Click this button will reboot device. ⑤ Click this button will set to factory reset. Control page ① Select the input source to the output port. ② Select the output port audio. Website: www.seada.co.uk E-mail: sales@seada.co.uk 8/12...
- Page 11 EDID mode status. Status page ① Network Configuration ◆ In DHCP open status: HDCP switch: Obtian the network configuration information, including IP address, Subnet, Gate. Then click “Save Changes” button to save DHCP status. Website: www.seada.co.uk E-mail: sales@seada.co.uk 9/12...
- Page 12 Net Status button: Click this button will refresh current network configuration information to display in Status Log. In this unit, Mac address can check only, you can not set it. ② Display the network configuration information. Upgrade page ① Open upgrade file to upgrade. Website: www.seada.co.uk E-mail: sales@seada.co.uk 10/12...
-
Page 13: Hdbt Receiver
※Flashing: The Transmitter and Receiver are Indicator Lamp in poor connection status. ※Dark: The Transmitter and Receiver are not connected. ※Illuminate: The HDMI signal with HDCP. Data Signal ※Flashing: The HDMI signal without HDCP. Indicator Lamp ※Dark: No HDMI signal. Website: www.seada.co.uk E-mail: sales@seada.co.uk 11/12... -
Page 14: Application Example
10. Application Example Website: www.seada.co.uk E-mail: sales@seada.co.uk 12/12...
