F r i e d r i c h
Polymobil III
Maintenance Instructions
System
Polymobil III
The protocol RXB8-115.105.03.04.02 is required for
these instructions
Print No.:
RXB8-115.101.03.04.02
Replaces: RXB8-115.101.03.03.02
04564100
SP
2005
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 04.05
written

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Polymobil III and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens Polymobil III

  • Page 1 F r i e d r i c h Polymobil III Maintenance Instructions System Polymobil III The protocol RXB8-115.105.03.04.02 is required for these instructions 04564100 2005 © Siemens AG The reproduction, transmission or use of this document or its contents is not...
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.
  • Page 3: Table Of Contents

    Final work steps ............39 3 _______ Changes to Previous Version_____________________________________ 40 Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 3 of 40 Medical Solutions 04.05...
  • Page 4: General Information

    * Within the purview of DIN VDE 0751-1, we recommend documenting the results of the maintenance both in the maintenance protocol and in the TSC protocol. The protocols should be filled out completely and handed over to the client after maintenance is com- plete. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 4 of 40 04.05...
  • Page 5: Required Tools And Measurement Devices

    Tools Catalog). • Standard service tool kit * • Digital multimeter • 2-channel storage oscilloscope • Protective conductor meter • Device leakage current measuring device Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 5 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 6: Required Lubricant

    Required lubricant • Multi-purpose WD-40 spray 28 70 061 • Optimol Longtime PD2 grease (20 g) 34 91 271 or (1 kg) 73 95 445 Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 6 of 40 04.05 CS PS 24 Medical Solutions...
  • Page 7: Emphasized Text

    Fig. 1: Safety Notes Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 7 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 8: Safety Information And Protective Measures

    Release radiation for as short a time as possible. Checks during which radiation must be released are identified by the radiation warning symbol shown on the left. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 8 of 40 04.05 CS PS 24...
  • Page 9 The voltage decreases within approx. 1.5 minutes to approx. 12 V; the LED goes out. • Connect the POLYMOBIL III only to a power supply (wall outlet) the installation of which corresponds to the requirements according to VDE 0107 or the national regulations. •...
  • Page 10: Abbreviations

    The steps identified by these abbreviations are part of the maintenance certificate and should be checked off upon completion. NOTE The sequence for complete maintenance and inspection is de- scribed on the following pages. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 10 of 40 04.05...
  • Page 11: Protective Conductor Resistance Test Information

    DIN VDE 0751-1/2001-10, Fig. C2. Pos. 1 = System Pos. 2 = Application part type B (if available) Pos. 3 = Measurement setup (integrated into measuring device) Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 11 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 12 "Certificates" register in the system binder. If values are newly determined, they are to be recorded as first measured values. The evaluation is omitted in this case. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 12 of 40 04.05...
  • Page 13: Leakage Current Measurement Information

    (Fig. 3 / p. 14)) must be given preference, since this method is not dangerous to the person performing the measurement and other persons. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 13 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 14 If the direct measurement of the leakage current is used (measuring arrangement accord- ing to (Fig. 4 / p. 15)), the system must be set up to be insulated during the measurement and must not be touched. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 14 of 40 04.05...
  • Page 15 This is also to be documented. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 15 of 40 Medical Solutions 04.05...
  • Page 16 "Certificates" register in the system bind- er. If values are newly determined, they are to be recorded as first measured values. The evaluation is omitted in this case. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 16 of 40 04.05...
  • Page 17: Technical Safety Checks (Tsc)

    2.3 Are undamaged accessories being used? 2.4 System radiation protection devices 2.10 Radiation, checks: present and undamaged? (No on-site SIE Radiation indicator radiation shield) SIE Acoustic signal Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 17 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 18 3.3.1 Patient leakage current measure- ment 3.3.2 Equivalent patient leakage current measurement 4. Mechanical checks 4.1 Are all wall, ceiling and floor mount- ings secure and undamaged? Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 18 of 40 04.05 CS PS 24 Medical Solutions...
  • Page 19 (e.g. collision protection)? 5.5. Are all safety distances (wall, floor, ceiling) met or ensured by other appropri- ate measures (such as light barriers)? Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 19 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 20 Enter the results of the check. Have the operator, or a person authorized by the operator, sign the TSC report. Hand the TSC report over to the operator, or a person authorized by the operator. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 20 of 40 04.05...
  • Page 21: Check Screws

    Inspection and Maintenance Inspection and Maintenance Check screws • Make sure that they are secure and tighten them if necessary: Cassette holder Pedals Front wheels Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 21 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 22: Inspection And Maintenance

    Single tank holder Single tank Control handle over the control console NOTE If screws or securing elements are replaced, the screw locks must also be replaced. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 22 of 40 04.05 CS PS 24 Medical Solutions...
  • Page 23: Checking The Wheels

    Check the wheels for noises, freedom of motion, and wear of the rubber lining and re- place them if necessary (see the service instructions "Replacing the Steering Roller"). Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 23 of 40 Medical Solutions 04.05...
  • Page 24: Checking The Pedal Positions

    Straight travel • Pedal positions as (3/Fig. 1 / p. 24) The system can be moved forward and backward. The front wheels are used for steering. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 24 of 40 04.05 CS PS 24 Medical Solutions...
  • Page 25: Stand

    Ensure that there is play (without any friction) on all sides of the locking bar in the stand head (6/Fig. 2 / p. 25). Stand mounting • Ensure that the stand is secure. Spring counterbalance system Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 25 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 26 Spray the stand joints with multi-purpose WD-40 spray. • Lubricate the chains (4/Fig. 5 / p. 26) with Optimol Longtime PD2 grease. • Attach the stand cover (2/Fig. 4 / p. 26). Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 26 of 40 04.05 CS PS 24 Medical Solutions...
  • Page 27: Single Tank

    - Attach the clamp handle in the vertical position and tighten the screw (4/Fig. 6 / p. 27). - Recheck the locking mechanism of the single tank. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 27 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 28: Double-Slot Diaphragm

    (3/Fig. 7 / p. 28) (4/Fig. 8 / p. 28) on both sides. • POLYMOBIL OFF and disconnect the power plug. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 28 of 40 04.05 CS PS 24...
  • Page 29: Visual Inspection

    - Ensure that the holder is secure at points where the lines are subject to particular stress due to movement. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 29 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 30: Signs

    Customer documentation Customer documentation • The operating instructions must be available at the customer site. The operating instructions are to be checked for availability, completeness, and legibility. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 30 of 40 04.05 CS PS 24...
  • Page 31: Checking The Voltage Supplies

    +15 V at X3.5 and X3.6 (0 V) (tolerance: ±1 V). -15 V at X3.7 and X3.6 (0 V) (tolerance: ±1 V). • POLYMOBIL OFF and disconnect the power plug. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 31 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 32: Radiation

    Trigger exposure with preferred data 60 kV, 10 mAs. Fig. 10: kV and tube current • Connect the oscilloscope on D910 to MP "IRS" (TARGET), "IR" (ACTUAL) and "GROUND". Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 32 of 40 04.05 CS PS 24...
  • Page 33 Trigger exposure with preferred data 60 kV, 10 mAs. The radiation indicator (2/Fig. 12 / p. 33) must be lit during an exposure. An acoustic signal sounds at the same time. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 33 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 34 • Measure the deviations (X1, X2, Y1, Y2) between the edges of the light field and the edges of the radiation field on all four sides as shown in the diagram. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 34 of 40 04.05...
  • Page 35 In the case of deviations greater than 1.6 cm, see the "Coincidence of the Light Field and Radiation Field" chapter of the service in- structions. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 35 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 36: Control Console

    • Check the operating elements and displays on the control console. - See "Overview of the Operating Elements" in the operating instructions. • POLYMOBIL OFF and disconnect the power plug. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 36 of 40 04.05...
  • Page 37: Protective Conductor Test

    If values are newly determined, they are to be recorded as first measured values. The evaluation is omitted in this case. Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 37 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 38: Leakage Current Measurement

    "Certificates" register in the system bind- er. If values are newly determined, they are to be recorded as first measured values. The evaluation is omitted in this case. Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 38 of 40 04.05...
  • Page 39: Final Work Steps

    (for example, benzine, alcohol, spot remover) because of potential incompatibility with the material! Do not spray the POLYMOBIL! Never let cleaning agents get into the POLYMOBIL! Siemens AG RXB8-115.101.03.04.02 Polymobil III Page 39 of 40 Medical Solutions 04.05 CS PS 24...
  • Page 40 Inspection and Protective conductor test Completely rewritten maintenance Inspection and Leakage current measurement Completely rewritten maintenance Inspection and Final work steps "Disinfection" checkpoint deleted maintenance Polymobil III RXB8-115.101.03.04.02 Siemens AG Page 40 of 40 04.05 CS PS 24 Medical Solutions...
