Page 2
1. Important Safety Instructions SAVE THESE INSTRUCTIONS This manual contains instructions and warnings that should be followed during the installation, operation and storage of this product. Do not operate the UPS before reading all safety information and operating instructions thoroughly. Comply with all warnings and operating instructions. Failure to heed these warnings may affect the warranty.
Page 3
(Sealed Lead-Acid). Do not dispose of the batteries in a fire. Visit Tripp Lite at tripplite.com/products/battery-finder to locate the specific replacement battery for your UPS. Storage and Maintenance Before storing, charge the UPS 5 hours.
Page 4
2. Introduction This product is an intelligent line-interactive sine wave UPS, designed to protect your personal computer or sensitive electronic equipment from all forms of power interference, including complete power failure. 3. Package Contents • UPS Unit • USB Cable •...
Page 5
4. Product Overview 11 12 11 12 LCD Display Up / Down Button Mute Button On / Off Button USB Charger Ports for Device Charging (5V 3A, 1x USB-A, 1x USB-C) USB Communication Port for UPS Monitoring and Control Modem/Phone/Network Surge Protection Surge-Protected Outlets Battery Backup Outlets Master Battery Backup and...
Page 6
5. Installation Before installing the UPS, select a proper location to install the UPS. • Place the UPS on a flat and clean surface, away from vibration, dust, humidity, high temperature, flammable liquids and gases and corrosive and conductive contaminants. Install the UPS indoors in a clean environment, away from windows and doors.
Page 7
2. Press and hold the ON/OFF button for two seconds to turn on the UPS. A beep will sound when the UPS starts. 3. If the UPS still does not start, contact Tripp Lite Tech Support for assistance. HID Function (Optional) This UPS is equipped with HID functionality.
Page 8
5. Installation Remote panel operation The LCD panel can be removed from the base and placed in a location that is easier to view. Follow the steps below to remove the remote panel. The distance between the remote panel and the base cannot exceed 20 ft. (6 m). An NiMH battery is installed on the back of remote panel.
Page 9
Installation NOTE: If there is a power interruption while replacing the batteries, the load will not be backed up even if the UPS is on. To replace the batteries with UPS on, start with step 5. Follow the steps below to replace the battery. Step 1: Turn off all equipment plugged into the UPS system’s outlets.
Page 10
7. ECO Energy-Saving Setup The ECO energy-saving feature enables your UPS system to save energy by automatically turning off designated outlets when your computer is turned off or in Standby Mode. ECO Mode is disabled by default. Enabling ECO Mode 1.
Page 11
8. Operation LCD Panel Display Function Configuration and Fault Information Indicates the fault or warning codes. Mute Operation Indicates the UPS alarm is disabled. Input, Battery, Backup Time, Output and Load Information Indicate the input voltage, input frequency, battery voltage, battery capacity, backup time, output voltage, output frequency, load capacity, load percentage, NiMH battery, PC CPU speed, PC CPU temperature and PC CPU load percentage.
Page 12
8. Operation LCD Panel Display Function Battery Information Indicates the UPS battery level range: 0-24%, 25-49%, 50-74% and 75-100%. When the battery reaches low battery level, the “LOW BATT” icon will display. Indicates the NiMH battery level of remote LCD panel. NOTE: Except when in UPS fault condition, the LCD backlight automatically shuts off if there is no action for 1 minute (30 seconds when panel is removed from base).
Page 13
8. Operation LCD Setting Mode After pressing and holding the “Up/Down” button for 2 seconds, the unit will enter Setting Mode. Press the “Up/Down” button to select setting programs. Press the “On/Off” button to enter the selectable options page. Press the “On/Off” button again to access selectable options.
Page 14
8. Operation Program Description Selectable option Brightness of RGB Normal LED Bottom Bank High (default) Scrolling Speed Normal (default) for RGB LED Front Bank High Scrolling Speed Normal (default) for RGB LED Bottom Bank High RGB LED Front Power bar Power color shift Bank Effects Power fade...
Page 15
8. Operation Program Description Selectable option RGB LED Bottom Power fade Solid(default) Bank Effects Breath Spectrum cycling Color1 RGB LED Orange (default) Front Bank Yellow Green Aqua Blue Purple White Others Color2 RGB LED Orange Front Bank Yellow (default) Green Aqua Blue Purple...
Page 16
8. Operation Program Description Selectable option Color1 RGB LED Orange (default) Bottom Bank Yellow Green Aqua Blue Purple White Others Color2 RGB LED Orange Bottom Bank Yellow (default) Green Aqua Blue Purple White Others On-Off Eco Mode Eco Mode On Eco Mode Off (default)
Page 17
8. Operation Display Setting The LCD information will be switched in turns by pressing the “Up/Down” button. The selectable information is switched in this order: input voltage, input frequency, battery voltage, battery capacity, estimated backup time, output voltage, output frequency, output in kW, output load percentage, master outlet power consumption, PC CPU frequency, PC CPU temperature, CPU utilization, panel board firmware version, base board firmware version and UPS control board firmware version.
Page 18
8. Operation Selectable Information LCD Screen Output Frequency Output in kW Output Load in Percent Master Outlet Power Consumption PC CPU Frequency PC CPU Temperature...
Page 19
8. Operation Selectable Information LCD Screen CPU Utilization Panel Board Firmware Version Base Board Firmware Version UPS Control Board Firmware Version...
Page 20
9. Trouble Shooting When there is a fault, error, warning, or alarm, both the front and bottom LED banks will flash red. If the UPS system does not operate correctly, use the following table to identify the problem. Problem/Fault code Possible Cause/Fault Event Solutions UPS will not turn on after...
Page 21
10. Specifications Model SMART600PSGLCD SMART1000PSGLCD Capacity 600 VA / 360 W 1000 VA / 600 W Input Voltage 110/120 VAC Input Voltage Range 97~145 VAC Output Voltage Regulation +/-10% Transfer Time Typical 6 ms, 10 ms max. Waveform Pure Sine Wave Battery Type &...
Page 22
Any damages (direct, indirect, special or consequential) to the product incurred during shipment to Tripp Lite or an authorized Tripp Lite service center is not covered under warranty. Products shipped to Tripp Lite or an authorized Tripp Lite service center must have transportation charges prepaid.
Page 23
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment.
Page 24
Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information.
