Summary of Contents for Pureline PL1510
- Page 2 PURELINE Sand Filter Pump System SAFETY INFORMATION PL1510 1. The sand filters are designed to work with water at temperatures > than 32F (0℃) and < than 113F (45℃). The filter should never be operated outside of these temperatures, or damage may occur.
- Page 3 How to install the filter tank 1. Mount the pump to sand filter support by using bolts and nuts. 2. Install the drain plug assembly as shown below. Place the tank onto the sand filter support in the correct direction (the drain plug is outside, as shown below). 3.
-
Page 4: Installation Notes
5. Connect the sand tank to the pump with the pump hose, hose clamps, and hose adapters. INSTALLATION NOTES: 1. Make sure the filter is working under the work pressure. A pressure control valve is needed when the pool system uses a booster pump. 2. - Page 5 4. Once water flow is steady out the waste line, run the pump for at least 2 minutes. The initial back-washing of the filer is recommended to remove any impurities of fine sand particles in the sand media. 5. Turn the pump off and set the valve to RINSE. Start the pump and operate until the water in the sight glass is clear (about 1/2 to 1 minute).
- Page 6 Parts Listing Description Quantity 4-way valve Clamp assembly O ring Filter tank Filter assembly Drain plug 1/4” (32mm)x35cm hose Hose clamp Hose adapter Hose adapter o-ring 0.35HP pump Screw M6X25 and nut M6 Sand filter support Gauge assembly Drain plug w/o-ring...
- Page 7 TROUBLESHOOTING AND TECHNICAL SERVICE This filter and its instructions are designed for residential use, with no need for professional supervision, except for exceptional cases. Here are some common problems and causes that may arise after years of service that you can diagnose and repair yourself. If you cannot solve the problem, contact our customer service team for assistance at 407-834-2200.
