ROCAM 4 Plus
DE Bedienungsanleitung
EN Instructions for use
FR Instruction d'utilisation
ES Instrucciones de uso
IT Istruzioni d'uso
NL Gebruiksaanwijzing
DA Brugsanvisning
SV Bruksanvisning
FI Käyttöohje
PL Instrukcja obsługi
CS Návod k používání
TR Kullanim kilavuzu
HU Kezelési útmutató
ET Kasutusjuhend läbi
LT Naudojimo instrukciją
LV Lietošanas pamācība
RU Инструкция по использованию
JA
マニュアル
rothenberger.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rothenberger ROCAM 4 Plus
Summary of Contents for Rothenberger ROCAM 4 Plus
- Page 1 ROCAM 4 Plus DE Bedienungsanleitung PL Instrukcja obsługi EN Instructions for use CS Návod k používání FR Instruction d’utilisation TR Kullanim kilavuzu ES Instrucciones de uso HU Kezelési útmutató IT Istruzioni d’uso ET Kasutusjuhend läbi NL Gebruiksaanwijzing LT Naudojimo instrukciją...
- Page 2 User interface start up screen ................... 27 Picture / Video mode ......................28 User interface operating elements ..................29 4.9.1 Using the ROCAM 4 Plus app ..................32 4.9.2 Data transmission to a PC ....................33 4.10 Replace the reel (B) ......................33 4.11...
- Page 3 Intended use ROCAM 4 Plus: The ROCAM 4 Plus TV inspection system is solely for inspecting empty, clean pipes, hollow cavities and hollow spaces, as indicated under Technical data. Other uses are discouraged. Do not leave camera heads in the sun for extended periods. This can damage the camera mod- ule! All applicable standards and regulations must be observed.
- Page 4 General Power Tool Safety Warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious inju- Save all warnings and instructions for future reference. The term “power tool”...
- Page 5 g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust- related hazards. h) Do not let familiarity gained from frequent use of tools allow you to become compla- cent and ignore tool safety principles.
- Page 6 Never service damaged batteries. All maintenance of batteries should only be carried out by the manufacturer or authorised customer service points. Special safety instructions ROCAM 4 Plus: Wear proper work clothes, work gloves, safety glasses and safety shoes. Do not perform any work inside the device! Only trained technical personnel (customer service)
- Page 7 Please also observe possibly more detailed national regulations. Technical data ROCAM 4 Plus Battery voltage ........ 18 V DC Rated power consumption ....16 W Working temperature ......
- Page 8 Positioning transmitter ....33 kHz (bolt-on optional) Protection class camera head ..IP 68 Included in delivery: ROCAM 4 Plus TV- inspection system with Camera head ø30 mm or ø40 mm, guide ball, positioning transmitter 33 kHz, USB cable, test adaptor, manual, 4 GB SD card, battery and charger.
- Page 9 Caution: Check for cleanliness and damage! If necessary, additional accessories can be attached to camera. When using pipe diameters greater than 70 mm, always use guide body! Clean the pipe system before inspection. Press button on the bottom cover (6), open the cover. Hold the door during opening. ...
- Page 10 Monitor unit with touchscreen The ROCAM 4 Plus comes with a 4GB SD card to save photo's and video's. This can be removed for data transfer. Connections Micro-HDMI, mini USB and SD card are on the side of the monitor unit.
- Page 11 (-10° to 50°C) If the ROCAM 4 Plus is used outside the specified operating temperature range, faults can occur on the screen! The ROCAM 4 Plus may switch itself off autonomously! Picture / Video mode ...
- Page 12 Touch arrow (or) circle / touch delete button to remove arrow (or) circle File Naming / Text Annotation Folder Name Will Appear in the Top Tool Bar (Don’t use special characters) Done button saves title Delete pictures. Confirm yes or no / back Delete audio file from saved pictures.
- Page 13 Select from 5 different brightness levels for optimum viewing Format / Wipe (4G) SD Card: Formatting will erase all saved images and/or video only in folder ROCAM 4 Plus on SD card. Not other Saved Data! Confirm with yes or...
- Page 14 • Download to transmit data to a smartphone/tablet App in iOS/App Sore or Android/Play Store (for use of the app see 4.9.1). Language Selection: Following languages are available: DE, EN, ES, FR, IT, NL, PT, DA, SV, FI, PL, CS, TR, HU, SLO, RU, BG, GRI, RU, CHI, JA, AR, HI Unit of Measure: Choose between „meter ”...
- Page 15 Using the settings of the Android/ iOS device, connect with the network “rocam4_hotspot“. The password for this is: “letrocam4in“. After making the configuration, leave the system settings of ROCAM 4 Plus and switch to Livebild. Open the app on the Android/ iOS device. This image appears...
- Page 16 Switch on the wifi function on the PC and connect with the wireless network “roc- am4_hotspot“. The network security key required to make the connection is: “letrocam4in“. Open the respective browser on the PC and enter the IP address of the ROCAM 4 Plus http://192.168.5.1.
- Page 17 4.11 Charger and battery Overview: Battery pack Warning display Sliding seat Capacity indicator button Operation display Capacity and signal indicator Start of operation Before plugging in, check to see that the rated mains voltage and mains frequency, as specified on the rating label, match your power supply! Devices such as this one, which generate direct current, may have an effect on basic residual- current circuit breakers.
- Page 18 Close the cover and press until it clicks. Take off the reel (8) from the ROCAM 4 Plus (see section 4.10) and clean under running wa- ter. Only clean the reel when removed from device.
