Teac CD-552E Specifications

52X CD-ROM Drive
Internal IDE Drive for Windows
• 7.8MBps Max. Data Transfer Rate
• 120ms Average Access Time
• Equipped with 128KB Data Buffer
• Available with White or Black Bezel
• Utilizes IDE/ATAPI Interface
• Windows Plug and Play Compatible
•
Rugged Design for High Reliability
•
Reads MultiRead/CD-RW Discs
The TEAC CD-552E 52X Max. CD-ROM drive provides unbeatable
performance and reliability. It features a maximum 7.8MB per
second data transfer rate that delivers smooth multimedia playback.
It spins at a Constant Angular Velocity (CAV) which optimizes
the drive's data transfer rate by rotating the disc at a consistent
speed. Combine it's fast data throughput with a quick 120ms
average access time and you have a drive with unsurpassed
CD-ROM performance.
Whether you're playing video clips, listening to music, or installing
new software, the TEAC 52X fits the bill. It reads all major CD
formats and a few others including Video CD, CD Plus and Photo
CD. In addition, the drive supports both standard 12cm and mini
8cm CDs and reads both CD-R and CD-RW media.
The CD-552E is available in a choice of black or white. Install it
horizontally or vertically, in either direction. It utilizes an IDE/ATAPI
interface, which provides the easiest integration available. And like all
TEAC drives, its rugged design is rock solid and designed for many
years of dependable use.
© 2002 TEAC America, Inc. All rights reserved. All trademarks and registered trademarks mentioned herein are the property of their respective companies. TRG85043/3-02/5K
TEAC America, Inc., 7733 Telegraph Road, Montebello, CA 90640. Phone 323.726.0303, Fax 323.727.7652
52X CD-ROM
Model:
Interface:
Data Transfer Rate:
Digital Audio Extraction:
Average Access Time:
Data Buffer Size:
Disc Types:
Disc Size:
Bezel Color:
Mounting Orientation:
Disc Loading:
Front Panel:
Power Requirement:
Headphone Jack:
Safety Standards:
MTBF:
Dimensions:
Weight:
Available with black or white (light gray) bezel.
www.teac.com
Specifications
CD-552E
IDE/ATAPI
3,450 KBps (23X) to
7,800 KBps (52X) CAV
3,450 KBps (23X) to
7,800 KBps (52X) CAV
120 msec (1/3 Stroke)
128KB
Audio CD; CD-ROM Mode-1;
Mode-2; CD-XA Mode-2; (Form1,
Form2); Video CD; CD Extra/CD-Plus;
UDF; CD-I; Mode-2 (Form1, Form2);
i-Trax; Photo CD (Single, Multisession);
CD-R; CD-RW (MultiRead)
12cm and 8cm
Choice of White (Light Gray) and Black
Horizontal and Vertical
(in Both Directions)
Motorized Loading Tray
Built-in Headphone Jack, Volume
Control Knob, Play Button, Power Disc
Eject/Load Button and LED Indicator
+12V DC and 5V DC
3.5mm Diameter Stereo Jack
UL, CSA, TUV
25,000 POH
5.86¨(W) x 1.69¨(H) x 7.53¨(D)
1.98 lbs
