Page 3: Table Of Contents
Professional tips Specifications Welcome to DLS! Dimensions Thank you for buying a DLS Reference ACW68I active slim subwoofer. For us, it’s all about the sound Product markings experience. We care deeply about sound and construction quality. In order for your experience to... -
Page 4: Features
2. Kick Bass Subsonic Filter tion, set the switch in the off position. The ACW68I is possible to use as high Note: Please connect the remote terminal power active midbass enclosure. Placed to the remote output of head unit as Fig.4. - Page 5 The HLI features DLS proprietary Smart Load Circuit , SLC. SLC is required for an error free function in newer cars with ad- vanced OEM diagnostics sound systems.
-
Page 6: Low Level Input Wiring
NOTE: Do not connect BOTH the high level and low level inputs from your receiver to your amplifier at the same time. Low Level Input Wiring Low-level (RCA) input wiring is prefered for best audio performance. Most trunk or hatchback installations will require a 15-20 feet RCA cable, while pickup trucks and under seat installations will require a 6-12 feet RCA cable. -
Page 7: Power Terminal
Power Terminal Connect to a good chassis ground. The ground connection should be clean, unpainted metal to provide a good electrical connection. Use a wire brush, a scraper or a piece of an abrasive sheet to clean the metal. Remote Terminal Connect the remote terminal to the remote output of the head unit. -
Page 8: Installation
Installation We include a fixing kit to ensure the subwoofer remains securely mounted. Two types of installation are possible. 4 screws M4*6 Figure 1 4 mounting tabs Under the seat Figure 2 1. The seat must be positioned in its normal fixed position. - Page 9 Installation We include a fixing kit to ensure the subwoofer remains securely mounted. Two types of installation are possible. 4 screws M4*6 Figure 1 4 mounting tabs In the trunk Figure 2 1. Rear seats must be positioned in their normal fixed position.
-
Page 10: Troubleshooting Testing
Troubleshooting testing lf you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous pages. lf problems persist, read the following troubleshooting tips which may help eliminate the problems. Amplifier will not Check to make sure you have a good ground connection. -
Page 11: Professional Tips
If the noise does not return, re- route original cable away from source of interference.If noise remains regardless of cable position, try to use so called Quasi-balanced signal cables. DLS PRO-cables are Quasi-balanced. -
Page 12: Specifications
Specifications Model: ACW68I Amp: Class AB Power: 120W RMS / 250W MAX THD: < 0.4 % SNR: > 95dB Frequency Response: 30Hz- 150Hz Input sensitivity HLI: 0.9V - 35V Input sensitivity RCA: 300mV - 6V Smart Load Circuit SLA: Auto turn on ATO:... -
Page 13: Dimensions
Dimensions 210mm 72mm... -
Page 14: Product Markings
European Economic Area (EEA). DLS products complies with the relevant provisions of the RoHS Directive for the European Union. In common with all Electrical and Electronic Equipment (EEE) the product should not be disposed of as household waste. - Page 15 DLS Sweden l info@dls.se l www.dls.se...
