l e x
F
W1042 - 90K1 / 90K2 / 90R3
King UPH Bed
IMPORTANT
Carefully remove all parts from the carton, and put
them individually on a soft cloth to prevent damage
to the parts.
We have taken great care in the design of this product
and request that you carefully and accurately follow our
assembly instructions to ensure proper set-up.
A Phillips Head Screwdriver is required for assembly (Not Provided)
Part List
A. Headboard
1 piece
F. Headboard
Bottom Rail
1 piece
Hardware List
Bolt
Ø5/16'' x 18 UNC x 1-1/2''
8 pieces
Thread Bolt
Ø5/16'' x 18 UNC x 3-1/2''
8 pieces
t e e l
B. Footboard
1 piece
G. Center Rail
2 pieces
Spring Washer
Ø5/16'' x 1.5mm
Ø5/16'' x Ø19 x 1.5mm
8 pieces
Curved Washer
1" x 5/8" x 1/16'
8 pieces
R
Assembly Instructions 1/4
C. Side rail
D. Headboard
2 pieces
Post Left
1 piece
H. Roll Slats
1set
Flat Washer
Hex Key
5/32''
8 pieces
1 piece
Hexagonal Nut
Ø5/16" x 1/2"
8 pieces
Hardware pack
E. Headboard
Post Right
1 piece
I. Slat Support
12 pieces
Screw
12 pieces
Spanner Wrench
1/2"
1 pieces
