l e x
F
W1042-860
Dresser
IMPORTANT
Carefully remove all parts from the carton, and put
them individually on a soft cloth to prevent damage
to the parts.
We have taken great care in the design of this product
and request that you carefully and accurately follow our
assembly instructions to ensure proper set-up.
Part List
A. Dresser
1 piece
Hardware List
Bolt
Ø5/16'' x 18 UNC x 1-3/4''
8 pieces
t e e l
Spring Washer
Flat Washer
Ø5/16'' x 1.5mm
Ø5/16'' x Ø19 x 1.5mm
8 pieces
R
Hardware pack
Assembly Instructions 1/3
B. Leg
4 pieces
Hex Key
5/32''
8 pieces
1 piece
C. Support Leg
1 piece
Anti- Tipping
1set
Advertisement
Related Manuals for FLEXSTEEL Bellevue W1042-860
Summary of Contents for FLEXSTEEL Bellevue W1042-860
- Page 1 l e x t e e l W1042-860 Dresser IMPORTANT Carefully remove all parts from the carton, and put them individually on a soft cloth to prevent damage to the parts. We have taken great care in the design of this product and request that you carefully and accurately follow our assembly instructions to ensure proper set-up.
- Page 2 l e x t e e l Assembly Instructions 2/3 IMPORTANT NOTES • Do not tighten up all the bolts until each part is properly assembled. • Keep the Hex Key in a safe place as you may need to tighten up the bolts in the future. •...
- Page 3 Avoid the use of harsh chemicals or abrasive cleaning materials. • Wipe the cabinet clean with a soft, dry cloth after each use. • Wipe up spills quickly with a soft, dry cloth. Flexsteel Industries, Inc. For Parts or Customer Service call toll-free: 1-888-415-3979 Monday-Friday 8:00 a.m.
