Summary of Contents for GE 35 Series

Page 1 Panametrics MMS35-111-1-000 Moisture Monitor Single-Channel Hygrometer Limited Availability Used and in Excellent Condition Buy Today! https://www.artisantg.com/98936-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . •...
Page 2 Measurement & Control Solutions Moisture Moisture Monitor Series 35 Single-Channel Hygrometer User’s Manual 910-140 Rev. H March 2011 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 3 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 4 Moisture Monitor Series 35 Single-Channel Hygrometer User’s Manual 910-140 Rev. H March 2011 www.ge-mcs.com ©2011 General Electric Company. All rights reserved. Technical content subject to change without notice. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 5 [no content intended for this page] Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 6: Safety Issues
Preface Information Paragraphs • Note paragraphs provide information that provides a deeper understanding of the situation, but is not essential to the proper completion of the instructions. • Important paragraphs provide information that emphasizes instructions that are essential to proper setup of the equipment. Failure to follow these instructions carefully may cause unreliable performance.
Page 7: Qualification Of Personnel
Environmental Compliance Waste Electrical and Electronic Equipment (WEEE) Directive GE Measurement & Control Solutions is an active participant in Europe’s Waste Electrical and Electronic Equipment (WEEE) take-back initiative, directive 2002/96/EC. The equipment that you bought has required the extraction and use of natural resources for its production.
Page 8: Table Of Contents
2.8.1 Modified or Non-GE Cables ........
Page 9 Contents Chapter 3. Operation 3.1 Introduction ............27 3.2 Getting Started .
Page 10 Contents Chapter 4. Troubleshooting and Maintenance 4.1 Introduction ............59 4.2 Common Problems .
Page 11 Contents [no content intended for this page] viii Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 12: Chapter 1. Features And Capabilities
Chapter 1. Features and Capabilities Chapter 1. Features and Capabilities The Series 35 is a microprocessor-based, single-channel hygrometer that measures moisture content in gases. The Series 35 is suitable for a wide range of process conditions requiring real-time moisture measurement. It measures dew/frost points over a range of –110 to +60°C (–166 to +140°F), and comes equipped with two optional alarm relays, one fault alarm, and a single analog output.
Page 13: Probes
Chapter 1. Features and Capabilities 1.2 Probes The moisture probe is the part of the system that comes in contact with the process, and is usually installed in a sample system. The Series 35 uses any M Series probe to measure dew point temperature in °C or °F. A sensor assembly is secured to the probe mount and protected with a sintered stainless steel shield (see Figure 2).
Page 14: Chapter 2. Installation
Chapter 2. Installation Chapter 2. Installation 2.1 Introduction This chapter discusses installing the Series 35 in all of its configurations. Below is a list of procedures that you must follow to install your unit. Depending on the type of unit you have, refer to the appropriate section(s) that follow to install your Series 35 correctly.
Page 15: Choosing A Site For Best Performance
• Do not install any other components, such as filters, upstream of the probe or sample system unless instructed to do so by GE. Many common components, such as filters and pressure regulators, are not suitable for sample systems because they have wetted parts that may absorb or release materials such as moisture into the sample stream.
Page 16 Chapter 2. Installation 2.2 Choosing a Site for Best Performance (cont.) • Observe the proper cable restrictions for the probes. The M Series probes require specially shielded cable. You can locate the M Series probes up to 600 meters (2,000 feet) from the Series 35. •...
Page 17: Precautions For Moisture Probes
Observing these precautions will result in a long and useful probe life. GE recommends that probe calibration be checked routinely, at one-year intervals, or as recommended by our applications engineers for your particular application.The probe measures the water vapor pressure in its...
Page 18 Chapter 2. Installation 2.3 Precautions for Moisture Probes (cont.) Static or Dynamic Use: The sensor performs equally well in still air or where considerable flow occurs. Its small size makes it ideal for measuring moisture conditions within completely sealed containers or dry boxes.
Page 19: Sample System Guidelines
The purpose of a sample system is to condition or control a sample stream to within the specifications of the probe. The application requirements determine the design of the sample system. GE applications engineers will make recommendations based on the following general guidelines.
Page 20 Chapter 2. Installation 2.4 Sample System Guidelines (cont.) Note: The actual sample system design is dependent on the application requirements. Probe Outlet Sample Cell Inlet Figure 3: Typical Moisture Sample System Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 21: Installing The Sample System
2.5 Installing the Sample System The sample system is usually fastened to a metal plate that has four mounting holes. GE also provides the sample system in an enclosure if requested. Outline and dimension drawings are included with all GE sample systems.
Page 22: Installing A Probe In The Sample System
If mounting the probe directly into the process line, CAUTION! consult GE for proper installation instructions and precautions. Follow the steps below to install the probe into the external sample cell. Insert the probe into the sample cell so it is perpendicular to the sample inlet.
Page 23 Chapter 2. Installation 2.6 Installing a Probe in the Sample System (cont.) Probe Inlet Sample Cell Outlet Figure 4: A Typical Probe Installation Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 24: Mounting The Electronics Unit
Chapter 2. Installation 2.7 Mounting the Electronics Unit The rack mount Series 35 may be mounted into a standard 19” rack, the panel mount Series 35 may be mounted into a rectangular cutout on most instrument panels, and the weatherproof Series 35 may be mounted on any vertical wall.
Page 25: Making Wiring Connections To The Electronics Unit
Chapter 2. Installation 2.8 Making Wiring Connections to the Electronics Unit This section covers the following topics: • precautions for modified or non-GE cables • connecting the probe • connecting the alarms • connecting a recorder output device • connecting an auxiliary input •...
Page 26: Modified Or Non-Ge Cables
• Carry the shield through any splice. A common mistake is to not connect the shields over the splice. If you are modifying a GE cable, the shield will not be accessible without cutting back the cable insulation. Also, do not ground the shield at both ends.
Page 27: Connecting The Probe
+105°C (221°F) or below –40°C (–40°F). Standard cable assemblies (including connectors) can be ordered from GE in any length up to 600 meters (2,000 feet). Follow the steps below to connect the probe to the electronics: Make sure the power is disconnected from the Series 35.
Page 28 Chapter 2. Installation 2.8.2 Connecting the Probe (cont.) IMPORTANT: To maintain good contact at each terminal block and to avoid damaging the pins on the connector, pull the connector straight off (not at an angle), make cable connections while the connector is away from the unit, and push the connector straight on (not at an angle) when the wiring is complete.
Page 29: Connecting The Alarms
Chapter 2. Installation 2.8.3 Connecting the Alarms The Series 35 has one fault alarm, and two optional alarms that can be configured as high or low; that is, the contacts can be programmed to trip when the measured reading is over or under the alarm setpoint. The fault alarm, if enabled, will trip when there is a power failure, when a calibration error or a range error occurs, when there is a signal fault, or when the system is reset by the watchdog function.
Page 30 Chapter 2. Installation 2.8.3a Connecting the High and Low Alarms (cont.) Table 2: High & Low Alarm Connections Connect Alarm A: To ALARM A Terminal Block: NC Contact pin #4 NO Contact pin #5 A Contact pin #6 Connect Alarm B: To ALARM B Terminal Block: NC Contact pin #7...
Page 31: Connecting A Recorder Output Device
Chapter 2. Installation 2.8.4 Connecting a Recorder Output Device IMPORTANT: The following instructions apply to Series 35 models with Output Board 703-1175. For models with Output Board 703-1180, see Appendix E. The Series 35 has one recorder output, which is isolated. This output provides either a current or voltage signal, which is set using switch S1 on the output circuit board (see Figure 6 on page 21 for the location of S1).
Page 32 Chapter 2. Installation 2.8.4 Connecting a Recorder Output Device (cont.) Switch S1 Figure 6: S1 Location on 703-1175 Output Board Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 33: Connecting An Output Device
Chapter 2. Installation 2.8.4 Connecting a Recorder Output Device (cont.) IMPORTANT: To maintain good contact at each terminal block and to avoid damaging the pins on the connector, pull the connector straight off (not at an angle), make cable connections while the connector is away from the unit, and push the connector straight on (not at an angle) when the wiring is complete.
Page 34: Connecting Power To The Unit
Chapter 2. Installation 2.8.5 Connecting Power to the Unit GE supplies a molded plug and cord for AC power connections in rack, bench and panel mount units; however, you must supply the power cable for 24 VDC units and weatherproof units.
Page 35: Performing An Mh Calibration/Test Adjustment
Chapter 2. Installation 2.8.6 Performing an MH Calibration/Test Adjustment If you modify the supplied cables or do not use standard GE-supplied cables, you must perform a calibration test/adjustment to test the cable and, if necessary, compensate for any error or offset introduced by splicing or long cable lengths.
Page 36 Chapter 2. Installation 2.8.6b Calibration Procedure (cont.) Reprogram the Series 35 with the new (corrected) low reference value (if required), as described in Entering High and Low Reference Values on page 37. Verify that the probe cable is not connected to the probe. Note the zero reference readings and verify that the readings are now within ±0.0003 MH.
Page 37 Chapter 2. Installation [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 38: Chapter 3. Operation
Chapter 3. Operation Chapter 3. Operation 3.1 Introduction The Series 35 has been factory-programmed and set up to begin taking measurements as soon as it is powered on. This chapter describes starting the unit and beginning operation of the unit as quickly as possible. In addition, setting up the alarm relays, a recorder, and the user-defined functions are covered.
Page 39: Getting Started
Chapter 3. Operation 3.2 Getting Started Since the calibration data has already been set up at the factory, you can begin taking measurements as soon as you power up the Series 35. Proceed to the appropriate section to power up your unit and verify that it is working correctly: •...
Page 40: Entering Data Into The User Program
Chapter 3. Operation 3.2.2 Entering Data into the User Program The Series 35 User Program allows you to change factory set-up data, set up alarms and a recorder output device, and set up user-defined program functions. In order to enter and exit the User Program, move through the main menus, and enter numeric data into the User Program, you must first learn how to use the programming keys located on the front panel of the Series 35.
Page 41 Chapter 3. Operation 3.2.2b Entering and Exiting the User Program This section describes how to use the [ENTER] [ESC] keys to enter and exit the User Program. Refer to Table 6 for the key sequence for entering the User Program main menu. Note: The first two steps must be performed within 5 seconds of each other or the unit will time out and return to displaying measurements.
Page 42 Chapter 3. Operation 3.2.2c Moving Through the User Program Use the arrow keys to scroll through the eight Main Menu options as follows (refer to the menu maps in Appendix B as a guide): • DP RANGE - use to enter high and low dew points for the calibration curve •...
Page 43: Entering Numeric Data
Chapter 3. Operation 3.2.2d Entering Numeric Data To enter numbers one digit at a time, use the arrow keys to scroll to the desired number (0 to 9 or the decimal point), then press the key to [ENTER] move to the next digit position. Repeat this procedure until all numbers are entered.
Page 44 Chapter 3. Operation 3.2.3a Entering the Dew Point Range The DP Range is used to enter high and low dew point values. This range is used by the Series 35 to determine the number of points on the calibration curve. Note: The high and low dew points are listed on the Moisture Probe Calibration Data Sheet located in the probe box.
Page 45 Chapter 3. Operation 3.2.3b Entering Calibration Data After entering the high and low dew point values, use the CURVE option to enter calibration data for the moisture probe or the auxiliary input. Refer to the appropriate section that follows to program the Series 35. To Enter Moisture Probe Calibration Data: Moisture probe calibration data is always taken at fixed dew point values in 10ºC intervals.
Page 46 Chapter 3. Operation To Enter Probe Calibration Data (cont.) Note: To abort the editing function without changing the value, press the key. [ESC] Repeat this procedure for each point on the MH Curve, then press [ESC] until you return to the CURVE menu.
Page 47 Chapter 3. Operation To Enter Auxiliary Input Calibration Data: (cont.) Edit Pt# 1 Use the arrow keys to scroll to the desired point, then press the [ENTER] key. #1mA = 4.000 Press either arrow key to delete the present mA value and enter edit mode. Use the arrow keys to enter a new value, one [ENTER] digit at a time, then press...
Page 48 Entering High and Low Reference Values IMPORTANT: Do not change these reference values unless instructed to do so by GE. The Series 35 requires high and low reference values for its moisture measurement circuitry. These references are factory calibration values that are specific to each unit.
Page 49: Changing The Measurement Display
Chapter 3. Operation 3.3 Changing the Measurement Display Use this section to set up the Series 35 display screen for the measurement modes you want to display. The front panel of the Series 35 contains four (4) display keys that let you quickly change the measurement display during operation.
Page 50: Setting Up The Alarm Relays
Chapter 3. Operation 3.4 Setting Up the Alarm Relays The Series 35 has one fault alarm and two optional high/low alarms. Use this section to enable the fault alarm or to set up the optional high/low alarm relays. (Refer to Table 7 on page 40 for a list of possible alarm conditions.) High/Low Alarms: these alarm relays can be programmed to trip when the measured reading is over (high) or under (low) the alarm setpoint.
Page 51 Chapter 3. Operation Fault Alarm (cont.): • when there is a signal fault • when the system is reset by the watchdog function. Note: The Watchdog Function is a supervisory circuit that automatically resets the User Program in the event of a system error. Table 7: Alarm Conditions Alarm Non-Fault...
Page 52: Enabling Or Disabling The Alarms
Chapter 3. Operation 3.4.1 Enabling or Disabling the Alarms If alarm A or alarm B is disabled, the display returns to the alarm menu; if alarm A or alarm B is enabled, the alarm mode options are displayed. The fault alarm options are limited to the “Enable” or “Disable” choices. After the fault alarm is enabled or disabled, the display returns to the alarm menu.
Page 53: Selecting The Measurement Units
Chapter 3. Operation 3.4.3 Selecting the Measurement Units The next set of prompts that appears depends on the alarm mode selected. Choose the units to which you want the alarm to respond. Refer to the appropriate section below and to Table 8 for a list of the available units. If you selected “ALM HYG”...
Page 54: Configuring The Alarm
Chapter 3. Operation 3.4.4 Configuring the Alarm After selecting the desired measurement units, the following set of prompts appears: Low Alarm Use the arrow keys to choose a high or low alarm, then press [ENTER] . (A high alarm trips when a reading is above the setpoint, Hi Alarm while a low alarm trips when a reading is below the setpoint.)
Page 55: Setting Up A Recorder
Chapter 3. Operation 3.5 Setting Up a Recorder Use this section to set up the one Series 35 recorder output. To configure the recorder output signal, do the following: • select the output signal in milliamps or volts • select the recorder measurement mode and units •...
Page 56: Selecting The Measurement Mode And Units
Chapter 3. Operation 3.5.2 Selecting the Measurement Mode and Units 3.5.2a Selecting the Measurement Mode Select “RCD HYG” if you want the recorder to respond to measurements taken from the probe input connection; select if you want the “RCD AUX” recorder to respond to measurements taken from the auxiliary input connection.
Page 57: Setting The Zero And Span Values
Chapter 3. Operation 3.5.2b Selecting the Measurement Units (cont.) “RCD AUX” was selected at the initial recorder prompt on page 45, either a mA (milliamp) output value or a user-defined XF (Auxiliary Function) output value may be chosen. RCD AUXmA Use the arrow keys to scroll to the desired output value, then press [ENTER]...
Page 58: Setting Up User-Defined Functions
Chapter 3. Operation 3.6 Setting Up User-Defined Functions Use this section to set up and define a variety of program functions to enhance the usability of the Series 35. menu lets you set up the following program functions: USER • Offset Value •...
Page 59: Entering An Offset Value
Chapter 3. Operation 3.6.1 Entering an Offset Value Use this option to adjust the displayed dew/frost point reading. A positive number increases the reading, while a negative number decreases the reading. The offset value is always displayed in dew/frost point °C. Note: Be sure to record all entered output data in the Data Information Sheet in Appendix C.
Page 60: Entering A Constant Pressure
Chapter 3. Operation 3.6.2 Entering a Constant Pressure This option lets you enter a fixed value for the pressure of the sample gas at the moisture probe location. This value is used to calculate the moisture content in ppmv. Refer to Table 9 for a list of the available constant pressure units.
Page 61: Entering An Automatic Calibration Interval
3.6.3 Entering an Automatic Calibration Interval The Series 35 automatically calibrates itself at user-defined intervals, to compensate for any drift in the electronics. Normally, GE recommends setting the Autocal interval to 480 minutes (eight hours). However, a smaller Autocal interval is beneficial if the Series 35 is exposed to extreme temperature or weather conditions.
Page 62 Chapter 3. Operation 3.6.3 Entering an Automatic Calibration Interval (cont.) After you confirm the Autocal interval and return to the main menu, the Series 35 immediately performs an Autocal. The next time the Autocal occurs depends on the length of the time interval setting. The Series 35 determines the times of subsequent Autocals by establishing a fixed schedule, beginning at midnight, using the specified interval.
Page 63: Entering A Backlight-On Time Interval
Chapter 3. Operation 3.6.4 Entering a Backlight-On Time Interval If your Series 35 is equipped with a backlight, you can program the backlight to turn off automatically after a predetermined time. If the display does not have the backlight, attempts to access this option results in an message;...
Page 64: Setting Up Computer Enhanced Response
Chapter 3. Operation 3.6.5 Setting Up Computer Enhanced Response Note: This option may not be installed on your Series 35. Computer Enhanced Response uses a dynamic moisture calibration technique to extrapolate the moisture level to the end point, when making measurements in abrupt “dry down”...
Page 65: Setting Up Range Error Processing
Chapter 3. Operation 3.6.6 Setting Up Range Error Processing Range errors occur when an input signal that is within the capacity of the analyzer is outside the range of the probe calibration data. The Series 35 displays range errors with an OVER RANGE UNDER RANGE message.
Page 66 Chapter 3. Operation 3.6.6 Setting Up Range Error Processing (cont.) Table 10: Range Error Processing Options Option Display Alarm/Recorder No Action none range error disabled Display error displayed fault alarm tripped fault alarm tripped, Hi/Lo RCD error displayed recorder output high for over-range errors, recorder output low for under-range errors fault alarm tripped, Hi/Hi RCD...
Page 67: Setting Up Calibration Error Processing
Chapter 3. Operation 3.6.7 Setting Up Calibration Error Processing A Calibration Error indicates a failure during measurement of the internal moisture references. During Autocal, internal references are read repeatedly, and the values measured are compared to a table of acceptable factory calibration values.
Page 68 Chapter 3. Operation 3.6.8 Entering a PPMv Constant Multiplier Use this option to apply a user-defined constant multiplier to the PPMv value. Values up to 999.9999 may be entered. PPMv MULTIPLIER In the menu, use the arrow keys to USER scroll to this prompt, then press the [ENTER] key.
Page 69 Chapter 3. Operation [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 70: Chapter 4. Troubleshooting And Maintenance
This chapter discusses some of the most commonly encountered problems and the procedures for correcting them. If you cannot find the information you need in this chapter, contact GE. Do not attempt to troubleshoot the Series 35 beyond the CAUTION! instructions in this chapter.
Page 71 Chapter 4. Troubleshooting and Maintenance Table 11: Solutions to Common Problems Possible System Symptom Cause Response Action Insufficient time Probe reads too Change the flow rate. A change in for system to wet during dry dew point indicates the sample equilibrate.
Page 72 Chapter 4. Troubleshooting and Maintenance Table 11: Solutions to Common Problems Possible System Symptom Cause Response Action Slow outgassing Replace the system components of system. with stainless steel or Slow electro-polished stainless steel. response. Sensor is contam- Clean the sensor and the sensor inated with shield.
Page 73: Screen Messages
(None) unit is plugged in. Check electrical outlet. “Loading...” Watchdog Reset System resets because Call GE if this happens (reinitializes) (see Chapter 3) watchdog signal is not more than 5 times within generated within ten minutes.
Page 74: Replacing The User Program
Chapter 4. Troubleshooting and Maintenance 4.4 Replacing the User Program The User Program is stored on an EPROM (Erasable Programmable Read Only Memory) chip. The EPROM is located on the main circuit board (part #703-1245), which is mounted inside the Series 35 electronics unit. If your Series 35 has a part #703-1180 circuit board, also see Appendix E.
Page 75: Removing The Circuit Board (Bench-Mount Only)
Chapter 4. Troubleshooting and Maintenance 4.4.1 Removing the Circuit Board (Bench-Mount Only) Note: The circuit board for the bench-mount unit is mounted on the inside of the electronics cover. Turn the power OFF and, if applicable, unplug the unit. WARNING! You must turn off and unplug the Series 35 before continuing with the following steps.
Page 76: Removing And Replacing The Eprom (All Units)
Chapter 4. Troubleshooting and Maintenance 4.4.2 Removing and Replacing the EPROM (All Units) Refer to Figure 7 on page 66 to locate the EPROM (labeled U28) on the #703-1245 circuit board. Use a chip puller to remove the EPROM. If you do not have a chip puller, use a small screwdriver to carefully wedge the chip out of its mounting.
Page 77: Replacing The Circuit Board (Bench-Mount Only)
Chapter 4. Troubleshooting and Maintenance 4.4.3 Replacing the Circuit Board (Bench-Mount Only) Replace the #703-1245 circuit board by turning it over and remounting the bracket that holds the circuit board to the inside of the Series 35 cover. Insert and tighten the six bracket screws. EPROM Notch Figure 7: EPROM and Notch (ref.
Page 78: Replacing And Recalibrating The Moisture Probes
Under severe conditions you should send the probes back for recalibration more frequently. Contact a GE applications engineer for the recommended calibration frequency for your application. When you receive new or recalibrated probes, install and connect them as described in Installing a Probe in the Sample System in Chapter 2.
Page 79: Testing The Alarm Relays
Chapter 4. Troubleshooting and Maintenance 4.6.1 Testing the Alarm Relays This test lets you manually trip and reset the alarm relays for testing purposes. TEST In the main menu, use the arrow keys to scroll to this prompt, then press the [ENTER] key.
Page 80: Testing The Recorder Output
Chapter 4. Troubleshooting and Maintenance 4.6.2 Testing the Recorder Output This option lets you test the recorder output to make sure it is operating properly. You can test four percentages of the full-scale recorder range: 125%, 100%, 50%,and 0%. TEST In the main menu, use the arrow keys to scroll to this prompt, then press the key.
Page 81: Adjusting The Recorder Zero/Span Values
Chapter 4. Troubleshooting and Maintenance 4.7 Adjusting the Recorder Zero/Span Values The measured value of the recorder output can vary from the programmed value due to resistance caused by the load (e.g., chart recorder, display, etc.) or by long wire runs or small gauge connecting wire. This menu option lets you adjust the recorder zero and span values to compensate for such variations.
Page 82 Chapter 4. Troubleshooting and Maintenance 4.7.1 Adjusting the Recorder Zero (cont.) Note: The recorder output cannot be adjusted to a value of 0.00 mA or 0.000 V due to limits imposed by electronic noise. The recorder output typically is 0.01 mA at a zero reading. Therefore, when checking for the zero value, the MMS35 automatically uses 5% of span for ranges of 0-20 mA and 0-2V (see Table 13).
Page 83 Chapter 4. Troubleshooting and Maintenance 4.7.1 Adjusting the Recorder Zero (cont.) Example: A test of a 0-20 mA output results in a meter reading of 1.3 mA. This is 0.3 mA higher than the desired meter reading (1 mA) shown in Table 13 on page 71.
Page 84: Adjusting The Recorder Span
Chapter 4. Troubleshooting and Maintenance 4.7.2 Adjusting the Recorder Span Note: The zero adjustment is an offset adjustment, while the span adjustment is a slope adjustment. As a result, the zero and span adjustments affect each other. Therefore, after you adjust one value you should re-adjust the other.
Page 85 Chapter 4. Troubleshooting and Maintenance 4.7.2 Adjusting the Recorder Span (cont.) Adjust the recorder span point to achieve the desired reading by performing the following operations. ADJ RCDS + Press either arrow key to delete the current Recorder Adjustment Value and enter edit mode.
Page 86: Chapter 5. Specifications
4 to 20 mA input. Intrinsic Safety: Intrinsically safe probe and cable when used with appropriate external zener barriers. Consult GE for more information. Recorder Output: 0 to 20-mA, 4 to 20-mA or 0 to 2-V analog, linear in parameter chosen.
Page 87 Chapter 5. Specifications 5.1 Electronics (cont.) Computer-Enhanced Response: Optional. Alarm Relays: Fault alarm Optional Form C: Standard Hermetically Sealed 8A @ 250VAC 0.3A @ 115VAC 8A @ 30VDC 2A @ 28VDC Note: To maintain Low Voltage Directive Compliance, EN Standard EN61010, the following rating applies: 2A @ 28VDC Display Units: Dew/frost point temperature: ºC, ºF...
Page 88: Dew/Frost Point Temperature
Chapter 5. Specifications 5.1 Electronics (cont.) Dew/Frost Point Temperature: Overall Range Capability: –110 to 60°C (–166 to 140ºF). Available Range Options: Standard: –80° to 20°C (–112° to 68°F) with data to -110°C (–166°F) High Range Data: –80° to 60°C (–112° to 140°F) Calibrated Accuracy at 25°C (77°F): ±2°C (3.6°F) from –65°...
Page 89: Moisture Measurement
Chapter 5. Specifications 5.2 Moisture Measurement Sensor Type: GE M-Series thin-film aluminum oxide Traceability: Each sensor is individually computer-calibrated against known moisture concentrations. Calibrations are traceable to National Institute of Standards and Technology (NIST) standard or National Physical Lab, U.K. (NPL) as accredited by Irish National Accreditation Board (INAB).
Page 90: Appendix A. Outline And Installation Drawings
Appendix A. Outline and Installation Drawings Appendix A. Outline and Installation Drawings This appendix contains the following drawings for the MMS 35: • Rack Mount Dimensions (ref. dwg #712-930), page 81 • Bench Mount Dimensions (ref. dwg #712-1006), page 82 •...
Page 91 Appendix A. Outline and Installation Drawings [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 92 Appendix A. Outline and Installation Drawings 9.96 2.91 0.25 (253.1) (74.0) (6.4) 12.00 (304.8) 10.12 4.44 (3.0) (112.8) (257.0) 3.47 POWER ENTER (88.1) 3.00 (76.2) SLOT (10.2) (6.9) 4 PLACES NOTES: 18.34 INCH 1. DIMENSIONS: (465.8) (MM) 2. WEIGHT: 19.00 (3.0KG) (482.6) Moisture Monitor Series 35 User’s Manual...
Page 93 Appendix A. Outline and Installation Drawings 10.78 (273.8) 10.98 (278.8) 3.62 NOTES: (91.9) INCH 1. DIMENSIONS: (MM) 4.5 LB 2. WEIGHT: (2.3 KG) Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 94 Appendix A. Outline and Installation Drawings 2.91 (74.0) (16.3) 10.40 (264.2) 10.30 (1.3) (261.6) (6.6) 12.00 (304.8) 3.14 (79.8) 3.65 (92.7) #10-32 STUD 4 PLACES .DIA, 4 PLACES (5.1) 1.00 PANEL MOUNTING DETAIL (25.4) SCALE=3/4 3.65 10.12 (92.7) (4.6) (257.0) 4.25 10.40 (108.0)
Page 95 Appendix A. Outline and Installation Drawings 11.44 (290.6) 8.00 (203.2) ENTER 15.71 (399.0) 13.41 13.56 12.75 (340.6) (323.9) (344.4) .313 DIA, 4 PLS (7.95) VIEW A-A NOTES: INCHES 1. DIMENSIONS: (MM) 5.22 (132.6) 9.25 LB. 2.60 2. WEIGHT: (4.20 KG) (66.0) 1.50 3.
Page 96 Appendix A. Outline and Installation Drawings 24VDC POWER AC POWER ALARM A ALARM B RECORDER FAULT ALARM OUTPUT OUTPUT NOT USED AUX IN PROBE FAULT ALARM ALARM FAULT ALARM ALARM ALARM ALARM 24VDC,100mA IN 1 D D N PROBE AUX IN PROBE AUX IN Moisture Monitor Series 35 User’s Manual...
Page 97 Appendix A. Outline and Installation Drawings AC POWER CHARGER CENTER BODY ALARM A ALARM B RECORDER FAULT ALARM OUTPUT OUTPUT 12VDC, 500mA NOT USED AUX-IN PROBE FAULT ALARM ALARM ALARM PORTABLE W/ SAMPLE SYSTEM 10 11 FAULT ALARM ALARM ALARM FAULT ALARM ALARM...
Page 98 Appendix A. Outline and Installation Drawings FAULT ALARM ALARM A ALARM B RECORDER OUTPUT OUTPUT AC POWER 24VDC POWER NOT USED AUX IN PROBE XXXVAC 24VDC PROBE NOT USED AUX IN FAULT ALARM ALARM ALARM Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ...
Page 99 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 100: Appendix B. Menu Maps
Appendix B. Menu Maps Appendix B. Menu Maps The following figures are complete diagrams of the Series 35 menu structure. Once you are familiar with how the Series 35 operates, use these diagrams as a reference for moving through the User Program. To enter the programming mode, perform the following sequence within five (5) seconds, or the Series 35 will time out and return to the measurement mode.
Page 101 Appendix B. Menu Maps [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 102 Appendix B. Menu Maps RUN? XX.X C NOTE: press at any time DISPLAY = Display Screen = Select Menu Option to go back one level. = Edit Mode Screen Must be pressed = Adjust Numeric Value = Enter Key = Escape Key within 5 seconds DP RANGE Hi DP...
Page 103 Appendix B. Menu Maps RUN? XX.X C NOTE: press at any time DISPLAY = Display Screen = Select Menu Option to go back one level. = Edit Mode Screen Must be pressed = Adjust Numeric Value = Enter Key = Escape Key within 5 seconds RCD HYG DP/F DP RANGE...
Page 104 Appendix B. Menu Maps RUN? XX.X C NOTE: press at any time DISPLAY = Display Screen = Select Menu Option to go back one level. = Edit Mode Screen Must be pressed = Adjust Numeric Value = Enter Key = Escape Key within 5 seconds OFFSET xxx.x C DP RANGE...
Page 105 March 2008 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 106: Appendix C. Data Information Sheet
Appendix C. Data Information Sheet Appendix C. Data Information Sheet Use this sheet to record all of the data that you enter into the User Program. If data is lost for any reason, use this sheet to re-program your unit. Store this sheet and any other related documents in a safe place for future reference.
Page 107 Appendix C. Data Information Sheet Notes: Date: Unit Serial Number: Application Description: Table 15: Dew Point Measurement Range High Table 16: Calibration Data for Moisture Point # MH Value Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 108 Appendix C. Data Information Sheet Table 17: Calibration Data for Auxiliary Input Point # Value Table 18: Probe Serial Number ___ ___ ___ ___ ___ ___ Table 19: MH Reference Values for Moisture High Zero Table 20: Alarm Output Settings Alarm A Alarm B Mode:...
Page 109 Appendix C. Data Information Sheet Table 21: Recorder Output Settings Recorder A Recorder B Range: Range: Mode: Mode: Zero: Zero: Span: Span: Table 22: User-Defined Functions Function Setting Offset Value Constant Pressure Auto-Cal Interval Backlight Interval Computer-Enhanced Response Range Error Processing Calibration Error Processing PPMv Constant Multiplier Moisture Monitor Series 35 User’s Manual...
Page 110: Appendix D. Spare Parts List
Appendix D. Spare Parts List Spare parts for the Moisture Monitor Series 35 are available directly from GE. Table 23 and Table 24 list the ordering information for the most commonly needed spare parts. If you require parts that are not listed here, contact GE for assistance.
Page 111 Appendix D. Spare Parts List [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 112: Appendix E. Older Version Circuit Boards
Appendix E. Older Version Circuit Boards Appendix E. Older Version Circuit Boards If your Series 35 main circuit board is numbered 703-1180, use the instructions and figures in this appendix where they are referenced in the User’s Manual. E.1 Replacing the User Program The User Program is stored on an EPROM (Erasable Programmable Read Only Memory) chip.
Page 113 Appendix E. Older Version Circuit Boards EPROM Notch Figure 18: EPROM and Notch (ref. dwg #703-1180) Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 114 Index Alarms Configuring ........... 43 Enabling/Disabling .
Page 115 Index Electronics Unit Configurations ..........1 Mounting .
Page 116 Index Numeric Data, Entering..........32 Offset Value .
Page 117 Index Range Error Processing..........54 Recorder Adjusting.
Page 118 Index Units, Display ........... . . 76 User Functions Autocal Interval .
Page 119 Index [no content intended for this page] Moisture Monitor Series 35 User’s Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 120: Warranty
Warranty Warranty Each instrument manufactured by GE Sensing is warranted to be free from defects in material and workmanship. Liability under this warranty is limited to restoring the instrument to normal operation or replacing the instrument, at the sole discretion of GE Sensing. Fuses and batteries are specifically excluded from any liability.
Page 121: Return Policy
AUTHORIZATION NUMBER (RAN), and shipping instructions for the return of the instrument to a service center will be provided. If GE Sensing instructs you to send your instrument to a service center, it must be shipped prepaid to the authorized repair station indicated in the shipping instructions.
Page 122 DECLARATION Sensing CONFORMITY DOC-0019, Rev. A GE Sensing 1100 Technology Park Drive Billerica, MA 01821 declare under our sole responsibility that the Moisture Monitor™ Series 35 Hygrometer to which this declaration relates, is in conformity with the following standards: • EN 61326-1: 2006, Class A, Table 2, Industrial Locations...
Page 123 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 124 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 125: Customer Support Centers
Customer Support Centers U.S.A. The Boston Center 1100 Technology Park Drive Billerica, MA 01821 U.S.A. Tel: 800 833 9438 (toll-free) 978 437 1000 E-mail: sensing@ge.com Ireland Sensing House Shannon Free Zone East Shannon, County Clare Ireland Tel: +35 361 470291 E-mail: gesensingsnnservices@ge.com An ISO 9001:2008 Certified Company www.ge-mcs.com/en/about-us/quality.html...
