Quick Start Guide
QFLEX 16LS-WP
Digitally Steerable Powered Column Array Loudspeaker with 16 Independently
Controlled Drivers, Integrated DSP and BeamEngine GUI Control for
Life Safety Installation Applications (Weather Protected)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QFLEX 16LS-WP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tannoy QFLEX 16LS-WP

  • Page 1 Quick Start Guide QFLEX 16LS-WP Digitally Steerable Powered Column Array Loudspeaker with 16 Independently Controlled Drivers, Integrated DSP and BeamEngine GUI Control for Life Safety Installation Applications (Weather Protected)
  • Page 2: Legal Disclaimer

    únicamente or table specified by the por cualquier daño o pérdida que pudiera sufrir LAB GRUPPEN, LAKE, TANNOY, TURBOSOUND, 11. Use únicamente los dispositivos o accesorios por un técnico cualificado. manufacturer, or sold with...
  • Page 3: Garantie Limitée

    électriques. informations peuvent faire l’ o bjet de modifications Um eine Gefährdung durch Stromschlag Standvorrichtungen, chariots, des diables, LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, sans notification. Toutes les marques appartiennent à auszuschließen, darf die Geräteabdeckung Stative, Halter oder Tische, Attention des présentoirs, des pieds...
  • Page 4 Por favor leia o manual de instruções. 、 、 、 、  tripé, suporte, ou mesa 用されている場合 LAKE TANNOY TURBOSOUND TC ELECTRONIC LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, し、 花瓶など水分を含んだものは、 装置の 、 、  および  especificados pelo には、 これが直ぐ TC HELICON BEHRINGER BUGERA Atenção TC HELICON, BEHRINGER, BUGERA e COOLAUDIO 上には置かないようにしてください。...
  • Page 5 MUSIC Tribe Tannoy has developed the QFlex Life Safety (LS) models as a cost eff ective solution for critical, life safety applications, a solution that balances complex power consumption needs with the high performance and intelligibility that is the core of the proven QFlex range. Based on Tannoy's superior knowledge and heritage of...
  • Page 6 Connections Every Tannoy QFlex product is carefully tested and inspected before being packaged and leaving the factory. After unpacking your loudspeaker, please inspect for any NOTE: QFlex is a professional product intended for installation by properly qualifi ed and certifi cated personnel.
  • Page 7 QFLEX 16LS-WP Quick Start Guide Assembly Mounting Place each module in its respective position on the assembly area keeping them slightly spaced apart. All electronic components are housed in the master module of a QFLEX 16LS-WP QFlex 16LS. Connect the multipin connectors as shown.
  • Page 8 Ambient noise sensing feature The BeamEngine and VNET (Podware) software applications are needed to operate the QFlex speakers. Refer to the VNET and QFlex manuals for information on installation and operation. Visit tannoy.com to download all associated documents for the QFlex line. BeamEngine...
  • Page 9: Specifications

    QFLEX 16LS-WP Quick Start Guide Other important information Specifi cations QFlex 16LS-WP Confi guration Important information 4" LF No. of amp channels 100 W (RMS) @ 4 Ohms Vertical dispersion 5 - 100 degrees symmetrical or asymetrical, 1. Register online. Please register your new...
  • Page 10 QFLEX 16LS-WP Quick Start Guide FEDERAL COMMUNICATION COMMISSION COMPLIANCE INFORMATION QFLEX 16LS-WP Responsible Party Name: MUSIC Tribe Brands UK Ltd. Address: Klark Industrial Park, Walter Nash Road, Kidderminster, Worcestershire, DY11 7HJ United Kingdom Phone Number: +44 1562 732290 QFLEX 16LS-WP This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
