- Page 1 RANGE USER MANUAL Di5, Di5t, Di5 DC & Di5 DCt Di6, Di6t, Di6 DC & Di6 DCt Di8 DC & Di8 DCt...
- Page 3 Designed for a wide variety of sound reinforcement applications the Tannoy Di is an ultra compact loudspeaker system capable of delivering high sound pressure levels with extremely low distortion, resulting in outstanding clarity, definition and detail. A truly universal solution, the Di offers outstanding durability and resistance to scuffs and knocks. Able to deliver consistent performance under a wide range of adverse conditions the Di is suited to applications indoors or out, whether it be a theme bar or theme park.
-
Page 4: Input Connector
YOKE TRIM Remove the yoke trims on the top and bottom panels to access the yoke bracket fixing point GRILLE AND TRIM ASSEMBLY INPUT CONNECTOR Remove the rubber grommet to access the connector. The rubber grommet ensures the rear of the product is kept water-tight SAFETY TAB... - Page 5 GRILLE AND TRIM ASSEMBLY YOKE BRACKET (SUPPLIED WITH FIXINGS) POLE MOUNT ADAPTOR K-BALL BRACKET...
- Page 6 USING SUPPLIED YOKE BRACKET 1. Fix the yoke bracket 2. Remove the yoke 3. Remove the rubber 4. Feed the speaker to the surface using a trims from the product grommet from the rear of cable through the rubber suitable fixing method. to access the bracket the speaker.
- Page 7 USING OPTIONAL K-BALL BRACKET 1. If attaching the 2. Connect the speaker 3. If a conduit junction 4. If you are attaching K-Ball bracket to a wires to the connector box has been used, the bracket directly to a flush mounted inwall block in the bracket.
- Page 8 USING OPTIONAL POLE MOUNT ADAPTOR WITH SUPPLIED YOKE BRACKET 1. Use the supplied 2. Fix the pole mount 3. Remove the yoke 4. Remove the rubber fixings to fix the yoke bracket adaptor to the trims from the product grommet from the rear bracket to the pole pole using the strapping to access the bracket...
- Page 9 USING POLE MOUNT ADAPTOR WITH OPTIONAL K-BALL BRACKET 1. Pass the speaker wire 2. Connect the speaker 3. Offer the K-Ball 4. Fix the pole mount through the pole-mount wires to the connector bracket up to the bracket adaptor to the adaptor plate then fix the block in the rear of the adaptor plate, with the...
- Page 10 Di5, Di5t, Di5 DC & Di5 DCt R165.0 7° [R6.50"] 102.0 [4.02"] 162.0 240.7 [6.38"] [9.47"] 130.4 [5.13"] R300.0 [R11.81"] 155.0 [6.10"] Di6, Di6t, Di6 DC & Di6 DCt R300.0 8° [R11.81"] 159.0 [6.26"] 357.5 223.2 [14.08"] [8.79"] 178.8 [7.04"] R500.0...
- Page 11 5” YOKE BRACKET R15.0 241.0 [9.49"] [R0.59"] 85.0 90.0 [3.35"] [3.54"] 123.0 [4.84"] [0.24"] 35.0 ?22.0 [1.38"] [?0.87"] 54.0 [2.13"] 6” YOKE BRACKET R15.0 [R0.59"] [2.56"] 358.0 [14.09"] 145.0 150.0 [5.71"] [5.91"] 180.0 [7.09"] 35.0 ?22.0 [1.38"] [?0.87"] [0.24"] 65.0 [2.56"] Di6 YOKE Di6 YOKE...
- Page 12 Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves the right to alter without prior notice.
- Page 13 Data can be downloaded from www.tannoy.com Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves the right to alter without prior notice.
- Page 14 If you suspect a problem with a Tannoy product then, in the first instance, discuss it with your Tannoy dealer. If you require further assistance then we ask that you deal directly with your local Tannoy distributor. If you cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given below.
- Page 15 The following apparatus is manufactured in China for Tannoy Ltd of Rosehall Industrial Estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the protection requirements of the European Electromagnetic Compatibility Standards and Directives relevant to Domestic Electrical Equipment. The apparatus is designed and constructed such that electromagnetic...
- Page 16 T: 00 45 8742 7000 E: info@tcgroup-international.com TCGA (Americas sales) T: 00 1 (519) 745 1158 E: info@tcgroup-americas.com Tannoy Middle East T: 00 971 (04) 4401208 E: enquiries@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
