- Page 1 50 3 3A-1 S PLAS H ™ BAT H LI F T OPERATING INSTRUCTIONS SAVE THIS MANUAL FOR FUTURE USE. LX_5033A-1-INS-LAB-RevA23...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..........................3 INTENDED USE ..........................3 CONTRAINDICATIONS ........................3 SAFETY GUIDELINES—PLEASE READ BEFORE USE ..............3 WARNING / CAUTION SUMMARY ....................3 1 UNPACKING THE BATH LIFT ......................4 2 SETUP — CHARGING THE BATTERY................... 5 3 SETUP — PREPARING THE TUB FOR INSTALLATION ............... 6 4 SETUP —... -
Page 3: Introduction
INTRODUCTION These operating instruction contains assembly, operation and maintenance instructions for your bath lift. Read the entire instructions carefully before using your bath lift, and refer to them during use if you have questions. INTENDED USE The intended use of the 5033A-1 Splash Bath Lift is to aid the user into and out of the bathtub. -
Page 4: Unpacking The Bath Lift
UNPACKING THE BATH LIFT Unless the bath lift is to be used immediately, retain box and packaging materials for storage until use is required. 1. Check for obvious damage to the carton or its contents. If damage is evident, please notify the carrier and your GF authorized distributor. -
Page 5: Setup - Charging The Battery
SETUP — CHARGING THE BATTERY WARNING: Before first operation of your bath lift or after long periods of non-use (typically 7-10 days), fully charge the battery as follows. A flat battery will take up to 2 hours to charge. Do not charge in the bathroom or any humid area. Always charge in a dry area, ensuring your hands are dry first. -
Page 6: Setup - Preparing The Tub For Installation
SETUP — PREPARING THE TUB FOR INSTALLATION fig 1 fig 3 1. Remove any non-slip mats from the tub. 2. Ensure the bottom of the tub is clean and smooth, with no oil or tub cleaner residues that will prevent the suction feet from sticking. WARNING: Suction feet are not suitable in tubs that have been re-enamelled or that have rippled or textured surfaces. -
Page 7: Setup - Installing The Bath Lift
SETUP — INSTALLING THE BATH LIFT 1. Carefully pick up the bath lift, holding it as close as possible to your body. WARNING: When lifting the bath lift, always lift close to your body. 2. Place the suction feet on the flat bottom of the tub and as far back as possible at the opposite end to the faucets. - Page 8 fig 5 label 5. Fill the tub with water to the required level. Ensure the water temperature is not too hot before using the bath lift. s NOTICE: Ensure the actuator is not totally submerged in water. WARNING: Water level will rise when your body enters the tub and displaces the water. The depth of the water must not exceed the depth as indicated by the label (see above right) on the back and sides of the bath lift.
-
Page 9: Setup - Connecting The Hand Control
SETUP — CONNECTING THE HAND CONTROL Info: If the battery has not been used before or has not been used for a long period (typically 7-10 days), ensure you place it on charge before using the bath lift. fig 6 1. -
Page 10: Operation - Using The Bath Lift
OPERATION — USING THE BATH LIFT WARNING: Ensure all four suction feet are attached to the tub surface before each use. fig 7 1. To raise the bath lift, press the hand control UP button (see fig 7). If the side flaps are caught on any obstruction, immediately lower the bath lift by pressing the hand control DOWN button. -
Page 11: When The Bath Lift Is Not In Use
WARNING: If the hand control RED light appears while lowering, the bath lift will not go down any further. If this happens, press the UP button and the bath lift will raise you to the top of the tub. Charge the battery immediately. WARNING: In the event of an emergency, sliding the battery out of the hand control can instantly terminate all bath lift movement. -
Page 12: Removing The Bath Lift From The Tub
REMOVING THE BATH LIFT FROM THE TUB 1. Ensure the bath lift is in its lowest position at the bottom of the tub. 2. Remove the battery from the hand control. 3. Place the hand control on the seat and fold the side flaps in. fig 8 4. -
Page 13: Cleaning
CLEANING Clean the bath lift as frequently as you clean your tub, using non-abrasive cleaners. Cleaning agents should be used in accordance with their manufacturer’s guidelines. If the bath lift is used communally, we recommend disinfecting it after each use. SOLVENT-based cleaners, such as white spirit, should NOT be used. -
Page 14: Limited Warranty
LIMITED WARRANTY SCOPE OF WARRANTY GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and maintenance. -
Page 15: Symbols
SYMBOLS To comply with international standards for medical equipment, the following symbols are found on the bath lift’s labels: Only direct current from a small battery is used to power your bath lift. There is NO connection to electricity from an outlet when in use, so there is no risk of electric shock The bath lift is categorized as type B medical equipment and meets international standards for electrical safety... -
Page 16: Technical Data And Specifications
TECHNICAL DATA AND SPECIFICATIONS TECHNICAL DATA The bath lift seat and base is made of glass-filled polypropylene. The base frame tubes are made of aluminum. The hand control and battery are made of ABS. The hand control button cover and suction feet are made of thermoplastic elastomer. -
Page 17: Specifications
SPECIFICATIONS Bath Lift Lifting capacity (person) 280 lb / 127 kg / 20 stone Net weight (excluding battery) 14.33 lb / 6.5 kg Seat height UP 18.11 in. / 460 mm Seat height DOWN (loaded) 2.76 in. / 70 mm Power input 14.4 V dc nominal 7 A max Duty cycle... -
Page 18: Troubleshooting
TROUBLESHOOTING Symptom Possible Cause Solution Section Bath lift does not Battery is flat Charge battery Section 2 move; no sound Battery is not connected to Insert battery correctly into both Section 5 from the motor. hand control tracks on hand control cradle and slide all the way to the end until it clicks Not pressing correct area... - Page 19 Symptom Possible Cause Solution Section Battery does Power to charger is not Ensure battery charger plug is Section 2 not appear to be switched on or charger is connected to power socket/outlet and charged not connected to power switch it on (if applicable); check for socket/outlet battery charger indicator light Battery is not connected...
- Page 20 Symptom Possible Cause Solution Section Bath lift tips Bath lift not stored properly Always lower bath lift to bottom of tub Section 7 backward in after bath after use and ensure feet stick to tub highest position before each use Front suction feet are DO NOT USE bath lift;...
-
Page 21: Accessories
ACCESSORIES The bath lift can be supplied with a range of optional accessories. To order, contact your GF authorized distributor or Graham-Field Customer Service at 1.770.368.4700. Image Part Number Accessory Description 5033A-BB3103 Soft cover set Provides even greater comfort. (back and seat) 5033A-AB283 Side flap protector Side flap protectors are available... -
Page 22: Replacement Parts
REPLACEMENT PARTS Replacement parts, shown below, are available for the bath lift. To order, contact your GF authorized distributor or Graham-Field Customer Service at 1.770.368.4700. Item Part Item Part Number Description Number Number Description Number Left Side Flap 5033A-BB3002L Actuator 5033A-BB3004 Seat 5033A-BB3001... -
Page 23: 17 Index
17 INDEX Accessories 21 Unpacking the bath lift 4 Using the bath lift 10 Bath lift intended life 13 battery intended life 13 WARNING / CAUTION summary 3 WARNING statement, significance 3 Warranty, limited 14 When the bath lift is not in use 11 CAUTION statement, significance 3 Charging the battery 5 Cleaning 13... - Page 24 Manufactured For: GF Health Products, Inc. One Graham-Field Way, Atlanta, GA 30340 Made in United Kingdom +1 770.368.4700 © 2021, GF Health Products, Inc. All Rights Reserved. Information contained herein is subject to change without notice. Lumex is a registered trademark of GF Health Products, Inc. The most current and complete product information can be found on our website.
