Summary of Contents for Motorola MDHTN3003
- Page 1 MDHTN3003, MDHTN3004, MDHTN3005 Multi-Unit Chargers Mehrfach-Ladegeräte Chargeurs multi-cases Ìíîãîìñòíû çàðÿäíû óñòðîéñòâà Caricatori a più unità Los cargadores de varias unidades...
- Page 4 Other batteries may explode, caus- WARNING ing personal injury and damage. 2. Use of accessories not recommended by Motorola may result in risk of fire, electric shock, or injury. 3. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the charger.
- Page 5 5. To reduce risk of fire, electric shock, or injury, do not operate the charger if it has been broken or damaged in any way. Take it to a qualified Motorola WARNING service representative. 6. Do not disassemble the charger; it is not repair- able and replacement parts are not available.
- Page 6 MOTOROLA AUTHORIZED BATTERIES The batteries listed in Table 1 are approved for use with the MDHTN3003, MDHTN3004, and MDHTN3005 Multi-Unit Chargers. Table 1. Motorola Authorized Batteries Kit (part) Battery Chemistry/Description...
- Page 7 OPERATING INSTRUCTIONS Multi-unit chargers will charge only the Motorola authorized batteries listed in Table 1. Other batteries may not charge. Multi-unit chargers can charge up to six of the batteries (in any combination) listed in Table 1. Each of the six battery charger pockets will accommodate either a radio with a battery attached, or a battery alone.
- Page 8 b. pressing the battery toward the rear of the pocket c. sliding the battery into the charger pocket, ensuring complete contact between the charger and battery contacts RAISED RAIL CHARGING CONTACTS POCKET WARNING LABEL Figure 1. Battery Charger (viewed from above) 3.
- Page 9 Note Even though new batteries might prematurely indicate a full charge (steady green LED), charge the battery for 14 to 16 hours prior to initial use for best performance. Batteries will charge best at room temperature. TROUBLESHOOTING When troubleshooting, always observe the colour of the LED: Table 2.
- Page 10 Flashing Red LED Indicator? 1. Remove the battery from the charger, and: a. make sure that it is a Motorola authorized battery listed in Table1. Other batteries may not charge. b. remove power from the battery charger and, using a clean dry cloth, clean the gold metal, charging contacts of the battery and charger.
- Page 11 MDHTN3003, MDHTN3004, and MDHTN3005 Multi-Unit Chargers should be performed only by authorized Motorola service personnel. A service manual is available to qualified Motorola service technicians.
- Page 12 , Motorola sind Warenzeichen von Motorola, Inc. Alle Rechte vorbehalten. © 2005 par Motorola, Inc. , Motorola sont des marques déposées de Motorola, Inc. Tous droits réservés. © 2005 Motorola, Inc. , è Motorola ÿâëÿþòñÿ òîâàðíûìè çíàêàìè êîìïàíèè Motorola Inc.
