INSTALLATION AND OPERATING INSTRUCTIONS
WARNING: California Residents Only. This product can expose you to chemicals including
chromium which is known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information go to www.P65Warnings.ca.gov.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause
property damage, injury or death. Read and understand these instructions
thoroughly before positioning, installing, maintaining or servicing this equipment.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
APW Wyott
cooking equipment has been engineered to provide you with year-round dependable
®
service when used according to the instructions in this manual and standard commercial kitchen
practices.
972.908.6100 Phone
214.565.0976 Fax
DESIGNED SMART. BUILT SOLID.
Contact Bun Toaster
Model: M-95
INTENDED FOR OTHER THAN HOUSEHOLD USE
APW Wyott Food Service Equipment Company
1307 N. Watters Road, Suite 180 • Allen, TX 75013
®
1
ANSI/NSF4
P/N 70200001 09/18
+1.800.527.2100
www.apwwyott.com
Advertisement
Table of Contents
Related Manuals for APW Wyott M-95
Summary of Contents for APW Wyott M-95
- Page 1 ANSI/NSF4 P/N 70200001 09/18 APW Wyott Food Service Equipment Company 1307 N. Watters Road, Suite 180 • Allen, TX 75013 972.908.6100 Phone +1.800.527.2100 214.565.0976 Fax...
-
Page 2: Table Of Contents
IMPORTANT: Read the following important safety instructions to avoid personal injury or death, and to avoid damage to the equipment or property. WARNING: APW Wyott toasters are designed, built, and sold for commercial use. If positioned where the general public can use them, make sure that all cautions, warnings, and operating instructions are clearly posted near each unit to insure proper operation, reduce the chance of personal injury and/or equipment damage. - Page 3 Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in APW Wyott equipment. It is essential to use APW Wyott Replacement Parts when repairing APW Wyott equipment.
-
Page 4: General Information
3 . GENERAL INFORMATION Check the rating label for your model designation and electrical rating. The Rating Label is located on the bottom front of the control panel. Overall dimensions with feeder: 25 15/16” x 23 1/2” x 17 1/2” Electrical ratings: M952: 208VAC, 2780W, 13.4Amps, 60Hz or 240VAC, 2780W, 11.6Amps, 60Hz Cordset Configuration: 208/250V:NEMA6-20P Plug, 4 foot, 3 wire grounded cord. -
Page 5: Location
4 . Conveyor Installation Remove the top and bottom control panels by lifting it straight up. (See Figure 1) Lift conveyor assembly by using “U” shaped handles on each conveyor side bracket. Lower the conveyor into the two conveyor hanger brackets above the grill plate on each side, so the four spacers on the sides of the conveyor rest on the bottom flange and the bottom spacers are against the adjustment screws. -
Page 6: Operation Instructions
6 . OPERATION INSTRUCTIONS 6 . Wet operation . (using oil) Season the toaster grill by applying a light coating of oil to entire grill surface (Fry oil can be used). When toasting using oil, any high-quality cooking oil may be used with this toaster (do not use oils that contain dairy products such as butter). - Page 7 Daily Parts Cleaning: The Butter Roller, Butter Pan, Feeder, and Top and Bottom Control Panels can be placed in a dishwasher or sink and washed with mild detergent and warm water. Daily Conveyor Cleaning: Conveyor may be hot and is heavy, use caution when lifting and removing. Remove conveyor assembly by simply pushing back on the top row of paddles on conveyor.
- Page 8 If PTFE sheet is installed remove it when Bun Grill Toaster is cool. Step 1. Set the toaster temperature to 350°F. Step 2. Scrape loose food particles with scraper into Butter Pan under grill plate. Step 3. Squeeze 1 to 2 ounces of Scotch-Brite Quick Clean Small Appliance Cleaner No.
-
Page 9: Troubleshooting Guide
3. Is power switch “ON” and pilot light glowing? 4. Check the rating label. Is the unit connected to the correct power source? If the above checks out, and you still have problems, call an APW Wyott authorized service agent. APW SERVICE HOT LINE: 1-800-733-2203. -
Page 10: Exploded View
COVER RIGHT SIDE HOUSING 84213 PLATE COVER, LEFT SIDE 83065 ASSY CHAIN HANGER LEFT SIDE 83061 ASSY WELD HANGER ARM RIGHT SIDE 89301 LABEL, M-95 JIB CONTROL 84164 PANEL, CONTROL M-95 JIB 85281 FAN,COOLING, 3” DIA, 208/230V 89408 SWITCH, LIGHTED ROCKER 89491... - Page 11 Item Description 89059 WASHER #10 EXTERNAL LOCK 88993 SCREW 10-32X3/8 TRS HD PHILLIPS NYLK MS 89143 PLUG, HYCO # DP-187 88923 SCREW, 8-32x1-3/4 SLT PAN MS SS 89063 NUT, HEX 8-32 89145 TERMINAL BLOCK 300V-30AMPS 89054 NUT, KEPS 6-32 85640 CORDSET, 14/3 600V .440 HSJO 620P 89111 BUSHING, STRAIN RELIEF SR-7W-2...
- Page 12 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes...
-
Page 13: Warranty
Authorized Service Agencies. The use of other than APW Wyott Authorized Service Agencies will void this warranty and APW Wyott will not be responsible for such work or any charges associated with same. The closest APW Wyott Authorized Service Agent must be used.
