INSTALLATION
AND
OPERATING
INSTRUCTIONS
AT EXPRESS HORIZONTAL CONVEYOR TOASTER
UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
Replacement Parts List
WARNING: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment.
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Phone:
+1 (214) 421-7366
Fax:
+1 (214) 565-0976
Toll Free: +1 (800) 527-2100
Website: www.apwwyott.com
E-mail:
info@apwwyott.com
R
AT EXPRESS
Model:
TM
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE

TABLE OF CONTENTS

1
2
3
4
4
5
5
6
6
6
8
10
11
!
P/N 93300045 9/06
APW WYOTT
729 Third Avenue
Dallas, TX 75226

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT Express and is the answer not in the manual?

Questions and answers

Related Manuals for APW Wyott AT Express

Summary of Contents for APW Wyott AT Express

  • Page 1: Table Of Contents

    INSTALLATION OPERATING INSTRUCTIONS AT EXPRESS HORIZONTAL CONVEYOR TOASTER INTENDED FOR OTHER THAN HOUSEHOLD USE RETAIN THIS MANUAL FOR FUTURE REFERENCE UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES Safety Precautions Important Safety Instructions General Information Installation Instructions Specifications...

  • Page 2: Safety Precautions

    NOTICE: This symbol refers to information that needs special attention or must be fully understood even though not dangerous. APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully.

  • Page 3: Important Safety Instructions

    WARNING: To avoid electrical shock or personal injury, do not steam clean or use excessive water on the unit. WARNING: If service is required on this unit, contact your authorized APW Wyott Service Agent, or contact the APW Wyott Service Department directly at (214) 421-7366 or (800) 527-2100; fax (214) 565-0976.

  • Page 4: General Information

    Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in APW Wyott equipment. It is essential to use APW Wyott Replacement Parts when repairing APW Wyott equipment. Failure to use APW Wyott Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn.

  • Page 5: Specifications

    III. Toaster Placement Locate the toaster near a grounded receptacle of the proper configuration (see below). Plug the cordset directly into receptacle (DO NOT USE AN EXTENSION CORD). 1. In the United States, NEMA 5-15R. 2. In Canada, NEMA 5-20R. Place the toaster on a flat surface providing the following minimum clearances: 1.

  • Page 6: Cleaning Instructions

    If problems exist after checking the above, check the chart below. III. If any service is needed (italicized items), call an APW Wyott authorized service agency. All service should be performed by an APW Wyott authorized service agency. CLEANING INSTRUCTIONS...
  • Page 7 TROUBLESHOOTING CHART: THE PROBLEM THE CAUSE Won't toast... a. Toaster cold. b. Wrong power switch position. c. Wrong conveyor speed setting. Toasts unevenly... d. Only part of product surface is Toasted. e. Product located too far to side of conveyor. Product sticks to f.
  • Page 8 REPLACEMENT PARTS LIST - AT EXPRESS ITEM DESCRIPTION 93300010 W'ASSY, MAIN BODY 83956 DRIVE SHAFT ASSY AT-10 SEGMENTED BELT 83868 SPACER, CONVEYOR SHAFT 83248 BEARING, SHAFT 83821 BRACKET, BEARING 89061 NUT, HEX 10-24 38132 W'ASSY BEARING CLIP 38125 BEARING FLANGED POLYMER...
  • Page 9 EXPLODED VIEW - AT EXPRESS...

  • Page 10: Wiring Diagram

    IMPORTANT NOTICE: The information contained in this section of the manual is intended for individuals possessing backgrounds of electrical and mechanical experience, such as an authorized APW Wyott service technician. APW or the seller cannot be responsible for the interpretation of this information, nor can it assume any liability in connection with its use.

  • Page 11: Warranty

    APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
  • Page 12 Phone: +1 (214) 421-7366 Fax: +1 (214) 565-0976 Toll Free: +1 (800) 527-2100 Website: www.apwwyott.com E-mail: info@apwwyott.com APW WYOTT 729 Third Avenue Dallas, TX 75226...
