- Page 1 USER MANUAL WASHING MACHINE Front Loading MODEL: MF100W70B Series MF100W80B Series MF100W90B Series www.midea.com...
- Page 2 Therefore, we reserve the right to make changes to the design, features and accessories of all types and models without prior notice. On our website www.midea.com you can also download the user manual in digital form and discover other products. We hope you enjoy using your machine.
- Page 3 CONTENTS 1 SAFETY INSTRUCTIONS ....4 MAINTENANCE ........Safety Instructions ......4.1 Cleaning and Care ....... Cleaning the Cabinet......INSTALLATION ........Cleaning the Drum ......Product Description ...... Cleaning the Door Seal and Glass.. Accessories ........Cleaning the Inlet Filter ..... 2.2 Installation ......
- Page 4 1 SAFETY INSTRUCTIONS INTENDED USE The product is intended only for home use and for textiles in household amounts suitable for washing. This appliance is for indoor use only and not intended for built in use. Only use according to these instructions. The appliance is not intended for commercial use.
- Page 5 1 SAFETY INSTRUCTIONS Warning! ELECTRIC SHOCK HAZARD • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • If the machine is damaged, it must not be operated unless repaired by the manufacturer, its service agent or similarly qualified persons.
- Page 6 1 SAFETY INSTRUCTIONS INSTALLATION LOCATION AND SURROUNDING All washing and additional substances are to • be kept in a safe place out of the reach of children. • Do not install the machine on a carpet floor. • The obstruction of the openings by a carpet can damage the machine.
- Page 7 1 SAFETY INSTRUCTIONS INSTALLATION • Remove all packaging material and transport bolts before using the appliance. Otherwise, serious damage may result. • This appliance is equipped with a single inlet valve and can be connected to the cold water supply only. Mains plug must be accessible after installation.
- Page 8 1 SAFETY INSTRUCTIONS regulations. • Water and electrical connections must be carried out by a qualified technician in accordance with the manufacturer’s instructions and local safety regulations. Warning! • Don´t use multiple plugs or extension cords. • The appliance must not have an external switching device such as a timer or connected to a circuit that is regularly switched on and off.
- Page 9 1 SAFETY INSTRUCTIONS Do not remove the drain pump filter while there • is still water in the appliance. Big quantities of water can leak out, and there is a risk of scalding due to hot water. OPERATION AND MAINTENANCE •...
- Page 10 1 SAFETY INSTRUCTIONS • The door will unlock shortly after the end of a cycle. Please do not close the door with excessive • force. If it is found difficult to close the door, please check if the clothes are properly inserted and distributed.
- Page 11 1 SAFETY INSTRUCTIONS ENVIRONMENT Disposal of old appliances (Only for EU countries) This appliance is labelled in accordance with the European Directive 2012/19/EU on waste electrical and electronic equipment (WEEE). The directive provides the framework for the EU-wide take-back and recycling of waste equipment.
- Page 12 2 INSTALLATION 2.1 Product Description Service flap Control panel Door Drain hose Power supply cord Detergent dispenser Note! • The product picture is for illustration only, please refer to real product as reference. Accessories 4 x Cover 1 x Owner’s Acoustic sponge 1 x Supply hose (optional)
- Page 13 2 INSTALLATION 2.2 Installation Tools Needed If Installation By Yourself (not include) Installation area Warning! • Stability is important to prevent the product from wandering! • Make sure the machine is standing leveled and stable. • Make sure that the product does not stand onto the power cord. •...
- Page 14 2 INSTALLATION Unpacking the machine Warning! • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. • There is a risk of suffocation ! Keep all packaging well away from children. 1. Remove the cardboard box and styrofoam packing. 2.
- Page 15 2 INSTALLATION Levelling the machine Warning! • The lock nuts on all four feet must be screwed tightly against the housing. 1. Loosen the lock nut. 2. Turn the foot until it reaches the floor. 3. Adjust the legs and lock the nuts with a spanner.
- Page 16 2 INSTALLATION There are two ways to place the end of drain hose: Water trough 1.Put it into the water trough. 2.Connect it to the branch drain pipe of the trough. Acoustic Sponge Note! • Please make sure to assemble the acoustic sponges, which can effectively reduce the noise caused by the machine while working, in order to provide you with a more peaceful and quiet living environment.
- Page 17 3 OPERATION 3.1 Quick Start Caution! • Before washing, please make sure the washing machine is installed properly. • Your appliance was thoroughly checked before it left the factory. To remove any residual water and to neutralize potential odors, it’s recommended to clean your appliance before first use.
- Page 18 3 OPERATION 1. Before Washing earth terminal Open tap Plug in Load Main wash Softener Prewash Close door Add detergent Note! • Detergent need to be added in compartment I if the pre-wash function is selected. • Do not put laundry beads into the detergent dispenser.
- Page 19 3 OPERATION 2. Washing Power on Select programme Press Start/Pause to Select function or remain start the program default settings 3. After Washing Buzzer beep and “End” on display.
- Page 20 3 OPERATION 3.2 Before Each Washing • The ambient temperature of the machine should be 5 °C -40°C. If used under 0°C, the inlet valve and draining system may be damaged. If the machine is installed under freezing conditions, it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose can unfreeze before use.
- Page 21 3 OPERATION 3.3 Detergent Dispenser Pre wash Main wash Softener Release button to pull out the dispenser Caution! • Detergent only need to be added in compartment I ”after “ selecting pre-wash function. • Do not put laundry beads into the detergent dispenser. Programme Programme Cotton Cold...
- Page 22 3 OPERATION Detergent Recommendation Recommended washing Type of laundry Washing Wash cycles detergent and textile temp. Heavy-duty detergent Cotton 40℃, White laundry made 40 60/ with bleaching agents from boil-proof Cotton 60℃, and optical brighteners cotton or linen Steam Care Colour detergent without Coloured laundry Cotton...
- Page 23 3 OPERATION 3.4 Control Panel Product is switched Power. Start/Pause Press the button to start or pause the washing cycle. Option This allows you to select an additional function and will light when selected. Programmes Available according to the laundry type. Display The display shows the settings, estimated time remaining, options, and status messages for your washer.
- Page 24 3 OPERATION 3.5 Display Pre Wash Door Lock Extra Rinse Display Wash Time Delay Time Speed Error...
- Page 25 3 OPERATION 3.6 Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made Cotton of cotton or linen. Steam Care Steam Care is applicable for daily laundries like cotton and synthetics. The steam can deeply penetrate the fiber, which effectively eliminate bacterias and germs, preventing odors and protecting your health.
- Page 26 3 OPERATION Programme Load(kg) Default Time Cotton Cold 3:49 3:49 3:49 Cotton 20 ℃ 3:49 3:49 3:49 Cotton 40 ℃ 3:49 3:49 3:49 Cotton 60 ℃ 3:54 3:54 3:54 Jeans 1:48 1:48 1:48 Delicate 0:50 0:50 0:50 ECO 40-60 3:28 3:38 3:48 Rinse &...
- Page 27 3 OPERATION 3.7 Option Default Default spin Additional Cycle speed in rpm Temp.(℃) functions 1400 Cold 1000 Cotton Cold 1000 Cotton 20 ℃ 1000 Cotton 40 ℃ 1000 Cotton 60 ℃ 1000 Jeans Delicate ECO 40-60 1400 Rinse & Spin 1000 Spin only 1000...
- Page 28 3 OPERATION Pre Wash The Prewash function can get an extra wash before main wash, it is suitable for washing the dust rises to surface of the clothes; You need to put detergent into the Case (I) when select it. Extra Rinse The laundry will undergo extra rinse once after you select it.
- Page 29 3 OPERATION Child Lock To avoid mis operation by children. Extra Rinse Wash Start Press [Extra Rinse] and [Pre Wash] 3 sec. till buzzer beep. Caution! When the Child Lock is activated, the display will alternately show “CL” and the remaining time. Pressing any other button will cause the Child Lock indicator to flash for 3 sec.
- Page 30 4 MAINTENANCE 4.1 Cleaning and Care Warning! • Always unplug the appliance and close the water tap before cleaning and maintenance. Cleaning the Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary.
- Page 31 4 MAINTENANCE Cleaning the Inlet Filter Note! • Diminishing water flow is a sign that the filter need to be cleaned. 1. Close the tap and 2. Clean the filter with remove the water a brush. supply hose from it. 3.
- Page 32 4 MAINTENANCE Cleaning the Detergent Dispenser 1. Press down the release [ ] on the softener cover and pull the dispenser drawer out of the recess. Clean the inside of the recess with a brush. 2. Lift the softener cover off the dispenser drawer and wash both items with water.
- Page 33 4 MAINTENANCE Cleaning the Drain Pump Filter Warning! • Make sure that the machine has finished the washing cycle and is empty. Switch it off and unplug it before cleaning the drain pump filter. • Be careful of hot water. Wait for water cooling down. Risk of scalding! •...
- Page 34 4 MAINTENANCE 4.2 Trouble Shooting Whenever there is a problem with the appliance, check if you can solve it following the tables below. If the problem persists, please contact the customer service. Description Possible cause Solution Appliance does Door is not closed Close the door properly not start properly.
- Page 35 4 MAINTENANCE 4.3 Customer service Spare part for your appliance are available for a minimum of 10 years following EU COMMISSION REGULATION 2019/2023 ANNEX II Ecodesign requirements. In case of questions, please contact our local customer service center. Warning! Risk of electric shock •...
- Page 36 5 TECHNICAL SPECIFICATION Model Power Supply 220-240V~,50Hz MAX.Current Standard Water Pressure 0.05MPa~1MPa Washing Capacity 7.0kg 8.0kg 9.0kg Dimension 595mm 850mm 850mm 850mm 495mm 565mm 565mm Weight 60kg 68kg 71kg Rated Power 2000W 2000W 2000W...
- Page 37 V1.0 16138100A35596...
