WASHING MACHINE

USER MANUAL

Front Loading

Read This Manual

Use all instructions and explanations of

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

application is sold or passed on then ensure

that the new owner always receives those

operation instructions.

MODEL:

MF100W75

Table of Contents

Need help?

Do you have a question about the MF100W75 and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea MF100W75

Page 1 Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the application is sold or passed on then ensure that the new owner always receives those operation instructions. MODEL: MF100W75...
Page 2: Table Of Contents
CONTENTS Safety Instructions Safety Instructions ..........Installation Product Description ..........Installation ............Operations Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Option..............Other Functions ............Programmes............Washing Programmes Table ........Maintenances Cleaning And Care ..........Trouble Shooting ............
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions • This appliance is not intended for use by persons(includingchildren) with reduced physical,sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. •...
Page 4 SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: ！ Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in...
Page 5 SAFETY INSTRUCTIONS • Before any maintenance the device, unplug the appliance from the mains. • Always unplug the machine and turn off the water supply after use. The max. inlet water pressure, in pascals. The min. inlet water pressure, in pascals. •...
Page 6 SAFETY INSTRUCTIONS • Do not use any socket with rated current less than that of appliance.Never pull out power plug with wet hand. Risk to children! • Children of less than 3 years should be supervised to ensure that they do not play with appliance. •...
Page 7 SAFETY INSTRUCTIONS • It isn't intended to be built-in using. • Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases. • Remove all packages and transport bolts before using the appliance.
Page 8 SAFETY INSTRUCTIONS 6.A precaution indicates that the appliance shall not be installed at a humid place. • Please do not close the door with excessive forces. If it is found difficult to close the door, please check if the clothes are put in or distributed well. •...
Page 9: Product Description
INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service filter Drain hose Note! • The product line chart is for reference only, please refer to real product as standard. Accessories Transport Owner’s manual Acoustic Supply hose...
Page 10: Installation
INSTALLATION Installation Installation area ！ Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. W> 20mm Before installing the machine, the location characterized follows shall be selected: 1.Rigid, dry, and level surface 2.Avoid direct sunlight 3.Sufficient ventilation...
Page 11 INSTALLATION Levelling the washing machine ！ Warning! • The lock nuts on all four feet must be screwed tightly against the housing. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2.Loosen the lock nut turn the feet until it closely contacts with the floor.
Page 12 INSTALLATION Drain Hose ！！ Warning! Warning! • Do not kink or protract the drain hose. • Position drain hose properly ,otherwise damage might result of water leakage. There are two ways to place the end of drain hose: 1.Put it into the water trough. 2.Connect it to the branch drain pipe of the trough.
Page 13: Operations
OPERATIONS Quick Start Caution! • Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Main wash Softener...
Page 14: Before Each Washing
OPERATIONS Before Each Washing • The working condition of the washer should be(0-40)°C.If used under 0°C,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0°Cor less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use.
Page 15: Detergent Dispenser
OPERATIONS Detergent Dispenser Pre wash detergent Main wash detergent Softener Pull out the dispenser Caution! • Detergent only need to be added in "case I “after selecting pre-washing for product with this function. Programme Programme Spin only Cotton Cold Cotton 20℃ Hygiene 90℃...
Page 16: Control Panel
OPERATIONS Control Panel Note! • The chart is for reference only, Please refer to real product as standard. Start/Pause Product is switched Power. Press the button to start or pause the washing cycle. Programmes Option Available according to the laundry type. This allows you to select an additional function and will light when selected.
Page 17 OPERATIONS Option Pre Wash The Prewash function can get an extra wash before main wash,it is suitable for washing the dust rises to surface of the clothes;You need to put detergent into the Case (I) when select it. Extra Rinse The laundry will undergo extra rinse once after you select it.
Page 18: Other Functions
OPERATIONS Other functions Child Lock To avoid mis operation by children. Extra Rinse Wash Press [Extra Rinse] and [Pre Wash] Start 3 sec. till buzzer beep. Caution! • Press the two button 3sec. also to be released the function. • The “Child Lock” will lock all buttons except [ •...
Page 19 OPERATIONS Mute the buzzer Spin Delay Press the [Delay]&[Spin] button for 3sec. Start the buzzer is mute. To act the buzzer function, press the two buttons again for 3 seconds. The setting will be kept until the next reset. Caution! •...
Page 20: Programmes
OPERATIONS Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made of cotton or Cotton linen. Washing machine can kill some bacterium, and achieve hygiene Hygiene 90℃ effect. This programme is suitable for washing not very dirty clothes, Rapid 45’...
Page 21: Washing Programmes Table
OPERATIONS Washing Programmes Table Programme Load(kg) Default Time 1200 Cotton Cold 2:10 Cotton 20℃ 2:20 2:40 Cotton 40℃ 2:30 Cotton 60℃ 1:48 Jeans 0:50 Delicate 3:53 ECO 40-60 0:20 Rinse & Spin 0:12 Spin only 2:18 Hygiene 90℃ 1:30 Mix 60℃ 1:20 Mix 40℃...
Page 22: Maintenances
MAINTENANCES Cleaning And Care ！ Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary.
Page 23 MAINTENANCES Cleaning The Inlet Filter Note! • Inlet filter must be cleaned if there is less water. Washing the filter in the tap 1.Close the tap. 2.Remove the water supply hose from the tap. 3.clean the filter. 4.Reconnect the water supply hose Washing the filter in washing machine: Screw off the inlet pipe from the backside of the machine.
Page 24 MAINTENANCES Cleaning The Drain Pump Filter ！ Warning! • Be careful of the hot water! • Allow detergent solution to cool down. • Unplug the machine to avoid electrical shock before washing. • Drain pump filter can filter the yarns and small foreign matters from the washing.
Page 25: Trouble Shooting
MAINTENANCES Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Description Reason Solution Washing machine Restart after the door is closed Door is not closed properly cannot start up Check if the clothes is stuck...
Page 26: Technical Specifications
MAINTENANCES Technical Specifications Power Supply 220-240V~,50Hz MAX.Current 0.05MPa~1MPa Standard Water Pressure Dimension Washing Net Weight Rated Power Model Capacity (W*D*Hmm) MF100W75 7.5kg 595*400*850 55kg 2050W...
Page 27 QUESTIONS OR COMMENTS Country Contact Center Web Site +6621077799 http://www.midea.com/th Thailand Myanmar +09260367229 https://www.gbs.com.mm/en/about/vsk/ Cambodia +85523212435 http://bluemidea.com http;//vn.midea.com Vietnam +1800588863 Philippines +63288635522 http://www.mideaph.com Indonesian +628001888523 http://id.midea.com Malaysia https://www.midea.com/my/ +60392211033 Singapore +62222536 https://www.midea.com/sg/ This product is RoHS compliant.
Page 28 16238000A *****...
