  • Page 1: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS Safety Instructions ..........INSTALLATION Product Description ..........Installation ............OPERATIONS Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Option..............Other Functions ............. Programmes ............MAINTENANCES Cleaning And Care ..........Trouble Shooting ............ Technical Specifications .........

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: ！ Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in...
  • Page 3 SAFETY INSTRUCTIONS • The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. • Before any maintenance the device, unplug the appliance from the mains. • Always unplug the machine and turn off the water supply after use.
  • Page 4 SAFETY INSTRUCTIONS • Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation very wet rooms as well as in the rooms with explosive or caustic gas. • Remove all packages and transport bolts before using the appliance.
  • Page 5 SAFETY INSTRUCTIONS • Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result. Risk of damaging appliance! • Your product is only for home use and is only designed for the textiles suitable for machine washing. •...
  • Page 6 SAFETY INSTRUCTIONS • Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine. • Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.

  • Page 7: Installation

    INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service filter Drain hose Note! • The product line chart is for reference only, please refer to real product as standard. Accessories Transport Drain hose support Owner’s manual...

  • Page 8: Installation

    INSTALLATION Installation Installation area ！ Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. W> 20mm Before installing the machine, the location characterized follows shall be selected: 1.Rigid, dry, and level surface 2.Avoid direct sunlight 3.Sufficient ventilation...
  • Page 9 INSTALLATION Levelling the washing machine ！ Warning! • The lock nuts on all four feet must be screwed tightly against the housing. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2.Loosen the lock nut turn the feet until it closely contacts with the floor.
  • Page 10 INSTALLATION Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise. water supply hose water Inlet valve Drain Hose ！ ！ Warning! Warning! • Do not kink or protract the drain hose. •...

  • Page 11: Operations

    OPERATIONS Quick Start Caution! • Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Main wash Softener...

  • Page 12: Before Each Washing

    OPERATIONS Before Each Washing • The working condition of the washer should be(0-40)℃.If used under 0℃,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0℃or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use.

  • Page 13: Detergent Dispenser

    OPERATIONS Detergent Dispenser Pre wash detergent Main wash detergent Softener Dam-board Dam-board Liquid detergent Powder detergent Pull out the dispenser Caution! • Detergent only need to be added in "case I “after selecting pre-washing for machines with this function. Programme Programme Cotton Eco Bulky/Bedlinen...

  • Page 14: Control Panel

    OPERATIONS Control Panel Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched On/Off. Press the button to start or pause the washing cycle. Programmes Option Available according to the laundry type. This allows you to select an additional function and will light when selected.
  • Page 15 OPERATIONS Option Delay Set the Delay function: 1. Select a programme; 2.Press the Delay button to choose the time(the delaying time is 0-24 H.); 3.Press [Start/Pause] to commence the delay operation Delay Setting time Start Choose the Programme Cancel the Delay function: Press the [Delay] button until the display be 0H.It should be pressed before starting the programme.

  • Page 16: Other Functions

    OPERATIONS Other Functions Temp. ℃, Press the button to regulate the temperature(Cold,20 40℃,60℃,90℃) Speed Press the button to change the speed. 1200: 0-400-600-800-1000-1200 1400: 0-400-600-800-1000-1200-1400 Programme Programme Default Speed(rpm) Default Speed(rpm) 1200 1400 1400 1200 Cotton Eco Rinse & Spin Cotton Bulky/Bedlinen 1200...
  • Page 17 OPERATIONS Child Lock To avoid mis operation by children. Temp. Function Temp. Choose the Start Press [ ] and [ [Temp.] and [Dry] Temp. Function Programme 3 sec. till buzzer beep. Caution! When child lock is activated and program starts, child lock indicator will switch on, and the CL and remaining time on the display are alternately displayed in 0.5s.

  • Page 18: Programmes

    OPERATIONS Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made of cotton or Cotton linen. Wash synthetic articles, for example: shirts, coats, blending. Synthetic While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles.
  • Page 19 OPERATIONS Programmes Dry Only Select it to dry clothes, the temperature is different .The drying time according to the load . 1Hour W/D For small synthetic clothes or shirts, load limitation is 1 kg (about 4 shirts). When you have an urgent appointment but no more clean shirt left in your cupboard, this program will help you.Time duration is only 1 hour including wash and dry.

  • Page 20: Maintenances

    MAINTENANCES Cleaning And Care ！ Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary.
  • Page 21 MAINTENANCES Cleaning The Inlet Filter Note! • Inlet filter must be cleaned if there is less water. Washing the filter in the tap 1.Close the tap. 2.Remove the water supply hose from the tap. 3.clean the filter. 4.Reconnect the water supply hose Washing the filter in washing machine: Screw off the inlet pipe from the backside of the machine.
  • Page 22 MAINTENANCES Cleaning The Drain Pump Filter ！ Warning! • Be careful of the hot water! • Allow detergent solution to cool down. • Unplug the machine to avoid electrical shock before washing. • Drain pump filter can filter the yarns and small foreign matters from the washing.

  • Page 23: Trouble Shooting

    MAINTENANCES Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Description Reason Solution Washing machine Restart after the door is closed Door is not closed properly cannot start up Check if the clothes is stuck...

  • Page 24: Technical Specifications

    MAINTENANCES Technical Specifications Power Supply 220-240V~,50Hz MAX.Current Standard Water Pressure 0.05MPa~1MPa Model Rated Power Washing Capacity Dimension Net Weight (W*D*Hmm) 6.0kg 2050W 595*470*850 54kg 7.0kg 2050W 595*495*850 60kg 8.0kg 595*565*850 68kg 2000W 10 24 10 24...
  • Page 25 MAINTENANCES Model Capacity 1200 rpm Spin Speed A+++ Energy efficiency class 153kWh /annual Annual energy consumption 0.5W Power consumption of off - mode 1.0W Power consumption of Left on -mode 9240L /annual Annual water consumption Spin- drying efficiency class Cotton Eco Standard washing cycle 0.77 kwh /cycle Energy consumption of the standard 60°C at full load...
  • Page 26 MAINTENANCES Model Capacity 1400 rpm Spin Speed A+++ Energy efficiency class 174kWh /annual Annual energy consumption 0.5W Power consumption of off - mode 1.0W Power consumption of Left on -mode 9900L /annual Annual water consumption Spin- drying efficiency class Cotton Eco Standard washing cycle 0.91 kwh /cycle Energy consumption of the standard 60°C at full load...
  • Page 27 MAINTENANCES Model Capacity 1400 rpm Spin Speed A+++ Energy efficiency class 196kWh /annual Annual energy consumption 0.5W Power consumption of off - mode 1.0W Power consumption of Left on -mode 11000L /annual Annual water consumption Spin- drying efficiency class Cotton Eco Standard washing cycle 0.90 kwh /cycle Energy consumption of the standard 60°C at full load...

  • Page 28: Product Fiches

    MAINTENANCES Note! • Programme setting for testing in accordance with applicable standard En60456 for wash. • Programme setting for testing in accordance with applicable standard En50229 for wash and dry. • When using the test programmes, wash the specified load using the maximum spin speed.
  • Page 42 Pre Lavadora Bloqueo de Acalarado la puerta Extra...
  • Page 43 ropa de cama ropa de bebé lana ropa deportiva diario 45 vaqueros Rápido 15 color centrifugado...
  • Page 44 ropa de cama ropa de bebé lana ropa deportiva vaqueros diario 45 color Rápido 15 centrifugado...
  • Page 46 Diario 45 Color Este progrma es especial para cargar color; puede proteger mejor los colores. limpieza tambor ropa deportiva Este programa para lavar las prendas deportivos. ropa de cama Este programa para lavar las prendas tranquilamente.
  • Page 47 Solo seco: Selecciónelo para secar la ropa, la temperatura es diferente. El tiempo de secado según la carga. 1 hora W / D: para ropa o camisas sintéticas pequeñas, la limitación de carga es de 1 kg (alrededor de 4 camisas). La duración del tiempo es de solo 1 hora, incluido el lavado y secado.
  • Page 52 6.0kg 2050W 595*470*850 54kg 7.0kg 2050W 595*495*850 60kg 8.0kg 595*565*850 68kg 2000W...
