CD 5230
Shown with optional stand.
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
Specifications subject to change without notice. Selection, offers and programs may vary by country; see your
ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [15056-00B-06/10] CD5230-1
For more product information, visit us on the web at ViewSonic.com
52 " S L I M B E Z EL F UL L HD 108 0P
COM ME RC I A L L C D D I SPL AY
LCD
Type
Display Area
Optimum Resolution
Contrast Ratio
Viewing Angles
Response Time
Light Source
Brightness
Aspect Ratio
Panel Surface
INPUT
Video Input
Video Output
Control Input/Output
AUDIO OUTPUT
Amplifier
INPUT SIGNAL
TV/Video Comp.
CONNECTOR
Analog
Digital
Power
POWER
Voltage
Consumption
CONTROLS
Panel
VGA Setting
OSD Setting
Input
Audio
Special
Diagnostic
OPERATING
Temperature (landscape)
CONDITIONS
Temperature (portrait)
Humidity
DIMENSIONS
Physical with stand (optional)
(W x H x D)
Physical without stand
WEIGHT
Net with stand (optional)
Net without stand
Gross without stand
VESA
MOUNT
®
REGULATIONS
RECYCLE/DISPOSAL
PACKAGE CONTENTS
WARRANTY
Complete Your Digital Signage Solution
Add a network media player and digital signage software.
Media Players
• NMP-550 (RISC-based)
• NMP-600 (X-86-based)
• NMP-610 (X-86-based)
• NMP-700 (X-86-based)
Software
• ViewSonic's Signage Manager Express
• VMS 2.0
• FriendlyWay Composer Software
• Best Wave DisplayIt! Software
52" color TFT active matrix, wide LCD
45.3" horizontal x 25.5" vertical; 51.9" diagonal
1920x1080
2500:1 (typ)
178º horizontal, 178º vertical
8ms
Long life, 50,000 hrs. (typ)
700 cd/m2 (typ)
16:9
Anti-glare, hard coating (3H)
HDMI, DVI, component, VGA
VGA, component, DVI
RS-232
2-watt
480i, 480p, 720p, 1080i, 1080p
15-pin mini D-sub (VGA)
HDMI, DVI
3-pin plug
AC 100–240V (universal), 50–60Hz
360W (typ)
Power, Exit, +, –, Menu/Enter
Picture mode, contrast, brightness, color temperature,
temperature adjust, sharpness
Auto adjustment, clock, phase, sharpness,
H. position, V. position
Languages, OSD H. position, OSD V. position, OSD timer
VGA, DVI, HDMI, YPbPr
Volume, mute, audio source
Aspect ratio, over scan, power save, image retention,
auto adjustment, monitor ID, reset
Thermal, back light, ambient, 5V detect, 12 detect
32–104ºF (0–40ºC)
41–95ºF (5–35ºC)
20–80% (non-condensing)
47.1" x 29.1" x 8.8" (1197mm x 740mm x 223mm)
47.1" x 27.4" x 5.0" (1197mm x 693mm x 126mm)
88.9 lb. (40.3 kg)
83.8 lb. (38.0 kg)
99.21 lb. (45.0 kg)
400mm x 200mm
UL/FCC-B
The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
LCD display, power cable, remote control
with batteries, Quick Start Guide
Three-year limited warranty on parts, labor and backlight
