Sparklan WPEQ-276AX Manual

Specification
Standards
Chipset
Data Rate
Operating Frequency
Interface
Form Factor
Antenna
Modulation
Power Consumption
Operating Voltage
Operating Temperature Range
Storage Temperature Range
Humidity
(Non-Condensing)
Dimension L x W x H (in mm)
Weight (g)
Driver Support
Security
WPEQ-276AX
Manual
IEEE 802.11ax 2T2R 6G
Qualcomm Atheros QCN9072
802.11ax: HE0~11
IEEE 802.11ax
5.925~7.125GHz
*Subject to local regulations
WLAN: PCIe
Mini PCIe
2 x IPEX MHF1 connectors
Wi-Fi :
802.11ax: OFDMA (BPSK, QPSK, DBPSK, DQPSK, 16-QAM, 64-QAM, 256-QAM,
1024-QAM, 4096-QAM )
TX mode: 1288mA(Max.)
RX mode: 965mA(Max.)
DC 3.3V
-20°C ~ +70°C
-20°C ~ +90°C
5%~90% (Operating)
5%~90% (Storing)
50.80mm(±0.15mm) x 29.85mm(±0.15mm) x 9.30mm(±0.3mm)
14.82g
Linux
64/128-bits WEP, WPA, WPA2,WPA3,802.1x
