Specification
Standards
Chipset
Data Rate
Operating Frequency
Interface
Form Factor
Antenna
Modulation
WNFQ-291BE(BT)
Manual
IEEE 802.11be/ax/ac/a/b/g/n (2T2R)
Bluetooth V5.4,V5.3,V5.2, V5.1, V5.0, V4.2, V4.1, V4.0LE, V3.0, V2.1+EDR
Qualcomm WCN7851
802.11b: 11Mbps
802.11a/g: 54Mbps
802.11n: MCS0~15
802.11ac: MCS0~9
802.11ax: MCS0~13
802.11be: MCS0~13
Bluetooth: 1 Mbps, 2Mbps and Up to 3Mbps
IEEE 802.11 be/ax/ac/a/b/g/n
ISM Band, 2.412GHz~2.483GHz, 5.150GHz~5.850GHz ,5.925~7.125GHz
*Subject to local regulations
WLAN: PCIe
Bluetooth: USB
M.2 2230 E Key
2 x IPEX MHF4 connectors
Ant 1: WiFi/BT
Ant 2 : WiFi/BT
Wi-Fi:
802.11b: DSSS (DBPSK, DQPSK, CCK)
802.11g: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11n: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11ac: OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM)
802.11ax: OFDMA (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM,
4096-QAM)
802.11be: OFDMA (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM,
Wireless Module

Advertisement

loading
Need help?

Need help?

Do you have a question about the WNFQ-291BE(BT) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sparklan WNFQ-291BE(BT)

Summary of Contents for Sparklan WNFQ-291BE(BT)

  • Page 1 Wireless Module WNFQ-291BE(BT) Manual Specification IEEE 802.11be/ax/ac/a/b/g/n (2T2R) Standards Bluetooth V5.4,V5.3,V5.2, V5.1, V5.0, V4.2, V4.1, V4.0LE, V3.0, V2.1+EDR Chipset Qualcomm WCN7851 802.11b: 11Mbps 802.11a/g: 54Mbps 802.11n: MCS0~15 802.11ac: MCS0~9 Data Rate 802.11ax: MCS0~13 802.11be: MCS0~13 Bluetooth: 1 Mbps, 2Mbps and Up to 3Mbps IEEE 802.11 be/ax/ac/a/b/g/n Operating Frequency ISM Band, 2.412GHz~2.483GHz, 5.150GHz~5.850GHz ,5.925~7.125GHz...
  • Page 2 Wireless Module 4096-QAM) Header: GFSK Payload 2M: π/4-DQPSK Payload 3M: 8-DPSK 11be TX mode: 1250 mA (MAX) Power Consumption RX mode: 1200 mA (MAX) DC 3.3V Operating Voltage -10°~70°C (Operating) Operating Temperature Range -10°~70°C Storage Temperature Range 5%~90% (Operating) Humidity 5%~90% (Storing) (Non-Condensing) 30mm(±...
  • Page 3 Wireless Module Installation  Connect the Module to the PCIe slot of the computer.  Install Wi-Fi driver driver.  After the Wi-Fi Driver is installed , click the Network icon on the Windows, then search the network , and connect the Wireless Network you want.

  • Page 4: For Portable Device Usage

    Wireless Module Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 Wireless Module FOR 穿戴式產品 Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 5 mm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components.
  • Page 6 Wireless Module The module is tested for standalone mobile RF exposure use condition. Any other usage conditions such as co-location with other transmitter(s) or being used in a portable condition will need a separate reassessment through a class II permissive change application or new certification.
  • Page 7 Wireless Module The following antennas have been certified for use with this module; antennas of the same type with equal or lower gain may also be used with this module, except as described below. The antenna must be installed such that 20 cm can be maintained between the antenna and users.
  • Page 8 2.12 How to make changes Only Grantees are permitted to make permissive changes. Please contact us should the host integrator expect the module to be used differently than as granted: Grady Lin / CTO SparkLAN Communications, Inc. Tel: 886-2-2659-1880 Fax: 886-2-2659-5538 E-mail: grady.lin@sparklan.com...
  • Page 9 Wireless Module IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product.
