- Page 1 Wireless Module SparkLAN WPEB-265AXI(BT) [B33] & AP12275_PB33 WPEB-265AXI(BT) [B18] & AP12275_PB18 WPEB-265AXI(BT) [R33] & AP12275_PR33 WPEB-265AXI(BT) [R18] & AP12275_PR18 HW User manual Version 0.0 Revision History Date Revision Content Revised By Version 2020/12/30 Initial released Wayne...
-
Page 2: Table Of Contents
Wireless Module Contents Revision History ....................... 0 1. WPEB-265AXI(BT) [XXX] Series Hardware User Manual Introduction ....2 1.1. Module Block Diagram ..................2 1.2. External Reference Circuit ................3 2. PCB Layout Guide ...................... 5 2.1. PCI-e Layout Guide ..................5 USB Layout Guide .................... -
Page 3: Wpeb-265Axi(Bt) [Xxx] Series Hardware User Manual Introduction
This document provides customers with considerations for the hardware design of WPEB-265AXI(BT) [XXX] series. It includes hardware block diagram, reference design, PCB layout, and PCB stack up, which will be explained in detail below. 1.1. Module Block Diagram SparkLAN Ampak WPEB-265AXI(BT) [ B 33 ] &... -
Page 4: External Reference Circuit
Wireless Module 1.2. External Reference Circuit Connected to HOST I/O VIO Voltage Level [B33], [R33] : Typ.3.3V (3.0V~3.6V) [B18], [R18] : Typ.1.8V (1.62V~1.98V) Turn on the Wi-Fi function at default. WL_REG_ON C121 0.1uF HOST_PCIE_RDP PCIE_TDP C122 0.1uF HOST_PCIE_RDN PCIE_TDN HOST_PCIE_TDP PCIE_RDP R116 HOST_PCIE_TDN... -
Page 5: Figure3. Pci-E Interface Connection Diagram
Wireless Module PCIe interface conection diagram HOST WPEB-265AXI(BT) [XXX] PCIe_TDP PCIE_RDN PCIe_TDN PCIE_RDP PCIe_RDP PCIE_TDN PCIe_RDN PCIE_TDP PCIE_REFCLKP PCIE_REFCLKP PCIE_REFCLKN PCIE_REFCLKN Figure3. PCI-e Interface Connection Diagram UART & PCM interface conection diagram HOST WPEB-265AXI(BT) [XXX] UART_CTS_N UART_CTS_N UART_RTS_N UART_RTS_N UART_TXD UART_TXD UART_RXD UART_RXD... -
Page 6: Pcb Layout Guide
Wireless Module 2. PCB Layout Guide 2.1. PCI-e Layout Guide 1. The PCI-e differential pair signals impedance target is 100±20% ohms impedance. 2. Do not place probe or test points on any high-speed differential signal. 3. Do not route high-speed traces under or near crystals, oscillators, clock signal generators, switching power regulators, mounting holes, magnetic devices, or ICs that use or duplicate clock signals. - Page 7 Federal Communication Commission Interference Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 8 the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. Unique antenna connector (RP-SMA) must be used on the Part 15 authorized transmitters used in the host product.
- Page 9 Industry Canada statement: This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions: 1) This device may not cause interference, and 2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
- Page 10 pour l’exploitation point à point et non point à point, selon le cas. Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Déclaration d’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé.
- Page 11 Cette étiquette extérieure peut utiliser un libellé comme celui-ci: “ Contient IC: 6158A-PEB265AXIBT“. Plaque signalétique du produit final: Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 6158A-PEB265AXIBT ". Manual Information To the End User: The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
- Page 12 different operational conditions for a stand-alone modular transmitter in a host, host manufacturer have to consult with module manufacturer for the installation method in end system. l'hôte doit utiliser l'instrument uniquement dans des dispositifs qui répondent à la fcc / (catégorie d'exposition rf mobile, ce qui signifie le dispositif est installé et utilisé à...
