Sparklan WUBT-239ACN(BT) User Manual

WUBT-239ACN(BT)
802.11ac/a/b/g/n
Wi-Fi + Bluetooth 5.0
SparkLAN WUBT-239ACN(BT) is a highly integrated single-chip Wireless LAN (WLAN), Bluetooth USB
module which supports 2 streams 802.11ac solutions with multi-user MIMO (Multiple-Input, Multiple-
Output) wireless LAN (WLAN) and integrated Bluetooth 5.0. It is integrated 2Tx2R WLAN MAC, baseband,
and dual band RF in a single chip USB module. WUBT-239ACN(BT) provides a cost effective solution for
M2M (machine to machine) connectivity product/device by one USB
WUBT-239ACN(BT) 802.11ac/abgn 2Tx2R USB WLAN/BT module with various USB input format & internal
printing or external RF antenna connector for high performance wireless LAN and Bluetooth device. It is
designed to provide completely M2M connection & excellent cost performance with low power
consumption and enhance the advantages of robust system & applications.
Embedded Application
Applications include portable handheld
devices, thin client computer, medical
devices, network security & monitoring,
3D printer, TV, STB, POS, digital signs,
gaming machine, robotic machinery,
industrial tablets, etc.
All Rights Reserved. SparkLAN may make changes to specification and descriptions at any time without prior notice.
www.sparklan.com / sales@sparklan.com / +886 2 2659-1880
2T2R
USB Module
Key Feature

802.11ac/a/b/g/n Wi-Fi +Bluetooth 5.0

Support 802.11ac 2x2, compliant with MU-MIMO.
Operates in 2.4GHz and 5GHz frequency bands

Maximum data rates: 54Mbps in 802.11g, 300Mbps in
802.11n, 866.7Mbps in 802.11ac.
BT 5.0 features including Low-Energy 2 Mbps

Wireless Module
port.
WUBT-239ACN(BT)
ver.0.91
