V1.1
Microblower
MZB3004T04 / MZB3005T06 Driver Circuit Guide
March '25
This User's Manual includes warnings and cautions for safety.
Please read this User's Guide completely before operating the unit.
Please retain this document for future reference.
Murata Manufacturing Co., Ltd
Advertisement
Related Manuals for Murata MZB3004T04
Summary of Contents for Murata MZB3004T04
- Page 1 Microblower MZB3004T04 / MZB3005T06 Driver Circuit Guide March ‘25 This User’s Manual includes warnings and cautions for safety. Please read this User’s Guide completely before operating the unit. Please retain this document for future reference. Murata Manufacturing Co., Ltd V1.1...
- Page 2 This product is a sample for evaluation purposes only. Do not use this drive circuit in your finished product. Murata will not be liable for any claims if the sample drive circuit is shipped into the market. • Please note that Murata doesn’t guarantee the performance and reliability of our pump with this circuit. We recommend using the drive circuit outlined in the MZB3004T04 / MZB3005T06 specifications for guaranteed performance.
-
Page 3: Dc Power Supply
Driver circuit connections MicroBlower DC Power Supply Driver Circuit p/n MZB3004T04 (p/n MZBD304) Vdc input（GND） Output No polarity Vdc input（＋） p/n MZB3005T06 • Please use IC clips or lead wires when connecting DC power supply to drive circuit • Care should be taken when soldering lead wires, avoid touching soldering iron directly to the body of the... - Page 4 Considerations for soldering • Wiring Connection MicroBlower With the marking side facing up, wire should be routed up p/n MZB3004T04 through terminal and soldered. Marked side Soldering iron Apply solder to only this side of the terminal. Terminal Wiring •...
- Page 5 • This sample driver circuit (p/n MZBD304) is designed only for use with microblower p/n’s: MZB3004T04 / MZB3005T06. It cannot be used for other microblower part numbers • When using at low voltage (≦12Vdc), it might take a few seconds to start operation.
-
Page 6: Important Safety Instructions
Do not touch the circuit while it is operating. There is a risk of burns and electric shock due to high temperatures. 「駆動中は回路に触れないでください。(高温部による) 火傷と感電の恐れがあります。」 • Do not connect the circuit to any pump other than Murata's dedicated air pumps. 「専用のムラタ製エアポンプ以外と接続しないでください。」 Confidential... - Page 7 Important Safety Instructions Handling Warning 取り扱いに関する警告 • • Handle with care to avoid injury. Sharp edges of the circuit may pose a risk of cuts or punctures. Always wear appropriate protective gear, such as gloves, when handling.. 「基盤のエッジは鋭く、触るとけがをする恐れがあります。取扱時は手袋など適切な防具を着用してください • If you notice any abnormalities such as smoke, abnormal order, noise, immediately stop using the product and disconnect power 「異常（煙、異常な臭い、音など）を感じた場合は、直ちに使用を中止し、電源を切ってください。」...
- Page 8 Important Safety Instructions Warning regarding Power Supply 電源および充電に関する警告 • • Do not use with a voltage other than specified. May cause electric shock or fire. 「指定された電圧以外で使用しないでください。感電や火災の原因となることがあります。」 • Do not store this product in high temperature and humidity environments. There is a risk of fire and burns. 「本製品を高温多湿の場所に保管しないでください。火災や火傷の恐れがあります。」...
