instructions carefully and familiarize yourself with the different parts.
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1
HEADBOARD PANEL 1 PC
2
LEFT LEG
1 PC
3
RIGHT LEG
1 PC
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3) to headboard panel (1),
using wooden dowels (A) and JCB (B).
Tighten with the Allen wrench (C).
B
B
A
A
BACK VIEW
B
To ensure lasting safety, we recommend that you periodically check
BED WITH MATCHING FOORTBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your bed, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
TWIN > FULL
A
Wooden dowel - 4 pcs
B
JCB M6 X 35mm (1 3/8") - 4 pcs
A
1
3
A
Congratulations!
Your headboard is now assembled.
that all screws are tight and all parts are secure.
Spare - 1 pc
Spare - 1 pc
B
B
A
2
PO:
HARDWARE
C
Allen wrench - 1pc
Spare - 1pc
Adult assembly
CODE
ITEM
HBFB-MTR
R-29072X
READY
TO
ASSEMBLE
ITEM
R-29073X
Page 1 of 2
