Owner's Manual
Instructions for Assembly, Testing, Operation,
Log Splitter: Outdoor hydraulic powered machine that
READ and UNDERSTAND this manual completely before using log splitter.
All operators of this equipment must read and completely understand all safety information, operating instructions,
maintenance and storage instructions. Failure to properly operate and maintain the log splitter could result in serious
injury to the operator or bystanders from moving parts that can crush or cut, flying objects, burns, fire or explosion,
escaping high pressure hydraulic fluid, or carbon monoxide poisoning. In particular, be aware of the following
hazards:
Crush and Cut Hazards
Moving parts can crush and cut hands and fingers. Keep hands clear of endplate, wedge, log strippers, and logs
while splitting.
High Pressure Hydraulic Fluid Hazards
High fluid pressures and temperatures are developed in hydraulic log splitters. Hydraulic fluid escaping through
even a pin-size hole opening can puncture skin and cause severe blood poisoning. Inspect hydraulic system
regularly for possible leaks. Never check for leaks with your hand while the system is pressurized. Seek medical
attention immediately if injured by escaping fluid.
Fire Hazards
If your log splitter is intended for use near any ignitable forest, brush, or grassy covered land, the engine
exhaust should be equipped with a spark arrestor.
Keep a fire extinguisher with you, rated for ordinary combustibles and flammable liquids.
ASSEMBLY REQUIRED: This product requires assembly before use. See "Assembly" section for instructions.
INSPECT COMPONENTS. Closely inspect upon receipt to make sure no components are missing or damaged.
See "Assembly" section for instructions on whom to contact to report missing or damaged parts.
ADD ENGINE OIL and HYDRAULIC OIL BEFORE USING: This product is shipped without engine oil or
hydraulic oil. DO NOT start log splitter before adding both oils. See "Assembly" and "Initial Unpacking & Set-
up" sections for detailed instructions.
PRIME THE PUMP BEFORE USE: The pump on this product needs to be primed before use. See Initial Setup
for instructions.
Any Questions, Comments, Problems or Parts Orders
Call Iron & Oak Product Support 1-800-817-1005
MODELS:
BHVH3715GX
Servicing, & Storage
splits wood logs.
WARNING
STOP!
MBHVH3715A
ITEM NUMBER:
SERIAL NUMBER:
_______________
Advertisement
Table of Contents
Related Manuals for Iron & Oak BHVH3715GX
Summary of Contents for Iron & Oak BHVH3715GX
- Page 1 MBHVH3715A ITEM NUMBER: MODELS: SERIAL NUMBER: BHVH3715GX _______________ Owner’s Manual Instructions for Assembly, Testing, Operation, Servicing, & Storage Log Splitter: Outdoor hydraulic powered machine that splits wood logs. WARNING READ and UNDERSTAND this manual completely before using log splitter. All operators of this equipment must read and completely understand all safety information, operating instructions, maintenance and storage instructions.
-
Page 2: Hazard Signal Word Definitions
Hazard Signal Word Definitions... -
Page 3: Table Of Contents
About Your Log Splitter About Your Log Splitter ......................4 Safety Label Locations ......................5 Machine Components Identification ..................7 Initial Set-up ..........................8 Moving & Towing to the Job Site .................... 10 Before Each Use: Step One: Inspection/Maintenance ................. 13 Step Two: Fueling ...................... -
Page 4: About Your Log Splitter
About Your Log Splitter Thank you for purchasing your Iron & Oak log splitter! About Your Log Splitter This log splitter is a machine designed to split wood logs using a hydraulically powered moving wedge. The gasoline-powered engine is used to pressurize the system. This log splitter model is capable of splitting logs up to 24″... -
Page 5: Safety Label Locations
Safety Label Location Ref# Part # Description 778597 Horizontal Lock 778714 Vertical Lock 778609 Split Control Lever Operation 778610 Log Splitter Warning 39259 Carbon Monoxide Warning 789236 Towing and Moving Instructions 777891 High Pressure Hydraulic Fluid Hazard 777890 Fire Hazard 787944 Pinch Point Warning 777887... - Page 6 Safety Label Location...
-
Page 7: Machine Components Identification
Machine Component Identification Ref # Description Ref # Description End Plate Manual Tube Log Table Lift Handle Split Control Lever Horizontal Lock Wedge Suction Strainer Cylinder Magnetic Drain Plug Engine Guard Hydraulic Tank Engine Vertical Lock Hydraulic Oil Dipstick Beam Return Line Filter Fender Jack... -
Page 8: Initial Set-Up
Initial Set-up WARNING Carefully read and follow all instructions for initial assembly and set-up of this log splitter. Failure to properly assemble and set up this equipment could result in serious injury to the user or bystanders, or cause equipment damage. Step One: Assemble your log splitter. - Page 9 Initial Set-up Check the hydraulic system carefully: Step Four: Check Hydraulic 1. Visually inspect all hoses, tubing, clamps/fittings, pump, and cylinder for cracks, System fraying, kinks, or other damage. 2. Check all components for oily residue, which may indicate a leak. Do NOT operate the log splitter if there is any indication of damage or oily residue.
-
Page 10: Moving & Towing To The Job Site
Moving & Towing to Job Site WARNING The log splitter is heavy. It can crush and cause serious injury if it rolls out of control or tips over. Follow the instructions below for safely moving and towing the log splitter. Moving the log splitter 1. - Page 11 Moving & Towing to Job Site Towing: 1. Read Instructions Review towing safety instructions in your vehicle manual. 2. Check Tires Make sure tires are fully inflated and in good operating condition. See tire sidewall for recommended tire pressure. WARNING: ●...
- Page 12 Moving & Towing to Job Site Attach Safety Attach safety chains. Chains 1. Two safety chains must be used while towing. 2. Cross safety chains under the coupler allowing only enough slack for vehicle turns. To provide adequate ground clearance while towing, secure the jack in the “UP” Put Jack Up position.
-
Page 13: Before Each Use - Inspection / Maintenance
Before Each Use – Inspection / Maintenance Step One: Inspect and maintain log splitter before each use. If the log splitter has been used previously, it must be inspected and maintained BEFORE EACH SUBSEQUENT USE. WARNING ALWAYS shut off the engine, disconnect the spark plug, and relieve system pressure before inspecting, cleaning, adjusting, or repairing the splitter. - Page 14 Before Each Use – Inspection / Maintenance Check the hydraulic system carefully: 5. Hydraulic system 1. Visually inspect all hoses, tubing, clamps/fittings, pump, and cylinder for cracks, fraying, kinks, or other damage. 2. Check all components for oily residue, which may indicate a leak. Do NOT operate the log splitter if there is any indication of damage or oily residue.
-
Page 15: Before Each Use
Before Each Use – Fueling Step Two: Fueling WARNING Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Use extreme care when handling gasoline. 1. Engine off / cool The engine must be off and allowed to cool at least two minutes before adding fuel. -
Page 16: Step Three: Work Site Selection & Set-Up
Before Each Use – Work Site Selection & Set-Up Step Three: Work site selection and log splitter set-up WARNING It is important to select an appropriate work site and properly set up the log splitter in order to minimize the risk of slips and falls, equipment rolling or tipping over, carbon monoxide poisoning, and accidental fires. -
Page 17: Splitting Operation
Splitting Operation WARNING Before starting the log splitter, review the following instructions and safety information for safe operation. Failure to follow these rules may result in serious injury to the operator or bystanders from moving parts that crush, cut, or entangle; from flying objects, burns, fire, falling or tripping; or from carbon monoxide poisoning. - Page 18 Splitting Operation 1. Put on Wear the following protective clothing and safety gear. protective 1) Eye protection. Always wear safety glasses or goggles when operating the machine. clothing / Pieces of log may fly out and serious eye injury can occur 2) Boots.
- Page 19 Splitting Operation b) Set to 1) Pull out horizontal lock catch pin, then grasp lifting handle and lift beam until it Vertical rotates into vertical position. position Crush hazard. The beam is heavy – do not let it just drop. It could WARNING: crush fingers or cause damage to the splitter.
- Page 20 Splitting Operation 5. Load log Load log onto beam between the wedge and an endplate, cut edge against the endplate - positioned for a lengthwise cut. Notes: a) The log splitter is designed only for cutting lengthwise with the grain, NOT for cutting across the grain.
- Page 21 Splitting Operation 6. Extend Move Split Control Lever toward endplate to extend wedge and split log. wedge Operator Position- Vertical Operator Position- Horizontal Important safety instructions: Operator position. ALWAYS operate the log splitter from the manufacturer's indicated OPERATOR POSITION. (See diagram above.) Other positions are unsafe because they can increase the risk of injury from crushing, cutting, flying objects, or burns.
- Page 22 Splitting Operation 8. Important If a log does not split completely and becomes stuck on the wedge, follow the instructions below to remove the log. STUCK LOG A log can become stuck to the wedge if the wedge becomes embedded in the log and the procedure log doesn't split and separate.
- Page 23 Splitting Operation 11. After use 1. Turn off engine. 2. Remove engine debris. Debris on a hot engine can be a fire hazard. After the engine is off, clean debris and chaff from engine cylinder head, cylinder head fins, blower housing rotating screen, and muffler areas.
-
Page 24: Storage
Storage WARNING Gasoline vapors can ignite and cause a fire. Select a well-ventilated storage area away from sources of heat, flame, or sparks. Follow the instructions below for storing your log splitter between uses: 1. Retract cylinder Retract the wedge completely to the hitch end of the log splitter to keep the rod protected from corrosion. -
Page 25: Periodic Maintenance
Periodic Maintenance In addition to the maintenance performed with each use, periodic maintenance should also be performed according to the following schedule. WARNING ALWAYS shut off the engine, disconnect the spark plug, and relieve system pressure before cleaning, adjusting, or repairing the splitter. Relieve system pressure by moving Split Control Lever back and forth several times. - Page 26 Periodic Maintenance thereafter. 1. Use a 788283-1 return line filter. 2. Shut down the engine on the Log Splitter. 3. Relieve hydraulic system pressure by moving the splitter control lever back and forth several times. 4. Unthread the canister and discard it along with the accompanying seal. Note: A strap wrench may be required.
-
Page 27: Troubleshooting
Troubleshooting WARNING Before troubleshooting or attempting to service, read the following safety instructions to avoid serious injury to the operator or bystanders from moving parts that can crush or cut, burns, fire or explosion, or escaping high pressure hydraulic fluid. Important Safety Instructions 1. -
Page 28: Specifications
Specifications Maximum Pressure …..…… 3500 PSI Maximum Flow …..…….. 16 GPM Hydraulic Fluid Capacity.…… 12 Gallons Hydraulic Fluid Type………… *10 wt AW32, ASLE H-150, or ISO32 Engine Size………………….. 270 cc Coupler Size...………….……. 2″ Maximum Towing Speed.…… 55 MPH pavement, 45 MPH gravel Maximum Log Length ... -
Page 29: Parts Breakdown - Exploded View
Parts Breakdown - Exploded View – Rev A... - Page 30 Parts Breakdown - Exploded View – Rev A Ref# Part# Description Ref# Part# Description 791869 Hydraulic Control Valve 793162 5 x 24 Cylinder 778827 8 MOR-8FP Elbow 778592 Pin for Cylinder 788209 ½" x 18.5" Hose 30313 Bridge Pin 788206 ½"...
-
Page 31: Summary Of Important Safety Information For Operation
Summary of Important Safety Information for Operation WARNING Carefully read and make sure you understand the following safety information before using the log splitter. Improper use or maintenance of the log splitter can result in serious injury to the operator or bystanders from moving parts that can crush or cut, flying objects, escaping high pressure hydraulic fluid, or carbon monoxide poisoning. - Page 32 Summary of Important Safety Information for Operation Tires. Be sure the tires are fully inflated and in good repair before towing the log splitter. When adding air to the tires, do not over-inflate – serious injury could occur if tire explodes. ...
- Page 33 Summary of Important Safety Information for Operation Safety During Inspection/Maintenance Always inspect your log splitter before each use, and repair as needed, to keep it in safe working condition: Engine off. Always make sure the engine is off before cleaning, repairing or adjusting the splitter, except as recommended by the manufacturer.
- Page 34 Summary of Important Safety Information for Operation Don't overfill. DO NOT overfill the gas tank. Allow at least 1/2" of empty space below the fill neck to allow for fuel expansion. Replace cap. Replace gas cap securely before starting engine. ...
- Page 35 Summary of Important Safety Information for Operation Other exhaust dangers. Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Avoid inhalation of exhaust.
- Page 36 Summary of Important Safety Information for Operation Adding attachments to the splitter. Personal injury could result from log or metal pieces flying out at high speed toward the operator or bystanders, or the splitter could become damaged. Changing splitting position. Do not change splitting positions (horizontal/vertical) with the engine running. You may contact the muffler and receive serious burns.
-
Page 37: Packaging Removal And Assembly Instructions
Package Removal and Assembly Instructions Crate Contents: Log Splitter, Tongue Assembly, and Manual Bag. Tools needed: Side cutters, hammer, crowbar, and power screw driver, torque wrench, 1/2” socket, 1/2” wrench, ratchet 1. Cut all bands holding splitter to the pallet. Use 1/2 x 3”... - Page 38 Package Removal and Assembly Instructions 4. Use a hammer and crowbar to remove boards that surround the splitter and those that support and protect the engine. 5. Remove board screwed down over the splitter endplate by removing the screws with a power screw driver.
-
Page 39: Limited Warranty
This limited warranty is in lieu of any other warranty expressed or implied, written or oral and Iron & Oak assumes no other responsibility or liability outside that expressed within this limited warranty. Limited Warranty for Log Splitter Models: BH2W2015GX BHVH3715GX Consumer Warranty Period Commercial Warranty Period Weldments... - Page 40 This page has intentionally been left blank.
- Page 41 Iron & Oak Product Registration Form Your Information Full Name: Last First M.I. Address: Street Address Apartment/Unit # City State ZIP Code Home Phone: Alternate Phone: Email Address: Purchased From Company: Address: Street Address Apartment/Unit # City State ZIP Code Model Information Purchase Date: □...
- Page 42 Great Northern Equipment Distributing Inc. 20195 S. Diamond Lake Rd, Ste 100 Rogers, MN 55374 Assembled in USA...
