0.7 CFM Air Inflator
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #6108531
Thank you very much for choosing a IRONTON product!
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ironton 6108531
Summary of Contents for Ironton 6108531
- Page 1 Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #6108531 Thank you very much for choosing a IRONTON product! READ & SAVE THESE INSTRUCTIONS...
- Page 2 For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Assembly Instructions .......................... 8 Before Each Use ............................ 8 Operating Instructions .......................... 9 After Each Use ............................9 Troubleshooting .......................... -
Page 4: Intended Use
Intended Use The Ironton Portable Tire Inflator with digital tire pressure gauge can inflate your standard car tires in seconds. A simple press on car air inflator and it will do all work for you. A great solution for emergency on this way. - Page 5 ⚠WARNING • This product may contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm. ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury.
-
Page 6: Specific Operation Warnings
⚠CAUTION PRODUCT USE AND CARE Do not force the product. Products are safer and do a better job when used in the manner for • which they are designed. Plan your work, and use the correct product for the job. •... - Page 7 allow it to cool before continuing operation. Use a second tire pressure gauge to verify the tires are inflated to the proper pressure. • ⚠WARNING • Forbidden disassembly battery The battery has a protection mechanism and a protection circuit inside to avoid danger. Improper removal will damage the protective function and will cause the battery to heat, smoke, deform or burning.
-
Page 8: Assembly Instructions
Assembly Instructions Before Each Use ⚠WARNING Attention • Avoid using batteries in strong light exposure environments, to avoid hot, deform, burning, at least to avoid battery performance degradation and reduced life. • Antistatic There is a protection circuit in the battery to avoid various accidents, do not use the battery in places where static electricity is generated, because static electricity (more than 2200V) is easy to damage the protection board, resulting in abnormal battery work. -
Page 9: Operating Instructions
Operating Instructions General Operation. 1. Put one end of the air hose connection with the air inflator, and screw the other end into the tire valve core. For the French valve core, please tighten the conversion nozzle. 2. LCD screen intelligent air inflator, first long time press the “ " button to active the power supply and 3. -
Page 10: Troubleshooting
Troubleshooting Use the table below to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance Failure Possible Cause Corrective Action There’s a poor connection between the 1. Gently turn the plug in the cigarette plug and the socket. -
Page 11: Parts Diagram
Parts Diagram Part List 1. Air Inflator 2. Air Hose 3. 12V DC Power Cable 4. USB Power Cable 5. Storage Pouch 6. Inflation Needle 7. Inflator Nozzle 8. All Brass Schrader Chuck 9. Presta Chuck Page 11 of 14... -
Page 12: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. •... -
Page 13: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 14 of 14...
