14-oz. Pistol Grip Grease Gun
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #74936
READ & SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 74936 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ironton 74936

Summary of Contents for Ironton 74936

  • Page 1 14-oz. Pistol Grip Grease Gun Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #74936 READ & SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Grease Gun ........................6 Assembly Instructions .......................... 7 Before Each Use ..........................10 Operating Instructions ........................

  • Page 4: Intended Use

    Intended Use The Ironton 14-oz. Pistol Grip Grease Gun features the convenience of three-way loading. • Pistol grip for use in tight spaces. • Air bleeder valve eliminates air lock. Packaging Contents • • • • 1/8 NPT Fixed Spout 7”...
  • Page 5 ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. •...

  • Page 6: Specific Operation Warnings

    • Store the product when it is not in use. Store it in a dry, secure place out of the reach of children. Inspect the tool for good working condition prior to storage and before re-use. • Use only accessories that are recommended by the manufacturer for use with your product. Accessories that may be suitable for one product may create a risk of injury when used with another tool.

  • Page 7: Assembly Instructions

    Reference Number Subassembly Adjustable Handle Assembly Air Filler Main Head Tube Container T-Handle Lock Rigid Spout Coupler Assembly Instructions 1. Screw the tube container into the grease gun head. 2. Attach the spout/coupler assembly to the grease gun head. Cartridge Loading 1.
  • Page 8 2. Pull the handle back until it is fully extended. Lock it into place with the locking plate. 3. Remove the cap and/or lid from both ends of the cartridge (not included). Insert the cartridge into the tube container in the direction indicated on the cartridge. Make sure that the cartridge is as far in as possible.
  • Page 9 (not included). 3. Pull back slowly and extend the tube handle fully to draw grease upward into the tube container. Lock the T-handle into place with the locking plate when it is fully extended. 4. Reassemble the tube container to the main head. Press the locking plate to release the T-handle. Press the handle in as far as it will go.

  • Page 10: Before Each Use

    4. Insert the pin into the air filler valve again to release the trapped air. The grease gun is now ready to use. Before Each Use Before each use, prime the grease gun by following the Operation Instructions until grease flows from the tip.

  • Page 11: Troubleshooting

    Clean leftover grease from the tube container after each use. • Using a cloth, clean the fill nozzle and the tip, removing any dirt, grease, or debris. • Wipe off the entire grease gun. • Pull the handle back until it is fully locked into the lock plate. Maintain the grease gun by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures.

  • Page 12: Parts Diagram

    Failure Possible Cause Corrective Action Disconnect any extensions and prime until grease flows. There is trapped air in the grease gun. Release trapped air in the grease gun. The grease gun continues to lose Refill the grease gun and repeat The grease gun is out of grease.

  • Page 13: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in India Page 14 of 14...
