- Page 1 14.4 Volt Li-ion Grease Gun Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #75417 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Grounding .............................. 6 Extension Cords ............................ 7 Main Parts of Grease Gun ........................8 Assembly Instructions .......................... 8 Before Each Use ............................ -
Page 4: Intended Use
Intended Use The Ironton 14.4 Volt Li-ion Grease Gun is designed to pump and dispense lubricant using battery power. A battery pack, charger, and 30” flexible hose are included. Packaging Contents • • • Cordless Grease Gun 14.4 Volt Battery Pack Charger •... - Page 5 ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. •...
-
Page 6: Specific Operation Warnings
Inspect the tool for good working condition prior to storage and before re-use. • Use only accessories that are recommended by the manufacturer for use with your product. Accessories that may be suitable for one product may create a risk of injury when used with another tool. -
Page 7: Extension Cords
Extension Cords ⚠WARNING • USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause overheating. -
Page 8: Main Parts Of Grease Gun
Main Parts of Grease Gun If any parts are missing, do not operate the tool until the missing parts are replaced. Subassembly Grease Gun Body Grease Tube Assembly High-pressure Hose 14.4 V Battery Pack Assembly Instructions ⚠WARNING • Recharge only with the charger specified for the battery. For specific charging instructions, read the operator’s manual supplied with your charger and battery. -
Page 9: Before Each Use
To remove the battery, push the release buttons and pull the battery pack away from the tool. To insert the battery, slide the pack into the body of the tool. Make sure it latches securely into place. Before Each Use ⚠WARNING •... - Page 10 Charger Operation • If the battery pack is installed in the gun, remove it by depressing the two battery release buttons (one button on each side of the battery pack) and pulling the battery pack out of the gun. • Insert the charger power plug into the 120V/ 60hz power socket.
- Page 11 Figure 2 • Remove the pull-tab from the grease cartridge and screw the grease tube assembly clockwise into the gun. • To release the follower rod, depress the follower key and push the follower rod forward into the grease tube assembly. Purge the air from the pump. See the Purging Air Pockets section. Filling the Gun from a Bulk Container •...
- Page 12 • When you have finished applying grease, remove the high-pressure hose coupler from the grease fitting by pulling it sideways. See Figure 6. ⚠WARNING • The pressure relief valve is factory preset at 7,000 PSI (+/- 500 PSI). Do not adjust the pressure relief valve.
- Page 13 Figure 9 • Carefully release the follower handle to eject the empty cartridge from the grease tube assembly. Re-Priming NOTE: The gun may lose its prime due to air pockets in the lubricant. 1. Withdraw the follower rod from the grease tube assembly and firmly push the follower rod back into the grease tube assembly.
-
Page 14: After Each Use
After Each Use ⚠WARNING • If the supply cord of the charger is damaged, it must be replaced only by a qualified service technician. • When storing, always remove the battery pack from the grease gun. Keep the grease gun and its accessories in a clean, dry location and out of the reach of children. -
Page 15: Troubleshooting
Maintain the grease gun by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from oil and grease. -
Page 16: Parts Diagram
Failure Possible Cause Corrective Action Wear ANSI-approved safety goggles and NIOSH-approved dust Blocked motor housing vents. mask/respirator while blowing dust out Pressure relief of motor using compressed air. valve remains open. Blockage in the line or the Check the hose and the grease fitting. grease fitting. -
Page 17: Replacement Parts
Number Part Description Quantity Push Block Pump Assembly Cover Stopcock Hex Nut Air Pocket Valve Coupler Hose Seal Ring Charger Trigger Switch Follower Handle Follower Key Spring Follower Rod Follower Follower Seal Screw Bolt Push Plate Pressure Relief Valve Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. -
Page 18: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 19 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 19 of 19...
